Introducing the new Predator 68
New Predator 68
New Predator 68
New Predator 68
New Predator 68
New Predator 68
New Predator 68
New Predator 68
New Predator 68
New Predator 68
New Predator 68
New Predator 68
New Predator 68
New Predator 68 PRINCIPAL FEATURES (PROVISIONAL) PRINCIPAL CHARACTERISTICS Air conditioning Classification CE Hydraulic lifting platform (shaft drive only) Length overall – (incl. pulpit and platform) 21.7M 71’2” Electric winch and capstan at bow with foredeck controls Length waterline 16.42M 53’10” Hot and cold swimming shower at stern Beam – (maximum) 5.09M 16’9” Power-assisted steering Draft – (@ full load incl. props) 1.58M 5’2” DVD/CD/radio in saloon Displacement – (@ half load) 37300kg 82209Ib iPod docking station in saloon Fuel capacity 3500 Litres 770Gal. 925US Gal. Aft cockpit bar unit Fresh-water capacity 800 Litres 176Gal. 211US Gal. Electric refrigerator/freezer Propulsion Twin FP props in tunnels Ceramic hob, microwave/oven Engine options up to 3244ps (total) Electronic depth and speed displays Fuel options Diesel Radar/chart plotter with GPS Generators – standard 1x 17.5kW @ 50Hz 230v single phase (Euro) Autopilot 1x 21.5kW @ 60Hz 120/240v single phase (US) VHF radio with DSC Maximum speed up to 33 knots* Hot and cold water system Cruising speed up to 24 knots* Fresh water pump Range up to 300 nautical miles* Toilet system with holding tank Automatic fire extinguishing system for engine room All principal characteristics and specifications are provisional and subject to final Automatic bilge pumps specification. Slow speed generators with silent exhausts AC shorepower/battery charger Bow thruster Trim tabs Fresh water marina connection Teak decking on the bathing platform and steps Teak decking in the aft cockpit Screen demisters Hard top with Sliding Sunroof All items included in standard specification. Page 1 � Sunseeker New Predator 68 Provisional Specification Issue No.1 September 2012
New Predator 68 1 Construction 4 Aft cockpit Hand-laid GRP Self draining Gel coat including stripes Teak-laid Cockpit Decking Vinylester skin coat with powderbound mat Stern safety door Stitched multi-axial reinforced single skin bottom Cockpit speakers with CD remote Balsa cored hull topsides Wetbar sink with hot and cold water, cool box, ice maker, locker and griddle PVC foam cored deck and superstructure Upholstered seating around cockpit table Hull stiffened with longitudinal stringers supported by transverse bulkheads and floors Large stern sunbather Lockers beneath seating 2 Deck Overhead cockpit lights 24v Fittings all in stainless steel Low-level courtesy lights 24v 8 x stainless steel deck cleats Engine room access hatch Pulpit and cockpit rails Boat hook Stainless steel fendering with rubber insert Curved safety glass windscreen 5 Helm console Stainless steel bow roller with anchor stop Twin helm seats Stainless steel bow plate Navigation console with chart area Delta anchor and 60m chain (galvanised) Hydraulic power steering Electric winch and capstan with deck and Interior helm controls Leather rimmed steering wheel Chain locker/fender stowage Analogue engine instrumentation Fender tie bar under anchor locker lid Chart plotter with GPS Fore deck coach-roof storage lockers Radar open scanner Fuel fillers port and starboard Autopilot Fresh-water filler Speed and depth instramentation IMCO navigation lights VHF radio with DSC 2 x Pantograph windscreen wipers and washers Rudder indicator Garage for tender Water tank gauge Ensign staff and socket Fuel tank gauge Trim tab controls 3 Bathing platform Single lever electronic engine controls Hydraulic lifting platform Magnetic compass Teak-laid bathing platform and steps Waterproof plug and socket 12v Hot and cold swimming shower Horn Fresh-water marina connection Windscreen wipers and washers Dockside AC shore power connection Glass holders Stainless steel swimming ladder Hand-held fire extinguisher Page 2 � Sunseeker New Predator 68 Provisional Specification Issue No.1 September 2012
New Predator 68 6 Deck saloon Overhead bedside cupboards Separate dining area with table Hanging wardrobes with mirrored panel Stowage beneath seats Overhead lights LED 24v 40” Television on fall and rise system 2 x opening portholes with mosquito screens Bluray/DVD/CD cinema sound system Port-light blinds Cupboards Deck hatch with blind and mosquito screen Drinks cupboard Sky-light Overhead halogen lighting LED 24v 2 x Double AC sockets Stainless steel sliding door to cockpit Door to shower room Main control panel (AC/DC) Fitted carpet Generator controls Air Conditioning Air Conditioning 32” television 3 x Double AC sockets DVD/CD player Carpet Choice of interior finishes and veneers 9 Forward en suite shower room Scatter cushions Washbasin Taps and accessories 7 Galley Hot and cold water supply Sink and drainer Separate shower compartment 4 ring ceramic hob and extractor fan Electric toilet Electric refrigerator Extractor fan Electric freezer Mirrored vanity unit Microwave convection oven Shelved cupboard Hot and cold water Toothbrush and glass holder Rubbish bin Soap dispenser Cupboard and drawer storage Towel ring and towels 8 place crockery set Overhead lights 8 place cutlery set Opening porthole with mosquito screen and blind 2 x Double AC sockets Razor socket 240/110v Hand-held fire extinguisher First aid kit 8 Forward stateroom Double berth Storage beneath Drawer in base-end 2 x reading lights 24v Outboard shelving and cupboards Page 3 � Sunseeker New Predator 68 Provisional Specification Issue No.1 September 2012
New Predator 68 10 Starboard guest cabin Door to shower room 2 x single berths Fitted carpet Under berth storage Settee 2 x reading lights 24v Air Conditioning Hanging wardrobe 32” television Overhead lighting LED 24v DVD/CD player Opening porthole with mosquito screen and blinds Double AC socket 13 Aft en suite shower room Fitted carpet Washbasin Air Conditioning Taps and accessories 19” television Hot and cold water supply DVD/CD player Separate shower compartment Electric toilet 11 Starboard en suite shower room Extractor fan Washbasin Mirrored vanity unit Taps and accessories Shelved cupboard Hot and cold water supply Toothbrush and glass holder Separate shower compartment Soap dispenser Electric toilet Towel ring and towels Extractor fan Overhead lights LED Mirrored vanity unit Opening porthole with mosquito screen and blind Shelved cupboard Razor socket 240/110v Toothbrush and glass holder Soap dispenser 14 Electrical system Towel ring and towels 17.5kw 50hz generator with underwater silent exhaust and sound shield Overhead lights LED AC dockside connection Opening porthole with mosquito screen and blind Galvanic isolator Razor socket 240/110v 24v and 12v DC electrical system with full circuit breaker protection 6 x engine batteries 24v circuit 12 Master aft stateroom 4 x domestic batteries 24v circuit Double berth 2 x generator batteries 12v circuit Cupboard and drawer stowage Alternator split charging system 2 x reading lights 24v Remote battery switches controlled from locker in cockpit Bedside drawers Battery charger for 24v circuits Walk-in wardrobe Battery charger for 12v circuits Overhead lights LED 24v Water heater 2 x large windows with opening portholes, mosquito screens and blinds AC electrical sockets through out the boat Two Double AC sockets 24v hand light and cable Page 4 � Sunseeker New Predator 68 Provisional Specification Issue No.1 September 2012
