To deliver safety performance and retain combat readiness of federal police servicemen and special forces from stab, gunshot and shrapnel injury in line with counter‐terrorism.

 IST RAN has supplied over 70.000 vests to various units of law enforcement agencies in Russia (Ministry of Interior, Federal Security Service, National Guard) throughout the past 15 years  Since 2012, a fundamentally new generation of body armor has been developed by in‐house ballistic experts and scientists, specializing in composite materials  The new generation product line “IST” offers unrivaled safety performance that allows servicemen to retain full combat readiness even after being stricken by gunshot and shrapnel.

 Large area of level IIIa protection  Lightweight structure allows for functional NIJ IV armour  Very low back‐face signature according to NIJ testing

 IST RAN bulletproof vests are certified by the national certification system in all classes of protection according to GOST 34286‐2017 and tested in accordance with NIJ Ballistic Resistance 0101.06 and NIJ Stab Resistance 0115.00.  In addition to national certification, tests imitating real‐life shrapnel and blunt force trauma were carried out.  All testing accounted for following quality indicators:  Protection against bullet and knife penetration;  Protection from the real pieces of field ordnance (shrapnel);  Protection from blunt force trauma;  5 year product warranty;  Ergonomic performance.

Virtually all ballistic vests standards regulate the following key parameters: 1. Non‐penetration of the projectile, i.e. ballistic resistance 2. Back‐face signature (BFS) generated by the projectile, measured in mm, which determines the severity of the injury after blunt‐force trauma, affecting combat capability and the need for hospital admittance of the victim. All standards have zero‐tolerance for penetration from several shots, as it is the main protection parameter. The back‐face signature however, is treated differently: the most widely accepted standard for ballistic protection is the U.S. NIJ, which allows for a 44mm BFS, yet German technical regulations allow for 18‐22mm. Fig.1: BFS in competitor vests vs. IST vest

US NIJ 0101.06 Germany VPAM BSW 2006

NIJ IIIa NIJ III NIJ IV 9 mm FMJ 7,62x39 AP .30 M2 AP 0,44 Magnum 7,62x51 FMJ NATO M80 BALL 7,62x54mm AP Armour type SAP SAP+HAP SAP+HAP Weight of ballistic 2,2 6,2 7,0 package, kg Protection area (size L), 42 – soft 42 – soft 42 – soft dm2 15 – hard, front+back 15 – hard, front+back Back‐face signature, mm <8 0 0 Comments Resistant to fragments of grenade, mines and projectiles. Note: in‐depth research on BFS and related trauma was conducted using results from animal carcasses SAP – Soft Armour Protection HAP – Hard Armour Protection

 IST vests are designed with real‐life duty conditions in mind which means resistance to actual shrapnel, low weight and protection from blunt‐force trauma.  Official standards offer only shrapnel tests with ball‐style fragments weighing 1,05g 6,35mm in diameter, which are not representative of the real scenarios  IST RAN conducted voluntary tests in the field to simulate striking by elements of size 10‐15mm from anti‐personnel mines PM‐4, hand grenades PGN, RGO, under‐barrel grenades VOG‐17, VOG‐25, mortar fire with high‐explosive fragmenting ammo of caliber 82‐120mm and artillery ammo of caliber 76,2‐ 122mm  Excellent result were achieved – non‐penetration of the vest

NIJ level IIIa ‐ SAP Complete level IIIa protection with: • Thoracic section; • Dorsal section with extensions; • Side sections; • Size adjustment with Velcro fasteners • Possibility of belt insert Protection area: SAP 42 dm² (size L) Weight of ballistic package: 2.2 kg Covert SAP vest Overt SAP vest NIJ level III – SAP + HAP Combined level III protection with: • Thoracic section; • Dorsal section with extensions; • Side sections; • Two ceramic plates, front and back • Anti‐traumatic dampening layer • Size adjustment with velcro fasteners • Possibility of belt insert Protection area: SAP 42 dm² (size L) + HAP 15 dm² Weight of ballistic package: 6.2 kg SAP vest HAP insert

NIJ level IV – SAP + HAP Combined level IV protection with: • Thoracic section; • Dorsal section with extensions; • Side sections; • Two ceramic plates, front and back • Anti‐traumatic dampening layer • Size adjustment with velcro fasteners • Possibility of belt insert Protection area: SAP 42 dm² (size L) + HAP 15 dm² Weight of ballistic package: 7.0 kg Overt SAP vest HAP insert Note: • All sales are made in accordance with regulations of Russian Federation, including export laws • Ballistic carrier to be made according to specific client requirements (mole system/pockets/velcro) with weights starting from 1kg.

Several variants exist: 1. Outer wear 2. Covert wear 3. Extended protection 4. SAP only or SAP+HAP 5. HAP Helmets
