Memory Virtualization: Paging Speed Prof. Patrick G. Bridges 1 - PowerPoint PPT Presentation

University of New Mexico Memory Virtualization: Paging Speed Prof. Patrick G. Bridges 1 University of New Mexico Speeding up Translation with a TLB Page table entries (PTEs) are cached in L1 like any other memory word PTEs may be


  1. University of New Mexico Memory Virtualization: Paging Speed Prof. Patrick G. Bridges 1

  2. University of New Mexico Speeding up Translation with a TLB  Page table entries (PTEs) are cached in L1 like any other memory word ▪ PTEs may be evicted by other data references ▪ PTE hit still requires a small L1 delay  Solution: Translation Lookaside Buffer (TLB) ▪ Small set-associative hardware cache in MMU ▪ Maps virtual page numbers to physical page numbers ▪ Contains complete page table entries for small number of pages 2

  3. University of New Mexico TLB  Part of the chip’s memory -management unit(MMU).  A hardware cache of popular virtual-to-physical address translation. TLB MMU TLB Hit Lookup Physical Logical TLB Address Address popular v to p TLB Miss Page 0 Page Table CPU Page 1 all v to p entries Page 2 … Page n Address Translation with MMU Physical Memory 3

  4. University of New Mexico Accessing the TLB  MMU uses the VPN portion of the virtual address to access the TLB: T = 2 t sets VPN TLBT matches tag of n-1 p+t p+t-1 p p-1 0 line within set TLB tag (TLBT) TLB index (TLBI) VPO Set 0 v tag PTE v tag PTE TLBI selects the set Set 1 v tag PTE v tag PTE … Set T-1 v tag PTE v tag PTE 4

  5. University of New Mexico TLB Hit CPU Chip TLB PTE 2 3 VPN 1 VA PA CPU MMU Cache/ 4 Memory Data 5 A TLB hit eliminates a memory access 5

  6. University of New Mexico TLB Miss CPU Chip TLB 4 2 PTE VPN 1 3 VA PTEA CPU MMU Cache/ PA Memory 5 Data 6 A TLB miss incurs an additional memory access (the PTE) Fortunately, TLB misses are rare. Why? 6

  7. University of New Mexico Example: Accessing An Array  How a TLB can improve its performance. OFFSET 00 04 08 12 16 VPN = 00 0: int sum = 0 ; VPN = 01 1: for( i=0; i<10; i++){ VPN = 03 2: sum+=a[i]; VPN = 04 3: } VPN = 05 VPN = 06 a[0] a[1] a[2] The TLB improves performance VPN = 07 a[3] a[4] a[5] a[6] due to spatial locality VPN = 08 a[7] a[8] a[9] 3 misses and 7 hits. VPN = 09 Thus TLB hit rate is 70%. VPN = 10 VPN = 11 VPN = 12 VPN = 13 VPN = 14 VPN = 15 7

  8. University of New Mexico Who Handles The TLB Miss?  Option 1: Hardware handles the TLB miss (x86, ARM). ▪ The hardware has to know exactly where the page tables are located in memory. ▪ The hardware would “walk” the page table, find the correct page - table entry and extract the desired translation, update and retry instruction. ▪ Hardware specifies the exact format of the page table! ▪ Hardware-managed TLB. 8

  9. University of New Mexico Who Handles The TLB Miss? (Cont.)  Option 2: Software-managed TLB (MIPS, some others) ▪ On a TLB miss, the hardware raises exception( trap handler ). ▪ Trap handler is code within the OS that is written with the express purpose of handling TLB miss. ▪ Allows for much wider range of page table organizations 9

  10. University of New Mexico TLB entry  TLB is generally a small fully associative cache . ▪ A typical TLB might have 32, 64, or 128 entries. ▪ Hardware search the entire TLB in parallel to find the desired translation. ▪ other bits: valid bits , protection bits, address-space identifier, dirty bit VPN PFN other bits Typical TLB entry look like this 10

  11. University of New Mexico Issue: Context Switching and Shared TLB  TLB is a hardware structure shared by all processes Page 0 Insert TLB Entry Page 1 TLB Table Page 2 VPN PFN valid prot access VPN10 … Process A 10 100 1 rwx Page n - - - - Virtual Memory - - - - - - - - Page 0 Page 1 Process B Page 2 … Page n Virtual Memory 11

  12. University of New Mexico TLB Issue: Context Switching Page 0 Page 1 TLB Table Page 2 … Process A VPN PFN valid prot Page n 10 100 1 rwx Virtual Memory - - - - Context 10 170 1 rwx Switching - - - - Page 0 Insert TLB Entry Page 1 access VPN10 Process B Page 2 … Can’t Distinguish which entry is Page n meant for which process Virtual Memory 12

  13. University of New Mexico Options Flush TLB on context switch 1. Provide an address space identifier (ASID) field in the TLB. 2. Page 0 Page 1 TLB Table Page 2 VPN PFN valid prot ASID Process A … 10 100 1 rwx 1 Page n - - - - - Virtual Memory 10 170 1 rwx 2 Page 0 - - - - - Page 1 Process B Page 2 … Page n Virtual Memory 13

  14. University of New Mexico Simple Memory System Example  Addressing ▪ 14-bit virtual addresses ▪ 12-bit physical address ▪ Page size = 64 bytes 13 12 11 10 9 8 7 6 5 4 3 2 1 0 VPN VPO Virtual Page Offset Virtual Page Number 11 10 9 8 7 6 5 4 3 2 1 0 PPN PPO Physical Page Number Physical Page Offset 14

  15. University of New Mexico 1. Simple Memory System TLB  16 entries  4-way associative TLBT TLBI 13 12 11 10 9 8 7 6 5 4 3 2 1 0 VPN VPO Set Tag PPN Valid Tag PPN Valid Tag PPN Valid Tag PPN Valid 0 03 – 0 09 0D 1 00 – 0 07 02 1 1 03 2D 1 02 – 0 04 – 0 0A – 0 2 02 – 0 08 – 0 06 – 0 03 – 0 3 07 – 0 03 0D 1 0A 34 1 02 – 0 15

  16. University of New Mexico 2. Simple Memory System Page Table Only show first 16 entries (out of 256) VPN PPN Valid VPN PPN Valid 00 28 1 08 13 1 01 – 0 09 17 1 02 33 1 0A 09 1 03 02 1 0B – 0 04 – 0 0C – 0 05 16 1 0D 2D 1 06 – 0 0E 11 1 07 – 0 0F 0D 1 16

  17. University of New Mexico 3. Simple Memory System Cache  16 lines, 4-byte block size  Physically addressed  Direct mapped CT CI CO 11 10 9 8 7 6 5 4 3 2 1 0 PPN PPO Idx Tag Valid B0 B1 B2 B3 Idx Tag Valid B0 B1 B2 B3 0 19 1 99 11 23 11 8 24 1 3A 00 51 89 1 15 0 – – – – 9 2D 0 – – – – 2 1B 1 00 02 04 08 A 2D 1 93 15 DA 3B 3 36 0 – – – – B 0B 0 – – – – 4 32 1 43 6D 8F 09 C 12 0 – – – – 5 0D 1 36 72 F0 1D D 16 1 04 96 34 15 6 31 0 – – – – E 13 1 83 77 1B D3 7 16 1 11 C2 DF 03 F 14 0 – – – – 17

  18. University of New Mexico Address Translation Example #1 Virtual Address: 0x03D4 TLBT TLBI 13 12 11 10 9 8 7 6 5 4 3 2 1 0 0 0 0 0 1 1 1 1 0 1 0 1 0 0 VPN VPO VPN ___ TLBI ___ TLBT ___ TLB Hit? __ Page Fault? __ PPN: ____ 0x0F 0x3 0x03 Y N 0x0D Physical Address CT CI CO 11 10 9 8 7 6 5 4 3 2 1 0 0 0 1 1 0 1 0 1 0 1 0 0 PPN PPO CO ___ CI__ CT ___ Hit? __ Byte: ____ 0 0x5 0x0D Y 0x36 18

  19. University of New Mexico Address Translation Example #2 Virtual Address: 0x0020 TLBT TLBI 13 12 11 10 9 8 7 6 5 4 3 2 1 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 VPN VPO VPN ___ TLBI ___ TLBT __ TLB Hit? __ Page Fault? __ PPN: ____ 0x00 0 0x00 N N 0x28 Physical Address CT CI CO 11 10 9 8 7 6 5 4 3 2 1 0 1 0 1 0 0 0 1 0 0 0 0 0 PPN PPO CO___ CI___ CT ____ Hit? __ Byte: ____ 0 0x8 0x28 N Mem 19

  20. University of New Mexico Address Translation Example #3 Virtual Address: 0x0020 TLBT TLBI 13 12 11 10 9 8 7 6 5 4 3 2 1 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 VPN VPO 0x00 0 0x00 N N 0x28 VPN ___ TLBI ___ TLBT ____ TLB Hit? __ Page Fault? __ PPN: ____ Physical Address CT CI CO 11 10 9 8 7 6 5 4 3 2 1 0 1 0 1 0 0 0 1 0 0 0 0 0 PPN PPO 0 0x8 0x28 N Mem CO___ CI___ CT ____ Hit? __ Byte: ____ 20
