Process Model to Predict Nondeterministic Behavior of IoT Systems Yeongbok Choe and Moonkun Lee 31 October 2018 Chonbuk National University Republic of Korea

Contents 1. Overview 2. dTP-Calculus 3. SAVE 4. Example 5. Analysis 6. Conclusions & Future Research 7. Q&A 2

1. Overview

Internet of Things Definition  Network of physical devices, vehicles, buildings and other items  that enable these objects to collect and exchange data 1 Applications  Media  Healthcare systems  Industry 4.0  …  Challenges  Safety  Security  Correctness  Complex dependencies  Cyber-Physical-Systems  Requirements  Specification  2 Verification  1 https://en.wikipedia.org/wiki/Internet_of_things 4 2 https://www.mobinius.com/industry-4-0-iot/

Motivation  Probability in IoT  Nondeterministic behavior of each devices  Complex  Non-predictable  Analysis and design are difficult 1 1 https://www.acmicpc.net/problem/13405 5

Motivation  Probability in IoT  Probability  In design step, statistics data is used  Error occurred  Route selection  Probability is used to analyze  Risk management  Behavior prediction 1 1 https://blog.storagecraft.com/business-continuity-statistics-tech/ 6

Approach  Process algebra  Specify IoT systems  Analyze IoT systems  Specify probability density function  Probabilistic analysis 7

2. dTP-Calculus

dTP-Calculus Geographical Space - Processes - Actions δ - Interactions - Space Movements - Time - Probability τ ρ Communication Control Synchrony 9

Syntax 10

Syntax  Probability  Probabilities specification  Discrete distribution  Probability density function specification  Normal distribution  Exponential distribution  Uniform distribution 11

Syntax  Probabilistic choice  Discrete distribution  𝑄 𝑑 + 𝐸 𝑅 𝑑  𝑑 : Probability  Example  𝑄 0.2 + 𝐸 𝑅 0.5 + 𝐸 𝑆{0.3} 1 1 https://en.wikipedia.org/wiki/Probability_distribution 12

Syntax  Probabilistic choice  Normal distribution  𝑄 𝑑 + 𝑂(𝜈,𝜏) 𝑅 𝑑  𝑑 : Variable area (Condition)  𝜈 : Mean  𝜏 : Standard deviation  Example  𝑄 𝑤 > 52 + 𝑂(50,5) 𝑅{𝑤 ≤ 52} 1 1 https://en.wikipedia.org/wiki/Normal_distribution 13

Syntax  Probabilistic choice  Exponential distribution  𝑄 𝑑 + 𝐹(𝜇) 𝑅 𝑑  𝑑 : Variable area (Condition)  𝜇 : Frequency  Example  𝑄 𝑤 > 2.5 + 𝐹(0.33) 𝑅{𝑤 ≤ 2.5} 1 1 https://en.wikipedia.org/wiki/Exponential_distribution 14

Syntax  Probabilistic choice  Uniform distribution  𝑄 𝑑 + 𝑉(𝑚, 𝑣) 𝑅 𝑑  𝑑 : Variable area (Condition)  𝑚 : Lower bound  𝑣 : Upper bound  Example  𝑄 𝑤 > 5 + 𝑉(3,7) 𝑅{𝑤 ≤ 5} 1 1 https://en.wikipedia.org/wiki/Uniform_distribution_(continuous) 15

Syntax  Probabilistic choice  Summation of the probabilities should be 1  Discrete distribution  𝑄 1 𝑑 1 + 𝐸 𝑄 2 𝑑 2 + 𝐸 ⋯ + 𝐸 𝑄 𝑜 {𝑑 𝑜 } 𝑜  𝑑 𝑗 = 1 𝑗=1  Normal distribution, uniform distribution  𝑄 1 𝑑 1 + 𝐺 𝑄 2 𝑑 2 + 𝐺 ⋯ + 𝐺 𝑄 𝑜 {𝑑 𝑜 } 𝑜  𝑑 𝑗 = ℝ 𝑗=1  ∀𝑗, 𝑘 ∈ 𝑦 𝑦 ∈ ℕ, 1 ≤ 𝑦 ≤ 𝑜 𝑢ℎ𝑓𝑜 𝑑 𝑗 ∩ 𝑑 𝑘 = ∅ (𝑔𝑝𝑠 𝑗 ≠ 𝑘)  Exponential distribution  𝑄 1 𝑑 1 + 𝐺 𝑄 2 𝑑 2 + 𝐺 ⋯ + 𝐺 𝑄 𝑜 {𝑑 𝑜 } 𝑜  𝑑 𝑗 = 𝑦 𝑦 ≥ 0, 𝑦 ∈ ℝ} 𝑗=1  ∀𝑗, 𝑘 ∈ 𝑦 𝑦 ∈ ℕ, 1 ≤ 𝑦 ≤ 𝑜 𝑢ℎ𝑓𝑜 𝑑 𝑗 ∩ 𝑑 𝑘 = ∅ (𝑔𝑝𝑠 𝑗 ≠ 𝑘) 16

Syntax  Probabilistic choice  Error  Summation of the probabilities is less than 1  𝑄 𝑑 1 + 𝐺 𝑅 𝑑 2 Undefined area 𝑑 1 𝑑 2 17

Syntax  Probabilistic choice  Error  Summation of the probabilities is greater than 1  𝑄 𝑑 1 + 𝐺 𝑅 𝑑 2 Overlapped area 𝑑 1 𝑑 2 18

Syntax  Probabilistic choice  Error  Summation of the probabilities is greater than 1  𝑄 𝑑 1 + 𝐺 𝑅 𝑑 2 𝑄 𝑑 1 𝑄 𝑑 1 ∥ 𝑅 𝑑 2 𝑅 𝑑 2 𝑑 1 𝑑 2 19

3. SAVE

SAVE  SAVE  Specification, Analysis, Verification, and Evaluation  Based on ADOxx meta-modeling platform 21

Specification - Visualization  Graphic language  System View  In-the-Large (ITL) Model  Representation  Interactions of each processes  Process View  In-the-Small (ITS) Model  Representation  Detailed actions of each processes 22

System View 23

System View 24

Process View 25

Process View 26

Analysis  Analysis  Path analysis  All possible execution path  Generate simulation model  Simulation  Simulate the system based on a path 27

Simulation model 28

Verification  Verification  Behavior analysis  Analyze the system behavior  Generate geo-temporal space model  Requirements Verification  Verify a set of system requirements 29

Analysis model 30

4. Example

Example  Smart Emergency Evacuation System  Sensors  Fire detection  Control System  Evacuation alarm  Rescue request  Evacuation route notification 1 1 http://www.arpel.com/business-services/fire-detection/ 32

Example Control System Building Sensor A Sensor B 33

Example  Textual Specification 34

Example  Textual Specification 35

Example  Textual Specification 36

Example  Textual Specification 37

Example  Probabilistic choice  Building  𝑇𝐵 𝐺𝑗𝑠𝑓 0.5 + 𝐸 𝑇𝐶 𝐺𝑗𝑠𝑓 {0.5}  Discrete distribution  P1  ∅ ⋅ … ⋅ 𝑤 < 2.5 + 𝑂 5,3 𝑝𝑣𝑢 2𝑜𝑒 ⋅ … ⋅ 𝑤 ≥ 2.5  Normal distribution  P2  ∅ ⋅ … ⋅ 𝑤 < 2.5 + 𝑂 5,8 𝑝𝑣𝑢 2𝑜𝑒 ⋅ … ⋅ 𝑤 ≥ 2.5  Normal distribution 38

Example  Probabilistic choice  Building  𝑇𝐵 𝐺𝑗𝑠𝑓 0.5 + 𝐸 𝑇𝐶 𝐺𝑗𝑠𝑓 {0.5}  Discrete distribution  P1  ∅ ⋅ … ⋅ 𝑤 < 2.5 + 𝑂 5,𝟒 𝑝𝑣𝑢 2𝑜𝑒 ⋅ … ⋅ 𝑤 ≥ 2.5  Normal distribution  P2  ∅ ⋅ … ⋅ 𝑤 < 2.5 + 𝑂 5,𝟗 𝑝𝑣𝑢 2𝑜𝑒 ⋅ … ⋅ 𝑤 ≥ 2.5  Normal distribution  P1 and P2 have same type’s choice, but parameters are different. 39

5. Analysis

Analysis  Execution path  8 paths 41

Analysis  Execution path  8 paths  Fire: The location where the fire occurred  Stay: P1 or P2, confined in Building  Out: P1 or P2, escaped from Building Path 1 Path 2 Path 3 Path 4 Path 5 Path 6 Path 7 Path 8 Fire Stair A Stair A Stair A Stair A Stair B Stair B Stair B Stair B P1 Stay Stay Out Out Stay Stay Out Out P2 Stay Out Stay Out Stay Out Stay Out 42

Analysis  Probability  Mathematical analysis  Calculate the probability  ∅ ⋅ … ⋅ 𝑤 < 2.5 + 𝑂 5,𝟒 𝑝𝑣𝑢 2𝑜𝑒 ⋅ … ⋅ 𝑤 ≥ 2.5  ∅ ⋅ … ⋅ 0.2023 + 𝐸 𝑝𝑣𝑢 2𝑜𝑒 ⋅ … ⋅ 0.7977  ∅ ⋅ … ⋅ 𝑤 < 2.5 + 𝑂 5,𝟗 𝑝𝑣𝑢 2𝑜𝑒 ⋅ … ⋅ 𝑤 ≥ 2.5  ∅ ⋅ … ⋅ 0.3773 + 𝐸 𝑝𝑣𝑢 2𝑜𝑒 ⋅ … ⋅ 0.6227 Path 1 Path 2 Path 3 Path 4 Path 5 Path 6 Path 7 Path 8 % 3.82 6.3 15.05 24.83 3.82 6.3 15.05 24.83 43

Analysis  Simulation  Simulate the system based on the probabilities 44

Analysis  Simulation  Simulate the system based on the probabilities Probability Number of Simulation Path 1 Path 2 Path 3 Path 4 Path 5 Path 6 Path 7 Path 8 1,000 3.5 6.2 14.2 25 3.5 7.5 14.4 25.7 1,000,000 3.79 6.32 15.04 24.86 3.82 6.32 14.98 24.87 45

Analysis  Simulation  Simulate the system based on the probabilities Probability Number of Simulation Path 1 Path 2 Path 3 Path 4 Path 5 Path 6 Path 7 Path 8 1,000 3.5 6.2 14.2 25 3.5 7.5 14.4 25.7 1,000,000 3.79 6.32 15.04 24.86 3.82 6.32 14.98 24.87 Simulation results Path 1 Path 2 Path 3 Path 4 Path 5 Path 6 Path 7 Path 8 % 3.82 6.3 15.05 24.83 3.82 6.3 15.05 24.83 Mathematical analysis 46

Analysis  Prediction of occurrence probability  In complex system, mathematical analysis is difficult.  Through the simulation, paths and probabilities are derived.  Automation  SAVE tool  Specify and analyze the system  Generate all possible paths  Simulation based on probability 47

6. Conclusions

Approach Geographical Space - Processes - Actions δ - Interactions - Space Movements - Time - Probability τ ρ Communication Control Synchrony 49

Approach  Various probability specification  Discrete distribution  Normal distribution  Exponential distribution  Uniform distribution 50

SAVE 51

SAVE  Simulation 52
