WITH GIS B R E T T M I L B U R N , G I S P T O N Y Y A T E S , - PowerPoint PPT Presentation

Aug 17, 2023 •138 likes •450 views

RD PARTY APPS INTEGRATING 3 RD WITH GIS B R E T T M I L B U R N , G I S P T O N Y Y A T E S , G I S P PRESENTATION OVERVIEW Overview of Langan Case Studies Greater New Haven Water Pollution Control Authority South Whitehall

  1. RD PARTY APPS INTEGRATING 3 RD WITH GIS B R E T T M I L B U R N , G I S P T O N Y Y A T E S , G I S P

  2. PRESENTATION OVERVIEW • Overview of Langan • Case Studies • Greater New Haven Water Pollution Control Authority • South Whitehall Township • Lessons Learned 2

  3. ABOUT LANGAN • Founded in 1970 • 1,100 Employees • 33 Office World Wide • 5 Offices in Florida • Miami • Orlando • Fort Lauderdale • Tampa • West Palm Beach 3

  4. OVERVIEW OF LANGAN SERVICES MARKETS Federal & Public Works Site/Civil Engineering Energy & Utilities Geotechnical Engineering Infrastructure Colleges & Universities Environmental Engineering K-12 Schools Data Management & Hospitals & Healthcare Mixed-Use Commercial Visualization Residential / Affordable Housing 3D Scanning/BIM Resorts, Hospitality & Casinos Stadiums / Arenas Natural Resources & Permitting Industrial, Manufacturing & Earthquake Engineering Warehouse Mission Critical & Datacenters Geology/Engineering Geology Pharmaceutical Sustainable Site Design Waterfront & Marine 4

  5. GREATER NEW HAVEN WATER POLLUTION CONTROL AUTHORITY NEW HAVEN, CT

  6. CLIENT OVERVIEW G r e a t e r N e w H a v e n W a t e r Hamden P o l l u t i o n C o n t r o l A u t h o r i t y POPULATION 60,960 • Four Member Communities • 555 Miles of Sewer Pipes Woodbridge • 30 Pump Stations POPULATION 8,890 • East Shore Treatment Plant • 29 MGD – Average Daily Flow New Haven • 40 MGD – Design Flow - Secondary Treatment POPULATION 130,282 East Haven • 100 MGD – Wet Weather Flow Primary POPULATION 29,257 Treatment CUSTOMERS 47,912 6

  7. HISTORY OF GIS USE • Long history of using GIS but in limited capacity • Langan awarded multi-year contract to perform updates from constant stream of paper as-builts • Identified additional pain points with manhole inspections • Implemented full enterprise GIS • Migrated and developed series of COTS viewers • Needed more………. 7

  8. MANHOLE INSPECTIONS F I E L D I N S P E C T I O N S 8

  9. MANHOLE INSPECTIONS • Need to include inspections results in GIS • Pull data from associated features • Work on all devices (iOS, Android, Windows) • Accessible for contractors 9

  10. GRANITE XP C C T V I N S P E C T I O N S 10

  11. SEWER CCTV INSPECTIONS • Already had GraniteXP in place • Catalog inspection videos • Easily viewable • Daily downloads from truck to office 11

  12. PELICAN TICKET ACCESS AU TOM ATING 8 1 1 C AL L S 12

  13. CALL BEFORE YOU DIG (CBYD) • Need to respond to numerous requests • Automated reports and maps • Integrate with web services from Enterprise • Classify assets as critical 13

  14. REGULATORY REPORTING EQuIS ™ is the most widely used environmental data management software and primarily used for managing environmental and “other” sample data. • Automated reporting • Interfaces with an extensive list of 3 rd party software including Esri GIS • Document management 14

  15. SENSOR IN INTEGRATION • Telemetry and sensor data retrieval • Automated data upload • Incorporate regulatory requirements / formats • Screening information against custom / regulatory criteria • Mobile data collection solution 15

  16. SOUTH WHIT ITEHALL TOWNSHIP IP South Whitehall Township, PA

  17. CLIENT OVERVIEW S o u t h W h i t e h a l l T o w n s h i p • Located 1 Hour North of Philadelphia and 1.5 Hours from New York City • Approximately 17 Square Miles • Over 18,000 Residents and Growing • Over 100 Miles of Sewer and Water Pipe • Half the Township on Public System • 6 Well Production Stations • Over 3.5 Million Gallons of Storage Capacity 17

  18. HISTORY OF GIS USE • Langan initially contracted with Public Works • Negotiated software • Implemented full enterprise GIS • Data Conversion / Digitization • Developed series of apps • MS4 • Fire Hydrant • Fire Department • Grease Inspections • Identified 3 rd party software that filled gaps • Other Departments Bought In 18

  19. MOBILE APPLICATIONS U T I L I T Y E N G I N E E R I N G D E P A R T M E N T 19

  20. MOBILE APPLICATIONS • MS4 requirements • Stormwater collection with Trimble R2 & Collector • BMP inspections • Hydrant flushing 20

  21. GRANITE XP 21

  22. SEWER CCTV INSPECTIONS • Worked with CUES to design architecture • Updated database to match CUES needs • Created SOP for daily data transfers 22

  23. HURCO VA VALVE EXERCISER 23

  24. AUTOMATED VALVE EXERCISING • Internal GPS • Automatic turn counts • Daily download from truck to office 24

  25. VERIZON NETWORK FLEET R E A L - T I M E V E H I C L E T R A C K I N G 25

  26. FLEET TRACKING • GPS on all trucks • 15-second breadcrumbs • 20-minute delay for public • Manual override available 26

  27. MUNIS FINANCE C U S T O M E R B I L L I N G I N F O Langan worked with Tyler Technologies to integrate Munis … 27

  28. CUSTOMER BILLINGS • Linked properties through PIN • Integrated mapping interface • New SOP for proposed & multi-unit properties • Replaced outdated system 28

  29. • Evaluate other products and the potential ROI LESSONS LEARNED • Be flexible in designing solutions for change & & BENFITS • Involve the right people………don’t rely solely on the software manufacturers and evaluate outside help who may have direct experience • Communication!! 29

  30. THANK YOU B R E T T M I L B U R N , G I S P b m i l b u r n @l a n ga n . co m TO N Y YAT ES , G I S P t yate s @ l a n ga n . co m W W W . L A N G A N . C O M
