P14415: Plastic Arborloo Final Review Patrick Morabito Samuel - PowerPoint PPT Presentation

P14415: Plastic Arborloo Final Review Patrick Morabito Samuel Svintozelsky Nathan Conklin Michael Coffey John Wilson Agenda Background & Motivation Engineering Requirements Overview Vacloo Final Prototype Vacloo


  1. P14415: Plastic Arborloo Final Review Patrick Morabito Samuel Svintozelsky Nathan Conklin Michael Coffey John Wilson

  2. Agenda ● Background & Motivation ● Engineering Requirements Overview ● Vacloo Final Prototype ● Vacloo Mold and Build ● Vacloo Testing ● Deckloo Final Prototype ● Deckloo Testing ● Fixtures ● EPA ● Conclusion ● Assessment (Team and MSD)

  3. Background and Motivation Inadequate sanitation is a major cause of preventable illnesses in children around the world. According to UNICEF, diarrhea alone causes over 1.5 million deaths in children under 5 . These illnesses can easily be prevented by improving sanitation. However, cost is a major barrier limiting the adoption of sanitation in Haiti. Peter Morgan’s Arborloo is a simple latrine built over a small pit, which when filled is then moved to a new pit location. The old, filled pit then has vegetation planted on top of it, such as a fruit tree.

  4. Project Goal Design a low cost, plastic, portable, easily constructed, modern looking, and safe to use arborloo base to be used in rural Haiti to improve sanitation.

  5. Engineering Requirements

  6. Critical Engineering Requirements

  7. Design 1 - Vacloo Vacuum formed plastic sheet inserted over rebar support layout. Covered by High- Density Polyethylene cover and lid. Assembled product installed 2-3 inches below ground level to secure rebar.

  8. Design 1 - Vacloo Mold Rev 2 Mold Rev 3 Mold

  9. Design 1 - Vacloo Vacuum Forming Vacuum forming at RIT Vacuum forming at Faro Industries -0.25in HDPE - 0.0625 - 0.125 in HDPE - Rev 2 Mold - Rev 3 Mold - Results unsuccessful - Results successful

  10. Vacloo Testing Highlights ● Vacloo loaded to 572 lbs ● Vacloo costs $19.61 per assembly in lots of 100+ ● Vacloo satisfied 13 of 14 engineering requirements

  11. Design 2 - Deckloo 100% Recycled High-Density Polyethylene plastic lumber boards attached together by cross member supports. Includes cover attached by inner tube strips.

  12. Deckloo Testing ● Deckloo loaded to 572 lbs ● Deckloo costs $40.91 in lots of 100+ ● Deckloo satisfied 12 of 14 engineering requirements

  13. Testing Results

  14. Failed Tests ● Vacloo - Failed tripping hazard spec due to lid knob ● Deckloo - Failed tripping hazard spec due to lid knob ● Deckloo - Failed maximum hole size spec

  15. Rebar Fixture

  16. Deckloo Fixture

  17. EPA P3 Design Expo ● Washington D.C. April 25- April 27 ● Presented work to EPA judges and public in hope to receive additional funding ● Earned Honorable Mention

  18. For the Future! There are still 2.8 billion people without proper sanitation! ● Use EPA Honorable Mention to go for funding of future Arborloo projects ● Improve Deckloo fixture ● Assemble more Deckloos with leftover recycled plastic lumber ● Pursue all plastic Vacloo design

  19. MSD Assessment Recommendations: ● Design restricted by material and by concept ○ More creative solutions to problem possibly stifled ● Right for MSD? ○ Technical challenge ○ Humanitarian Passion ● Just provide powerpoint slides for the elevator speech in lieu of lecture ● Longer Phases-more time for project and less time working on presentations ● More in class time to work in MSDI ● Two column formatting for the technical paper ● Make the tables lower in the MSD room again

  20. Conclusion ● Successful design of lightweight cost effective pit latrine systems ● Possibility for further development ○ Vacuum Forming in Haiti? ● More Critical Reviews of team member’s work

  21. Acknowledgements We’d like to thank: ● Sarah Brownell ● Dr. Brian Thorn ● Pedro Cruz-Dilone ● Kevin Gebo ● Rick Auburn ● The Mechanical Engineering Department Machine Shop Faculty and Staff ● Faro Industries

  22. Questions?
