MARINE LIGHTING Considered like a specialist of outstand- STARDECK - PowerPoint PPT Presentation

MARINE LIGHTING Considered like a specialist of outstand- STARDECK ing environment resistant lighting fixtures, it has been challenging and interesting for the KAPSEA engineering team to develop a range of marine lighting. Designed with and for boat professional, we have developed power- ful luminaries for most of yachts, sailing boats, commercial vessels applica- tions... MARINE LIGHTING SPECIALIST SINCE 2006

MARINE LIGHTING STARDECK SERIES The stardeck series is a range of fantastic deck washers, compact, powerful and efficient. Designed in order to resist to harmful environment, Stardeck series is well appreciated for installation on yacht decks but also on working boat, off-shore plateforms... IP67 The high quality KAPSEA sealing makes the range completely waterproofed, tested under the IP67 requirements. IK08 The high-resistant PC cover strengthens the Stardeck, complying with IK08 requirements. Compact and Light Much more compact and light than most of our competitors. 2.5kg for more than 6.000 lumens (Stardeck 50) and 3.2kg for more than 12.000 Lumens. (Stardeck 100) High resistance to vibrations PCB, COB, casing, bracket of the lighting fixture have all been design in order to resist to repeated vibrations. High Lumen output KAPSEA engineering team has been designing this range in order to achieve up to 120 Lumens/w of efficiency on the product lumen output.

MARINE LIGHTING 2.5KG STARDECK SERIES Compact and Light The stardeck series is a range of fantastic deck washers, compact, powerful and efficient. Designed in order to resist to harmful environment, Stardeck series is well appreciated for installation on yacht decks but also on working boat, off-shore plateforms... IK 08 Strong design 120 lm / Watt High Lumen output High resistance to vibrations IP67 Water proof

MARINE LIGHTING STAR FOCUS 50-DC S STAR FOCUS 100-DC Consommation 52 w Consommation 100 w Tension d’entrée 9-33 VDC Tension d’entrée 9-33 VDC Durée de vie 50,000 Hrs (L70% - 25℃) Durée de vie 50,000 Hrs (L70% - 25℃) CRI >80 CRI >80 Puces LED SMD 5852 Epistar tailor made Puces LED SMD 5630 Epistar tailor made Indice d’étanchéité IP67 Indice d’étanchéité IP67 Température d’utilisation -40℃ ~ 80℃ -40℃ ~ 80℃ Température d’utilisation Angle de faisceau 60℃ 60℃ Angle de faisceau Sortie lumen 12000 lm 6200 lm Sortie lumen Dimension 310*185*185 225*165*165 Dimension 2.5 kg Poids 1.67 kg Poids Couleur Couleur Noir Noir Blanc Blanc Températures de couleur Températures de couleur IK 08 IK 08 STAR DECK 50-DC STAR DECK 100-DC Consommation 52 w Consommation 58 w Tension d’entrée 9-33 VDC Tension d’entrée 9-33 VDC Durée de vie 50,000 Hrs (L70% - 25℃) Durée de vie 50,000 Hrs (L70% - 25℃) CRI >80 CRI >80 Puces LED SMD 5630 Epistar tailor made SMD 5852 Epistar tailor made Puces LED Indice d’étanchéité IP67 Indice d’étanchéité IP67 Température d’utilisation -40℃ ~ 80℃ -40℃ ~ 80℃ Température d’utilisation Angle de faisceau 120℃ 120℃ Angle de faisceau 12000 lm Sortie lumen 6200 lm Sortie lumen Dimension 330*185*185 Dimension 245*165*165 2.5 kg Poids 1.67 kg Poids Couleur Couleur Noir Noir Blanc Blanc Températures de couleur Températures de couleur IK 08 IK 08
