Upsilon production in STAR Pibero Djawotho for the STAR - PowerPoint PPT Presentation

Upsilon production in STAR Pibero Djawotho for the STAR Collaboration Texas A&M University QWG 2010 – FERMILAB – May 18-21, 2010

Outline I. Physics motivation II. Experimental apparatus A. RHIC machine B. STAR detector STAR ϒ trigger C. ϒ measurements III. A. p+p: baseline measurement B. d+Au: cold nuclear matter effects ϒ -hadron correlations: production mechanism C. IV. Conclusion and outlook for Au+Au May 18-21, 2010 QWG 2010 - FERMILAB 2

Physics motivation Sequential disappearance of states: ⇒ Color screening ⇒ Deconfinement T/T C 1/ 〈 r 〉 [fm -1 ] Matsui T and Satz H, PLB 178 416 (1986) ϒ (1S) 2 ⇒ QCD thermometer ⇒ QGP χ b (1P) Properties 1.2 J/ ψ (1S) ϒ ’(2S) Mocsy A and Petreczky P, PRD 77 014501 (2008) • Milestone measurements: χ b ’(2P) ϒ ’’(3S) ≤ T C χ c (1P) Ψ ’(2S) 1. Establish baseline in p+p and understand hadroproduction 2. Study cold nuclear matter effects in d+Au A .Mocsy, 417th WE-Heraeus-Seminar,2008 3. Investigate QGP properties in Au+Au May 18-21, 2010 QWG 2010 - FERMILAB 3

Expectations at RHIC energies ϒ (1S) does not melt • ϒ (2S) is likely to melt • ϒ (3S) will melt • Mocsy and Petreczky, PRL 99, 211602 (2007) May 18-21, 2010 QWG 2010 - FERMILAB 4

ϒ Pros and Cons: Physics Pros • Small background at M ee ~10 GeV/c 2 • Co-mover absorption (reduces yield) is very small – Lin and Ko, PLB 503, 104 (2001) • Recombination (enhances yield) negligible at RHIC ( σ bb << σ cc ) – Zhao and Rapp, PLB 664, 253 (2008) Cons • Extremely low rate – One ϒ per 10 9 minimum bias p+p interactions May 18-21, 2010 QWG 2010 - FERMILAB 5

ϒ Pros and Cons: Instrumental Pros • Efficient trigger - works in p+p up to central Au+Au collisions • Large acceptance at |y|<0.5 and Δφ =2 π • Large rejection factor ~10 5 in p+p • Sample full luminosity → no prescale Cons • Good resolution needed to separate all 3 ϒ S- states May 18-21, 2010 QWG 2010 - FERMILAB 6

Relativistic Heavy Ion Collider (RHIC) RHIC Species pp,dAu,CuCu,AuAu Energies 200 GeV, 500 GeV May 18-21, 2010 QWG 2010 - FERMILAB 7

Solenoidal Tracker At RHIC (STAR) EMC • Triggering → high-E T electron • E/p → e/h discrimination TPC • Tracking → momentum • dE/dx → electron ID BBC E-M Calorimeter • Triggering → min bias Projection Chamber • Luminosity monitor Time of Flight NIMA 499, 624 (2003) May 18-21, 2010 QWG 2010 - FERMILAB 8

STAR ϒ Trigger pp L0 Parameters (pp) High Tower E T > 3.5 GeV Trigger Patch E T > 4.3 GeV L0 Parameters (dAu,AuAu) E 1 Cluster High Tower E T > 4.0 GeV L0 L2 Parameters Data Trigger E 1 Cluster, Tower E 2 Cluster, AuAu cos( θ ), Invariant Mass θ E 2 Cluster Data May 18-21, 2010 QWG 2010 - FERMILAB 9

ϒ → e + e - in p+p at √ s=200 GeV ∫ L dt = 7.9 pb -1 of p+p (2006) arXiv:1001.2745 [nucl-ex] arXiv:1001.2745 [nucl-ex] Υ + + ( 1 S 2 S 3 S ) ⎛ ⎞ σ d ⎜ ⎟ + × = ± 23 B 114 38 pb ⎜ ⎟ − ee 24 dy ⎝ ⎠ = y 0 ( ) σ + σ = ± 38 24 pb DY 2 b b < < < | y | 0 . 5 , 8 m 11 GeV/c ee May 18-21, 2010 QWG 2010 - FERMILAB 10

Comparison of STAR ϒ cross section in p+p at √ s=200 GeV with theory and world data arXiv:1001.2745 [nucl-ex] CSM limits arXiv:1001.2745 [nucl-ex] • STAR data agrees with Color Evaporation Model (CEM) at NLO – Phys. Rept. 462, 125 (2008) • Color Singlet Model (CSM) underestimates STAR data by 2 σ – PRD 81, 051502 (2010) • STAR data consistent with world data trend May 18-21, 2010 QWG 2010 - FERMILAB 11

ϒ → e + e - in d+Au at √ s NN =200 GeV H.Liu, QM2009 • No inner silicon detectors (SVT+SSD), reduced material (X 0 ) in 2008 ∫ L dt=32 nb -1 ≈ 12.5 pb -1 (p+p equivalent) • • Signal+Background → unlike-sign electron pairs • Background → like-sign electron pairs Raw ϒ (1S+2S+3S) yield = 172±20(stat) extracted from M ee =7-11 GeV/c 2 • • Strong 8 σ signal Nucl.Phys. A830: 235c-238c (2009) May 18-21, 2010 QWG 2010 - FERMILAB 12

Nuclear Modification Factor arXiv:0907.4538 + + Y Y ' Y " ⎛ ⎞ d σ ⎜ ⎟ × = ± ± B 35 4 ( stat ) 5 ( syst ) nb ⎜ ⎟ ee dy ⎝ ⎠ = y 0 d+Au + + Υ Υ ' Υ " ⎛ ⎞ d σ × ⎜ ⎟ B dAu ⎜ ⎟ ee dy ⎝ ⎠ 1 = = × y 0 R dAu σ + + Υ Υ ' Υ " ⎛ ⎞ d σ × N dAu × ⎜ pp ⎟ B bin ⎜ ⎟ σ ee dy ⎝ ⎠ pp = y 0 σ = σ = 42 mb 2 . 2 b pp dAu R dAu ~ = ± + N 7 . 5 0 . 4 for minimum bias d Au bin R dAu =0.98±0.32(stat)±0.28(syst) p+p • Consistent with N bin scaling • Cold nuclear matter effects (shadowing) not large preliminary • 2009 p+p data will help reduce uncertainty on R dAu (improved statistics+reduced material) May 18-21, 2010 QWG 2010 - FERMILAB 13

ϒ -hadron correlations in d+Au at √ s=200 GeV • Current models can’t CSM COM simultaneously reproduce soft g quarkonia cross section, p T b b spectrum, and polarization ϒ ϒ b b – CDF, PRL 99, 132001 (2007) – D0 Note 5089-CONF hard g – Lansberg, arXiv:0811.4005v1 M. Cervantes, APS2010 [hep-ph] • Look for increase in hadronic activity on Δφ near-side peak as discriminator between CSM (Color d+Au Singlet Model) and COM (Color 200 GeV Octet Model) – Kraan, arXiv:0807.3123v1 [hep- ex] • Significant underlying event contributions seen in d+Au collisions. p+p in the works! May 18-21, 2010 QWG 2010 - FERMILAB 14

Summary and outlook for Au+Au • p+p at √ s=200 GeV � B ee ×(d σ /dy) ϒ + ϒ ’+ ϒ ” y=0 = 114±38 +23 -24 pb � ( σ DY + σ bb ) |y|<0.5,8<m<7 GeV/c2 = 38±24 pb • d+Au at √ s=200 GeV � B ee ×(d σ /dy) ϒ + ϒ ’+ ϒ ” y=0 = 35±4(stat)±5(syst) nb � R dAu = 0.98±0.32(stat)±0.28(syst) • Au+Au at √ s=200 GeV � Cross section and R AA coming soon! • Higher integrated luminosity (20 pb -1 ) from 2009 p+p � Low material � Reduced uncertainty for R dAu � Possible separation of ϒ states May 18-21, 2010 QWG 2010 - FERMILAB 15

Backup Slides

Systematic uncertainties for ϒ in p+p arXiv:1001.2745 [nucl-ex] May 18-21, 2010 QWG 2010 - FERMILAB 17

Drell-Yan and b-bbar contributions � - � Obtaining the expected shape from bb simulation PHYTIA and Drell ‐ Yan (NLO pQCD). � The continuum cross sections determined by a combined fit to bg. subtracted data. May 18-21, 2010 QWG 2010 - FERMILAB 18

STAR ϒ Mass Resolution • STAR detector does not resolve individual states of the ϒ – Finite p resolution – e-bremsstrahlung • Yield is extracted from combined ϒ + ϒ′ + ϒ″ states • FWHM ≈ 1 GeV/c 2 W.-M. Yao et al . (PDG), J. Phys. G 33 , 1 (2006); R. Vogt et al ., RHIC-II Heavy Flavor White Paper (d σ /dy) y=0 B ee × (d σ /dy) y=0 State Mass [GeV/c 2 ] B ee [%] ϒ 9.46030 2.38 2.6 nb 62 pb ϒ′ 10.02326 1.91 0.87 nb 17 pb ϒ″ 10.3552 2.18 0.53 nb 12 pb ϒ + ϒ′ + ϒ″ 91 pb May 18-21, 2010 QWG 2010 - FERMILAB 19
