TAKOMA PARK MIDDLE SCHOOL Montgomery County Public Schools - PowerPoint PPT Presentation

TAKOMA PARK MIDDLE SCHOOL Montgomery County Public Schools Facility Advisory Group Meeting #1 September 10, 2015 -- 7:00pm TAKOMA PARK MIDDLE SCHOOL Schedule Feasibility Study Meeting #1 September 10, 2015, 7:00pm Meeting #2


  1. TAKOMA PARK MIDDLE SCHOOL Montgomery County Public Schools Facility Advisory Group Meeting #1 September 10, 2015 -- 7:00pm

  2. TAKOMA PARK MIDDLE SCHOOL Schedule Feasibility Study • Meeting #1 – September 10, 2015, 7:00pm • Meeting #2 – September 16, 2015, 3:20pm • PTA Presentation – October 13, 2015, 7:00 pm 2

  3. TAKOMA PARK MIDDLE SCHOOL Objectives / Considerations • Addition Location • Program & Site Adjacencies • Student Circulation • Access to Fields & Paved Play Areas  Community use of site • Maintain Natural Light • Sustainability • 21 st Century Learning 3

  4. TAKOMA PARK MIDDLE SCHOOL Program Analysis 4

  5. TAKOMA PARK MIDDLE SCHOOL Existing Site N 5

  6. TAKOMA PARK MIDDLE SCHOOL Existing Site Fields & Play Areas N 6

  7. TAKOMA PARK MIDDLE SCHOOL Existing Site Parking N 7

  8. TAKOMA PARK MIDDLE SCHOOL Existing Site Public vs. Private N 8

  9. TAKOMA PARK MIDDLE SCHOOL Existing Site Analysis W E N S 9

  10. TAKOMA PARK MIDDLE SCHOOL Existing Public vs. Private Main Street Private Public N 10

  11. TAKOMA PARK MIDDLE SCHOOL Existing Horizontal Circulation Main Street Private Public N 11

  12. TAKOMA PARK MIDDLE SCHOOL Existing Horizontal and Vertical Circulation Main Street Private Public N 12

  13. TAKOMA PARK MIDDLE SCHOOL Existing 1 st Floor Plan boys aux art cr lockers gym cr cr cr cr cr cr home cr girls econ gym lab lockers esol p p lab lab dance guidance admin cr cr cr cr music cafeteria gh main entrance N 13

  14. TAKOMA PARK MIDDLE SCHOOL Existing 2 nd Floor Plan cr cr cr media cr center lab p p cr lab lab cr cr cr cr N 14

  15. TAKOMA PARK MIDDLE SCHOOL Existing 3 rd Floor Plan cr cr cr cr cr lab mech p p cr lab lab cr cr cr cr N 15

  16. TAKOMA PARK MIDDLE SCHOOL Existing Site Layout N 16

  17. TAKOMA PARK MIDDLE SCHOOL Potential Addition Areas Four Potential Addition Areas 2 3 4 1 N 17

  18. TAKOMA PARK MIDDLE SCHOOL Potential Addition Areas Four Potential Addition Areas Area 1 – East of Building Adjacent to programs o requiring additional program (gym, cafeteria, performing arts) Sufficient area o Ability to tie into existing o corridors Located on blacktop o used by community 1 N 18

  19. TAKOMA PARK MIDDLE SCHOOL Potential Addition Areas Four Potential Addition Areas Area 2 – North Side of Building Sufficient area for o construction Room to plan for future o expansion Adjacent to main o 2 academic area Ability to tie into existing o corridors Sloping terrain o Impacts existing o amphitheater N 19

  20. TAKOMA PARK MIDDLE SCHOOL Potential Addition Areas Four Potential Addition Areas Area 3 – Along Piney Branch Rd. Adjacent to existing science o laboratories Not adjacent to existing o corridors Adjacent to street o Very small area o Would require additional 3 o academic expansion area Interrupts site o circulation N 20

  21. TAKOMA PARK MIDDLE SCHOOL Potential Addition Areas Four Potential Addition Areas Area 4 – Front of School Adjacent to programs requiring o additional square footage (administration, guidance, general academics) Provide a new o building front Too close to existing bus o loop Very small area o Would require o 4 additional academic expansion area Would require o significant interior renovation N 21

  22. TAKOMA PARK MIDDLE SCHOOL Concepts 22

  23. TAKOMA PARK MIDDLE SCHOOL Music, Physical Ed. & Building Services Addition Area to relocate hardtop/basketball courts 4 PE/Music Addition N 23

  24. TAKOMA PARK MIDDLE SCHOOL Music, Physical Ed. & Building Services Addition - addition - renovation boys boys st aux aux aux lockers lockers t fitness gym gym gym icb health girls girls cr gym gym lockers lockers bsf st st dance stage dance music music cafeteria stage cafeteria N Existing Partial 1 st Floor Plan Proposed Floor Plan 24

  25. TAKOMA PARK MIDDLE SCHOOL Existing Site Layout N 25

  26. TAKOMA PARK MIDDLE SCHOOL Concept 1 Layout Academic Addition PE/Music Addition N 26

  27. CONCEPT 1 Renovation / Repurpose Areas - renovation boys aux art cr lockers gym cr cr cr cr cr cr home cr girls econ gym lab lockers esol p p cr lab st dance guidance admin cr cr cr cr cafeteria stage N 27

  28. CONCEPT 1 1 st Floor Plan cr cr cr boys st cr aux aux s art cr lockers t fitness gym gym mp admin icb lab cr cr health cr cr p home t cr girls cr econ gym lab lockers esol bsf p p cr lab st dance guidance admin music cr cr cr cr cafeteria stage N 28

  29. CONCEPT 1 2 ND Floor Plan cr cr cr cr s lab res cr media cr p t center lab p p cr lab lab cr cr cr cr N 29

  30. CONCEPT 1 3 RD Floor Plan esol cr cr cr s lab cr sp cr cr p t ed lab mech p p cr lab lab cr cr cr cr N 30

  31. CONCEPT 1 Circulation cr cr cr boys st cr aux aux s art cr lockers t gym fitness gym mp admin icb lab cr cr health cr cr p home t cr girls cr econ gym lab lockers esol bsf p p cr lab st dance guidance admin music cr cr cr cr cafeteria stage N 31

  32. TAKOMA PARK MIDDLE SCHOOL Existing Site Layout N 32

  33. TAKOMA PARK MIDDLE SCHOOL Concept 2 Layout Academic Addition PE/Music Addition N 33

  34. CONCEPT 2 Renovation / Repurpose Areas - renovation - renovation (1 st floor only) boys aux art cr lockers gym cr cr cr cr cr cr home cr girls econ gym lab lockers esol p p lab lab st dance guid admin cr cr cr cr cafeteria stage N 34

  35. CONCEPT 2 1 st Floor Plan s cr cr cr t res boys st aux aux art cr lockers t gym fitness gym mp icb lab cr admn admn cr health cr cr p home cr girls cr econ gym lab lockers esol bsf p p lab lab st dance guid admin music cr cr cr cr cafeteria stage N 35

  36. CONCEPT 2 2 nd Floor Plan s cr cr cr t cr lab cr cr media cr p center lab p p cr lab lab cr cr cr cr N 36

  37. CONCEPT 2 3 rd Floor Plan s cr cr cr t esol lab sp cr cr cr p ed lab mech p p cr lab lab cr cr cr cr N 37

  38. CONCEPT 2 Circulation s cr cr cr t res boys st aux aux art cr lockers t gym fitness gym mp icb lab cr admn cr health cr cr p home cr girls cr econ gym lab lockers esol bsf p p cr lab st dance guid admin music cr cr cr cr cafeteria stage N 38

  39. CONCEPT 1 Future Expansion Area For Future Addition 3 stories – 12 classrooms (single • loaded corridor) N 39

  40. CONCEPT 2 Future Expansion Area For Future Addition 3 stories – 12 Classrooms • N 40

  41. TAKOMA PARK MIDDLE SCHOOL Concept 1 - Pros and Cons Concept 1 Renovated Square Footage – 15,190 sf Addition Square Footage – 27,500 sf Efficiency Factor – 78.1 % • Pros Efficient double loaded corridor Compact floor plan Minimal site impact Natural light in all spaces Views to exterior (vs. courtyard) in all spaces • Cons Corridor dead ends into stair More demolition of existing classrooms (6 total) PE/Music Addition Academic Addition 41

  42. TAKOMA PARK MIDDLE SCHOOL Concept 2 - Pros and Cons Concept 2 Renovated Square Footage – 13,285 sf Addition Square Footage – 30,808 sf Efficiency Factor – 69.7 % • Pros Loop corridor improves circulation Forms courtyard for outdoor teaching area Natural light in all spaces Less demolition of existing classrooms (4 total) • Cons Single loaded corridor is inefficient (cost) Forms courtyard requiring maintenance Some classrooms have courtyard views PE/Music Addition Academic Addition 42

  43. TAKOMA PARK MIDDLE SCHOOL Project Schedule Feasibility Study • Meeting #1 – September 10, 2015, 7:00pm • Meeting #2 – September 16, 2015, 3:20pm • PTA Presentation – October 13, 2015, 7:00 pm 43

  44. TAKOMA PARK MIDDLE SCHOOL Questions / Comments WE WELCOME AND APPRECIATE YOUR FEEDBACK! This process is oriented around the collaboration of all involved. Please feel free to ask us questions. 44
