US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge Pre-Bid Meeting February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Key Project Personnel Kyle Poat • Darrin Beckett • D-1 Chief District Engineer Chris Kuntz Geotechnical Branch • Danny Peake • D-1 Project Development Brad Whybark Division of Env Analysis • Cassondra Cruikshank • D-1 Environmental Mike Shuecraft Division of Env Analysis • Tony Hunley • D-1 Utilities Jason Looper Stantec Project Manager • Taylor Perkins • Project Delivery Austin Hart • Stantec Deputy PM Smithland Section Supervisor February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Agenda Project Overview • Roadway Approaches • Utilities • Existing Bridge • River Bridge • Geotechnical & Foundations • Environmental Commitments • DBE Requirements • Schedule • February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Project Overview: Vicinity Map February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Project Overview: Existing Bridge Aerial February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Project Overview: Bridge Rendering February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Project Overview: Roll Plot February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Project Overview: Fly-Thru Video February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Procurement: Special Notes General Environmental Completion Date Mitigation of Impacts to Cumberland River (Mussels) • • CPM Scheduling Mitigation of Impacts to Osprey • • Web Camera Construction Monitoring System Pending US Army Corps of Engineers 404 Permit • • Provision of Compression Testing Machine Tree Removal • • Automated Gate Construction Activities • • Existing Bridge Bridge Demolition, Renovation, and Asbestos • Abatement Maintaining Existing Bridge • eNOI for KPDES Construction Stormwater Permit • Milestone Completion Date & Liquidated Damages • on Existing Bridge Repairs Geotechnical Traffic Control on Bridge Repair Contracts Project Specific Drilled Shaft Requirements • • Concrete Patching Repair Cone Penetration Test Data • • Structures with Fiber Reinforced Polymer Wrap Non-destructive Testing of Drilled Shafts • • Structures Pile Dynamic Testing • USCG Section 9 Permit Instrumentation on Existing Bridge • • Steel Paint Color Utility Relocation • Steel Erection Earth Moving • • Structure Lightning Protection Municipal Water Distribution • • Disc Bearings Municipal Sanitary Sewers • • Roadway Class 1A Geotextile Fabrics Used in Structural Pavement • Designs Concrete Slurry • Pipeline Inspection • February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Roadway: South Approach February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Roadway: North Approach February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Roadway: • South Approach Waste • North Approach Embankment • Existing Bridge Weight Restrictions February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Utilities: Waterline Relocation • Smithland Water Works – Water & Sewer Line Relocations • Crittenden-Livingston County Water District – Water Line Relocation • 2,599 LF PVC February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Utilities: Relocation Status • Jackson Purchase Energy Corporation – 4/30/20 • Windstream dba Kentucky Data Link – During construction February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Existing Bridge: Immediate Repairs February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Existing Bridge: Immediate Repairs February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Existing Bridge: Maintenance Bid Item $500,000 Bid Budget February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Bridge: Layout February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Bridge: South Approach Spans February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Bridge: North Approach Spans February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Bridge: Approach Substructures February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Bridge: Main Span Layout February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Bridge: Truss Typical Dimensions February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Bridge: Main Span Pier Types February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Bridge: Bridge Bearings February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Bridge: Steel Fabrication Notes • H & Box Section Truss Members • Bolts (ASTM F3125) Grade A325 Typical UNO � – � Grade A490 Gussets & Other Connections – � � • Structural Steel – Grade 50W Typical Typical – Grade HPS 70W Gusset Plates (2 ½” Max Thickness) • Paint – Kentucky Blue (Federal Standard 595B Color X5095) February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Bridge: Erection – Staging Area February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Geotech: • Overview of Subsurface Conditions & Foundations • Foundation-Related Special Notes • Drilled Shaft Considerations & Requirements • Non-Destructive Testing of Drilled Shafts • Dynamic Pile Testing • Instrumentation on Existing Bridge • Construct North Embankment ASAP February 28, 2020 February 28, 2020
US 60 Cumberland River Bridge – Pre-Bid Meeting Geotech: Overview of Subsurface Conditions & Foundations All Foundations Bear on Bedrock Piers 3 & 4 Drilled Shafts (8 Per Pier) 8.0 ft. dia. Perm. Casing • Piers 5 - 9 7.5 ft. dia. Rock Sockets • Pier 2 Abut 1 & Pier 1 Abut 2 Open-Ended Pipe Piles Pier 3 - Foundation Preparation (LS) HP 14x89 Spread Footings HP 14x89 • 30-inch diameter Pier 4 - Cofferdam (LS) Max. Reg. Flood Elev. = 345.0 ft. Approx. Rock Line Normal Pool Elev. = 302.0 ft. South Side of River Approx. Rock Line North Side of River ≈ 6 to 62 ft. Lean Clay w/ some Sand & Gravel ≈ 95 to 130 ft. Lean Clay & Sand ≈ 4 ft. thick Sandstone Boulder Encountered at P1 29 Hard Sandstone Bedrock (Shale Encountered at P8, P9, A2) February 28, 2020 Soft Shale Bedrock (Sandstone Encountered at A1 )
US 60 Cumberland River Bridge – Pre-Bid Meeting US 60 Cumberland River Bridge – Pre-Bid Meeting Geotech: Special Notes Applicable to Foundations • Drilled Shafts (11C) o “Standard Special Note” Posted on Division of Construction Website • Project Specific Drilled Shaft Requirements o Supplemental & Controls over Special Note for Drilled Shafts (11C) • Non-Destructive Testing of Drilled Shafts • Pile Dynamic Testing • Cone Penetration Test Data o For Information Only (No Work Specified) • Instrumentation on Existing Bridge • Completion Date o Not exclusive to foundations but addresses high water February 28, 2020 February 28, 2020
