Zipcart Team 26: Ryan Lagasse, Ricardo Henriquez, Jonathan Azevedo - PowerPoint PPT Presentation

Oct 24, 2022 •319 likes •612 views

Zipcart Team 26: Ryan Lagasse, Ricardo Henriquez, Jonathan Azevedo Team Ryan Lagasse Ricardo Henriquez Jonathan Azevedo Computer Systems Electrical Computer Systems 2 Motivation 3 Universal Product Codes (UPCs) Unique, twelve-digit

  1. Zipcart Team 26: Ryan Lagasse, Ricardo Henriquez, Jonathan Azevedo

  2. Team Ryan Lagasse Ricardo Henriquez Jonathan Azevedo Computer Systems Electrical Computer Systems 2

  3. Motivation 3

  4. Universal Product Codes (UPCs) • Unique, twelve-digit numbers that identify items • Barcodes are machine-readable Digits Code 1 – 6 Manufacturer ID 7 – 11 Item ID 12 Check Digit 4

  5. Reading UPCs with Computer Vision 5

  6. Challenges • Read moving barcodes at unpredictable angles • Operate at the embedded scale • Done in a way that comes natural to shoppers 6

  7. Requirements 1. Recognize barcode as item is placed in cart 2. Detect when item is removed from cart 3. Display item list and current balance 4. Detect an unscanned item to prevent theft 5. Sustain power for a full business day 7

  8. Specifications 1. 18 hours of continuous operation 2. One item entered/removed per two-second interval 3. Barcode surface must be reasonably flat 4. Maximum system latency: four seconds 8

  9. Competitors 9

  10. Design Alternatives • Barcode Scanner • Multiple Cameras • Dedicated Display Terminal 10

  11. Our Approach Mirror Mirror Mirror • Single camera mounted to cart Mirrors used see around product • • Cloud services Intermediary between system and application • • Android smartphone application Display item list and current balance • 11

  12. Block Diagram Cloud Database Cloud Endpoint • Product DB/Cache Optics System • Item Register UPC Detection System Mirror Feed Microprocessor UPC Info Camera VDD Feedback System Power Supply Smartphone LED Strip DC Motor Application Regulator Payment Li-ion Battery 12

  13. Block Diagram Cloud Database Cloud Endpoint • Product DB/Cache Optics System • Item Register UPC Detection System Mirror Feed Microprocessor UPC Info Camera VDD Feedback System Power Supply Smartphone LED Strip DC Motor Application Regulator Payment Li-ion Battery 13

  14. Optics System Front Mirror Mirror Mirror Left Front Right Back Cart, Top-Down Perspective 14

  15. Detection System Cloud Database Cloud Endpoint • Product DB/Cache • Product DB/Cache • Item Register • Item Register UPC Optics System Detection System Mirror Image Microprocessor Call Data Camera VDD Power Supply Feedback System Smartphone DC Motor LED Strip Application Regulator Payment Li-ion Battery 15

  16. Detection System • Computer Vision algorithm • Read UPCs from barcodes • Network interface POST /cloud/order/3214 HTTP/1.1 Barcode: 07314916939 POST /cloud/order/3214 HTTP/1.1 Barcode: 07314916939 DELETE /cloud/order/3214 HTTP/1.1 Barcode: 07314916939 • Send UPC, action to cloud • Small, embedded platform 16

  17. Feedback System Cloud Database Cloud Endpoint • Product DB/Cache • Item Register UPC Optics System Detection System Mirror Feed Microprocessor Call Data Camera VDD Feedback System Power Supply Smartphone LED Strip DC Motor Application Regulator Circuit Payment Li-ion Battery 17

  18. Feedback System • Intent is to differentiate a good scan from a bad one • LED strip along inner edge of cart • Green = good scan • Red = bad scan 18

  19. Power Supply Cloud Database Cloud Endpoint • Product DB/Cache • Item Register UPC Optics System Detection System Mirror Image Microprocessor Call Data Camera VDD Feedback System Power Supply Smartphone LED Strip DC Motor Application Regulator Circuit Payment Li-ion Battery 19

  20. Power Supply Self-sufficient to avoid charging • DC Motor to generate power mechanically • Brushed DC Motors typically 75-80% efficient • Regulator circuit to produce constant and stabilized voltage • 20

  21. Cloud Platform Cloud Database • Product DB/Cache • Item Register UPC Optics System Detection System Mirror Feed Microprocessor Call Data Camera VDD Feedback System Power Supply Smartphone LED Strip DC Motor Application Regulator Circuit Payment Li-ion Battery 21

  22. Cloud Platform • Track orders with database • Manage product information • Request from UPC API • Cache results in local database 22

  23. GET api.barcodelookup.com/{…} HTTP/1.1 Response: UPC: 073149169396 Product: Sterilite File Crate Price: 5.97 USD 23

  24. User Interface Cloud Database Cloud Endpoint • Product DB/Cache • Product DB/Cache • Item Register • Item Register Optics System UPC Detection System Mirror Feed Microprocessor Call Data Camera VDD Feedback System Power Supply Smartphone LED Strip DC Motor Application Regulator Circuit Payment Li-ion Battery 24

  25. User Interface • Display item register, balance • Enables a path to payment implementation • i.e. Samsung Pay, Venmo 25

  26. Schedule of Work 10/1 10/8 10/15 10/22 10/29 11/5 11/12 11/19 11/26 12/3 12/10 12/17 12/24 Benchside #1 Detection Install OpenCV Barcode Detection(Still Photo) Barcode Detection(Video Feed) UPC Recognition UPC Lookup Add Items to Cart Balance Remove Items from Cart Balance Detect Missed Items Power Planning DC Motor Regulator Circuit Booster Circuit Battery Protection Circuit Li-ion Battery PDR Benchside #2 MDR Thanksgiving Break Feedback System Integration Order Tracking Theft Detection App Interface, Android Website Shopping Cart Install LEDs Mount Camera Install Mirrors Calibration 26

  27. Bill of Materials  Raspberry Pi  DC Motor(s)  Camera  VRUZEND Battery Kit  Intel Movidius Visual Compute Stick  Li-ion Battery Cells  Android Phone  PCB  Shopping Cart  RGB LED Strip  Mirrors 27

  28. MDR Deliverables • Detect barcode around 180° of camera perspective • Successful integration of feedback system • Update cloud database with product information • Show power generation using DC Motor 28

  29. Zipcart Team 26: Ryan Lagasse, Ricardo Henriquez, Jonathan Azevedo
