SCE EVO CRIMPING MACHINES www.manuli-hydraulics.com Control panels - PowerPoint PPT Presentation

SCE EVO CRIMPING MACHINES www.manuli-hydraulics.com Control panels EVO and adjustable crimpers are available with 3 different control panels: SMART CONTROL (SC) SMART CONTROL ELECTRONIC (SCE) SAFE CRIMP SYSTEM (SCS) SCS SC SCE


  1. SCE EVO CRIMPING MACHINES www.manuli-hydraulics.com

  2. Control panels EVO and adjustable crimpers are available with 3 different control panels: • SMART CONTROL (SC) • SMART CONTROL ELECTRONIC (SCE) • SAFE CRIMP SYSTEM (SCS) SCS SC SCE Growing functionalities and embedded expertise

  3. Control panels Growing functionalities and embedded expertise CRIMPING FUNCTIONS SC SCE SCS NOTES DIGITAL SETTINGS ü ü ü ELECTRONIC SET STOP ü ü ü AUTOMATED OPENING C0NTROL ü ü ü MAINTENANCE IDENTIFICATION WITH PASSWORD ü ü ü EMBEDDED DIE SET CHART ü ü ü ON LINE CONNECTION TO THE CRIMPING CHART ü ü Not necessary in SCS TOUCH SCREEN ü ü EDITABLE DIE SET CHART ü ü RECURRENT ASSEMBLIES BOM SAVING ü (max 25) ü CALIPER CONNECTION FOR MACHINE SETTING ü "SPECIAL DIE SETS" CHART ü EMBEDDED CRIMPING CHART ü Advantage in unconnected areas EMBEDDED FERRULE REBOUND CALIBRATION ü CUSTOMIZED CRIMPING SEQUENCE ü OPERATOR/SUPERVISOR IDENTIFICATION ü QUALITY CHECK THROUGH HEAD PRESSURE ü Mistake proofing AUTOMATED MEASURE OF CRIMPING DIAMETER ü Mistake proofing QUANTITY COUNT TO PREVENT UNCRIMED FERRULES ü Mistake proofing CRIMPING BY STEPS (FOR TUBING AND THERMOPLASTIC) ü

  4. SMART CONTROL ELECTRONIC (SCE) Advantages compared to SC: ü Touch screen (easy interface) ü Editable die set chart (embedded chart) ü Recurrent assemblies BOM saving (25 max, very useful for personalization, user friendly & time saving) ü Caliper connection for machine setting & process control (in favor of safety and process reliability)

  5. WHY SCE? Customer Advantages: § MISTAKE PROOF § CRIMPING DATA UPDATE TO LAST RELEASE OF CRIMPING APP § SAFE SETUP USING CALIPER CONNECTION § EASY/FRIENDLY USAGE TIME SAVING SOLUTION § § COST EFFECTIVE SOLUTION
