PTP CUSTOM LED LIGHTING WIRING SYSTEM
FEATURES • Th The PT PTP Control En Enclosure come mes pr pre-wi wired and ready for installa in llatio ion. • Th The LED light fixt xture power supplies an and d the requ quired d lig lightin ing control l co components (photoce cell, occu ccupancy cy se senso sor, control relay, etc.) ar are in installe lled and pre-wi wired in the en enclosure. e. • Ca Cat 5 ports are installed in in the the to top of of the en enclosure e to co connect ct the enclosure en e to the the lighti hting ng contr ntrol sy syst stem. • Th The PTP TP Control En Enclosure is ET ETL appr approved d an and d man anufac actured d in the US USA. • De Designed specifically for Lithonia™ lig lightin ing fix ixtures.
FEATURES CONTINUED • LED light fixture power supplies and line voltage wiring separated from low voltage control section by removable metal covers. • The PTP Enclosure has a hinged and latched door that swings down to access the low voltage control components and the line voltage covers.
TRADITIONAL LED LIGHTING WIRING The traditional method for wiring room lighting involves various conduit runs, junction boxes, and fixture whips. The lighting control components are located somewhere above the ceiling in junction boxes.
PTP CUSTOM LED LIGHTING WIRING SYSTEM The PTP Custom LED Lighting Wiring System needs only one conduit run and junction box per room for normal power. The lighting control components are contained in the PTP Enclosure and accessible from below the ceiling.
BENEFITS FOR INSTALLER 1. Reduced installation cost since the electrical contractor only has to make 3 line voltage power connections (6 line voltage power connection if an emergency fixture). The plug-in low voltage cable that supplies each fixture can be installed by an electrician's apprentice or general laborer due to the class 2 rating. 2. Only one conduit run and junction required per room (or two if emergency power required). 3. The PTP Control Enclosure contains all the required lighting control components and comes fully wired, ETL approved, and ready for installation. The PTP Enclosure and all lighting components are fully tested before shipment. 4. The PTP Control Enclosure is fully customizable: Occupancy Sensor or Photo Cell can be installed on the • hinged door. Dimming control packs can be installed in the low • voltage section of the box. Controls up to 12 fixtures. •
BENEFITS FOR BUILDING OWNER All lighting control components, including LED fixture • power supplies, are contained in a centralized location accessible from the interior of the room through the hinged door on the enclosure preventing damage to ceiling grid and ceiling tiles. LED luminaires can be easily relocated. • The PTP Enclosure and LED fixtures are not permanently • connected to the building providing possible tax savings.
PICTURES
PICTURES
PICTURES
PICTURES
PICTURES
For more information on The System or our other products, please access our website or give us a call. (502) 301-7106 www.924inc.com
