2016 Service School New Components and Systems ACR Automatic - PowerPoint PPT Presentation

2016 Service School New Components and Systems ACR Automatic Charging Relay Nautique Surf Select Pebble with Bluetooth communication Nautique Surf Switch with RF communication JL Audio Amps and Speakers: JL M-Series Studio


  1. 2016 Service School

  2. New Components and Systems  ACR Automatic Charging Relay  Nautique Surf Select  Pebble with Bluetooth communication  Nautique Surf Switch with RF communication  JL Audio Amps and Speakers:  JL M-Series Studio Elite with JL Wavefront  JL M-Series Elite  JL MX-Series Premier  Fast actuators for NSS  Fast ballast pumps

  3. More New Components and Systems  Ballast Senders  G Series  210, 230  Not Sport200  Helm Control

  4. ACR Automatic Charging Relay  Available on G series only  Isolates “Stereo” battery from “Engine” battery for cleaner power supply to the Stereo  Combines batteries only when alternator is charging

  5. System power wiring before Bulletin 2015-07

  6. System power wiring after Bulletin 2015-07

  7. CAN Network Connector – G series, 210, 230  Diacomm and Ecom compatible connector more conveniently located at helm  Same as connector found on engine HELM ENGINE

  8. CAN Network Connector – Ski200 & Sport200 HELM

  9. JL M-Series Studio Elite TOWER SUB BOW, DASH, COCKPIT

  10. JL M-Series Elite TOWER BOW,COCKPIT, SUB

  11. LINC and ButtonPad capacitors  Reduces EMI noise coming from LINC and ButtonPad while engine is running  Not essential to boat operation  Can cause Accessory circuit to trip if capacitor fails  Prevents LINC Touch (G series) from cutting out during engine cranking

  12. LINC TOUCH SHUTS DOWN DURING ENGINE CRANKING  Make sure 1000uF capacitor is plugged in behind LINC display – LINC Touch is sensitive to voltage drop during engine cranking  Not a known issue with non- Touch LINC displays

  13. STEREO WORKS, BUT LINC WON’T BOOT UP  Unplug Black connector, Accessory ON, check for 12v  Hint: Use standard Deutsch DT size 16 pins to make good contact with two Accessory and one Ground pin

  14. Shift Override Button  If Stuck Closed  Engine will crank but transmission won’t shift  Engine remains stuck in neutral  May unplug switch to temporarily operate boat until switch is replaced  If Stuck Open  Blue light ring will not turn ON  Can’t disengage the shifting function to rev the engine

  15. Bulletin 2016-07 G Breaker Panels

  16. Accessory 27 Helm Control PDM 1 Paddlewheel Pin 5 Pressure senders Stereo GPS Relay 3event Dongle PA450UM CMS1 Ballast Heater Switches Switch

  17. Underwater Lights – 2 complaints Dimming every 30 seconds or so, then returning to original brightness 1.  Thermal protection feature that cannot be resolved, except by submersing in the water  When the boat moves above idle speed, they are above the water and are most likely to enter the thermal protection mode. Frequent U/W light circuit faults on LINC 2.  Resolution: 2016 LINC software updates increases underwater lights breaker to 15amps
