The performance of wind farms Evidence from the UK, Denmark and the - PowerPoint PPT Presentation

The performance of wind farms Evidence from the UK, Denmark and the US Professor Gordon Hughes University of Edinburgh 28 th January 2013 Background Wind power is a capital intensive technology Projections of load factors are critical


  1. The performance of wind farms Evidence from the UK, Denmark and the US Professor Gordon Hughes University of Edinburgh 28 th January 2013

  2. Background � Wind power is a capital intensive technology � Projections of load factors are critical for any assessment of costs and future investment � Difficulty of interpreting raw data � Systematic variations in wind conditions � Variations across sites & operational regimes � Changes in composition of turbine types, ages, etc � Lack of published evidence on performance of wind farms over time and by location 2

  3. Texas load factors - sparkline graphs 55578 55579 55581 55747 62 0 55795 55796 55968 55992 Load factor (%) 62 0 56111 56211 56212 56225 62 0 0 50 100 150 0 50 100 150 0 50 100 150 0 50 100 150 Months since Jan 2000 Graphs by plant_id

  4. Error components specification

  5. Period fixed effects vs wind speeds

  6. Statistical methods � Standard panel fixed effects estimation used with robust standard errors � Consistent estimates of coefficients under quite weak assumptions � Standard errors consistent if errors are heteroskedastic or serially correlated � Cross-check using bootstrap standard errors � No assumptions required about the distribution of the errors

  7. Analysis of UK onshore wind farms � Analysis of ROC monthly output for 2002-12 � Strong incentive to report reliable data � Standard panel fixed effects models allowing for age, period (wind availability), location � Multiplicative (log-linear) specification for load factor � Unit fixed effects capture site & location effects � Total of 296 separate reporting units analysed with total installed capacity of 4200 MW � Extensive testing to identify additional factors which influence performance 7

  8. United Kingdom onshore : quadratic vs age effects in additive model 8

  9. United Kingdom onshore : quadratic vs age effects in multiplicative model 9

  10. United Kingdom onshore : equal vs capacity weights in additive model 10

  11. United Kingdom onshore : equal vs capacity weights in multiplicative model 11

  12. Analysis of Danish wind farms � Data reported to Danish Energy Agency � Nominally for each turbine but aggregated for sites linked to a single meter � Data summed to wind farms defined by location, turbine type, installation date, etc � Onshore wind farms in Denmark are smaller and older than in the UK � 823 wind farms commissioned in 1992 or later with total capacity of 2570 MW � Limited sample of offshore wind farms � all in shallow water & most constructed in 2002 or later � 30 wind farms with total capacity of 860 MW 12

  13. Denmark: onshore wind farms 13

  14. Denmark: offshore wind farms 14

  15. Analysis of US wind farms � Data from Energy Information Agency (EIA) � Annual figures for plant characteristics � Monthly data for output – reported either monthly (largest plants) or annually � Data cleaning � Inconsistencies over time in reported capacity, etc � Sample of 673 plants over US � Initial analysis focuses on Texas [92 plants, 11.2 GW] and Minnesota [121 plants, 2.6 GW] � Extended to WSC (TX & OK – 13.6 GW), WNC (MN, IA, KS, ND, SD & NE – 12.3 GW) census regions covering about 50% of wind farms in US 15

  16. Texas: equal vs capacity weights in additive model 16

  17. Texas: equal vs capacity weights in multiplicative model 17

  18. Minnesota: equal vs capacity weights in additive model 18

  19. Minnesota: equal vs capacity weights in multiplicative model 19

  20. UK wind farms – age distribution 20 15 Wind farm age 10 5 0 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 20

  21. UK wind farms – capacity & turbine size 21

  22. UK – additive model by turbine size 22

  23. UK – multiplicative model by turbine size 23

  24. UK – additive model by country 24

  25. UK – wind & time trends Additive model Multiplicative model Full Wind & Time Full Wind & Time Age -1.159*** -1.719*** -0.0666*** -0.0861*** (0.257) (0.339) (0.015) (0.018) Age * medium 0.513** 0.659*** 0.0412*** 0.0422*** (0.227) (0.238) (0.015) (0.015) Age * large 1.288*** 1.515*** 0.0689*** 0.0735*** (0.252) (0.269) (0.016) (0.016) Age^2 0.00542 0.00417 0.00033 0.000307 (0.007) (0.008) (0.001) (0.001) Age^2 * medium -0.0321 -0.0385* -0.00250** -0.00251** (0.023) (0.021) (0.001) (0.001) Age^2 * large -0.125*** -0.126*** -0.00502** -0.00512** (0.035) (0.038) (0.002) (0.002) Wind 5.191*** 0.204*** (0.075) (0.003) Month 0.113*** 0.00529*** (0.026) (0.001) Constant 29.70*** -24.27*** 3.413*** 1.140*** (1.320) (1.552) (0.065) (0.067) R-squared 0.658 0.579 0.560 0.460 Number of groups 291 291 291 291 Robust standard errors in parentheses 25 *** p<0.01, ** p<0.05, * p<0.1

  26. UK – trend in additive period effects

  27. UK – trend in multiplicative period effects

  28. Denmark – trend in period effects

  29. Texas – trend in additive period effects

  30. Minnesota – trend in additive period effects

  31. UK : Median values of site effects by year Equal weights Capacity weights Additive Multiplicative Additive Multiplicative 2000 -0.61 0.06 9.55 0.71 2001 2.07 0.18 10.40 0.68 2002 3.83 0.21 11.46 0.69 2003 3.44 0.14 10.31 0.56 2004 -5.48 -0.34 -2.11 -0.04 2005 -0.87 -0.04 2.56 0.17 2006 -3.74 -0.17 -2.87 -0.15 2007 -2.36 -0.13 -2.05 -0.18 2008 -6.47 -0.33 -8.20 -0.49 2009 -3.87 -0.20 -6.00 -0.43 2010 -4.90 -0.25 -7.51 -0.53 2011 -8.14 -0.37 -12.07 -0.71 Average -3.40 -0.18 -3.63 -0.26 31

  32. UK : Determinants of site effects Additive model Multiplicative model (1) (2) (3) (4) Northern Ireland 4.683*** 4.520*** 0.200*** 0.195*** (0.999) (1.050) (0.047) (0.047) Scotland 5.259*** 6.554*** 0.202*** 0.241*** (0.910) (1.587) (0.038) (0.054) Wales 2.725*** 2.865*** 0.133*** 0.137*** (0.924) (0.955) (0.041) (0.044) Capacity in MW -0.0551*** -0.0537*** -0.00225*** -0.00221*** (0.017) (0.016) (0.001) (0.001) Year - 2000 -0.836*** -0.780*** -0.0479*** -0.0461*** (0.064) (0.069) (0.003) (0.003) (Year - 2000) * Scotland -0.219 -0.00664 (0.182) (0.006) Constant 0.817 0.552 0.0803*** 0.0723** (0.564) (0.588) (0.030) (0.034) Observations 291 291 291 291 R-squared 0.421 0.425 0.527 0.529 Bootstrap standard errors in parentheses; *** p<0.01, ** p<0.05, * p<0.1 32

  33. Performance degradation and output 33

  34. Age effects and project load factors UK & DK onshore experience 34

  35. Implications for energy policy 1 � Economic life of wind farms is no more than 15 years � Many onshore wind farms re-powered after 10-12 years � After 10 years the residual value of turbines is low, but there is an option value for site redevelopment � Costs of meeting renewable targets much higher than current forecasts suggest due to � Higher capacity required due to lower average load factors � Shorter operating lives implies higher replacement costs � Implications for financing investments � Not attractive to many infrastructure investors � Higher cost of capital due to uncertainty about length of investment return and residual values 35

  36. Implications for energy policy 2 � Impact of load factors on levelised costs � Increase from £86 to £183 per MWh for onshore wind and from £128 to £218 per MWh for R3 offshore wind � Market prices and/or subsidies required to fund renewable energy targets � DECC/CCC analysis based upon erroneous assumptions � Allowance of £8-10 per MWh for price differential � Total subsidy required in range £115-145 per MWh without any allowance for integration costs � Extra cost of offshore wind not as large as often thought 36

  37. Levelised costs : assumed vs actual performance 37

  38. Market prices by fuel type 38

  39. Differences between UK/TX & DK/MN � Average turbine size and scale of wind farms � Wake effects & maintenance regimes � Community ownership: capital vs operating costs � Resistance to larger turbines � Incentives for land use � Planning restrictions: upland sites and greater density of turbines � Treating wind turbines as short rotation forests � Link to cost of capital 39

  40. Conclusions � Improving the design and location of turbines � More detailed analysis of existing data � Longer term monitoring of installations � Implications for maintenance regimes � Lessons for lease contracts � Who should take performance risk? � Financing investment in wind energy � Structuring subsidies � Impact on financing new projects 40
