Power (CCHP) Systems in Future Energy Networks Student: Ke Qinyang - PowerPoint PPT Presentation

EEE38: Optimal Planning and Operation of Combined Cooling Heat and Power (CCHP) Systems in Future Energy Networks Student: Ke Qinyang School: Eunoia Junior College Supervisor: Prof. Xu Yan Teacher Mentor: Li Zhengmao School: Nanyang


  1. EEE38: Optimal Planning and Operation of Combined Cooling Heat and Power (CCHP) Systems in Future Energy Networks Student: Ke Qinyang School: Eunoia Junior College Supervisor: Prof. Xu Yan Teacher Mentor: Li Zhengmao School: Nanyang Technological University

  2. Energy

  3. Energy Consumption Trend 13730

  4. Efficiency 100% ?

  5. Solution? Renewable Energy Increase efficiency

  6. Combined Cooling Heat and Power (CCHP)

  7. Microgrid

  8. A microgrid is a small-scale power grid that is able to work independently or collaboratively with the others .

  9. Case Study Location: Northern China Mode: Grid-Connected Mode Season: Winter, Summer

  10. Advantage: 1. CCHP systems are able to recycle the exhausted gas and thermal energy and turn them into useful energy output 2. CCHP systems are able to generate electricity using multiple sources of energy, including renewable energy such as solar energy and wind energy 3. CCHP system is able to utilize electricity, heat, and cooling in an efficient and reliable manner 4. System’s stability and flexibility in different environments

  11. Future Improvement 1. Consider the energy storage system 2. Operation under Islanded Mode 3. Work on real work example

  12. Thank You!

  13. Reference 1. https://yearbook.enerdata.net 2. https://www.secureidnews.com/news-item/cyber-attack-takes-down-power-grid-60-substations/ 3. https://www.pewtrusts.org/en/research-and-analysis/issue-briefs/2016/02/why-and-how-microgrid-technology-is-a-good-power- source 4. https://news.energysage.com/five-types-of-renewable-energy-sources/ 5. https://www.raconteur.net/manufacturing/how-to-increase-efficiency-in-production 6. https://sites.google.com/site/heattransferwebquested5218/process/heat 7. https://www.weho.org/services/cooling-centers
