LATERAL VIEW 1
EXTERNAL VIEW 2
FORWARD CABIN 3
FORWARD CABIN WRITING DESK 4
PORT AMIDSHIP CABIN 5
VIEW AFT 6 SALOON
STB SIDE 7 SALOON
VIEW FORWARD 8 GALLEY
DRAWINGS SAIL PLAN 9
DECK LAYOUT 10 DRAWING
INTERIOR ARRANGEMENT 11 DRAWING
DRAWING 12 INTERIOR ARRANGEMENT OPTIONAL
ENGINE AND HYDRAULICS GENERAL DIMENSIONS ELECTRONICS Main engine Steyr MO166M28 3,2l ,inline 6-cyl 120 kW (163 Hp) Sailing instruments B & G H 3000 incl. 3 GFD, 3 x 20/20 and compass LOA 20.12 m 66.01 ft Gearbox ZF 63 IV 2.48:1 Navigation systems Furuno NavNet 3D, GPS GP 330 – B LWL 17.19 m 56.40 ft Propeller Folding 4-blade Brunton Varifold 25” x 20” Communication systems VHF Simrad RS 87 Beam max 5.39 m 17.68 ft Fuel system 2x 650ltr stainless steal tanks, separ fuel filters Entertainment systems Bose Lifestyle 18 in saloon and cockpit, Draught (light) 3.20 m 10.50 ft Generator Fischer Panda 14.000 NE PMS (11.9 kVA) 230 V AC 32” LCD TV in saloon Displacement (light) 30 000 kg 66 000 lbs Hydraulics Powered hydraulics with a manual back-up for Autopilots B & G H3000 main unit, Marsili power pack Displacement (loaded) 35 000 kg 77 000 lbs rig tensioning and furler Aerials RR Delta DSC Biscaya TV/FM/VHF Ballast 9 400 kg 20 720 lbs Pneumatics Low pressure 24V compressor for transom door seal Classification CE Category A Ocean HULL PLUMBING AND VENTILATION RIG Hull laminate Vacuum infused glass fibre reinforced polyester Freshwater 2x 625ltr stainless steal tanks Reinforcment laminates Glass/carbon fibre refinforced polyester Hot water 75 ltr stainless steal tank General Standard modulus carbon fibre, 3 spreader Bulkhead laminate Vacuum infused carbon fibre reinforced epoxy Water maker Spectra Newport 700, 109 l / h discontinuous shrouds swept back spreaders Hull finish Gelcoat Grey water 4x sanimarine grey water transfer pumps led to a Mast Mast tube of oval section with a molded topmast Keel Lead casting alloyed with antimony 210ltr stainless steal tank with electrical discharge taper Rudder Carbon fibre reinforced stock and blade pump/deck suction Boom Park Avenue type standard modulus Dinghy garage Space for 3.1 m deflated v-floor dinghy Black water 1x 210ltr stainless steal tank with electrical Standing rigging Navtec Nitronic 50 discharge pump/deck suction Running rigging Dyneema DECK Bilge system 2 x manual Gusher Titan, 3 x electrical bilge pumps Furlers Reckmann UD3 Sphere, with an aluminium foil LPG system Force 10 (four burner),2 x 6kg gas bottles Rig hydraulics Powered by central hydraulic system Deck laminate Vacuum infused carbon/glass fibre reinforced epoxy Ventilation Forced supply- & exhaust ventilation in cabins, Dimensions IG 27.50 m 90.22 ft Reinforcment laminates Glass/carbon fibre refinforced epoxy forepeak and lazarette J 7.45 m 24.44 ft Deck finish Gelcoat Galley fan Gorenje DF 615 E extractor hood P 25.25 m 82.84 ft Teak deck 9x 55 mm teak slats Air handling systems Webasto Blue Cool Premium TwG 50000 BTU/h, E 7.60 m 29.93 ft Winches 4x Harken B980.3 STEA, 2x Harken B70.3 STEA with reverced cycle and diesel heater Sail areas Fore triangle 102.4 m 2 1102.6 sq.ft Windlass Lewmar V6 Refrigeration systems Friogonautica custom, refrigerator 1x140ltr and Main sail 121.6 m 2 1308.9 sq.ft Anchor arm Nautor custom built anchor arm 1x180ltr, freezer 1x125ltr Jib 95.4 m 2 1026.9 sq.ft EQUIPMENT Sail handling system Harken black anodized deck hardware ELECTRICAL Hatches and windows Nautor custom built acrylic Anchor CQR 34kg, 75 lbs and Danforth 60H 27 kg Shore power 230 V, 50 A INTERIOR Generator Fisher Panda 14000, 11,9 kVA @ 3000 rpm Chargers 2 pcs Mastervolt 24/75A for service batteries, General Teak with satin finish and white painted panels 1 pcs Mastervolt 24/50A for instrument batteries Main inverter Mastervolt 24/2500, 230 V, 50 Hz, 2500 W Electronics inverter Mastervolt 24/1500, 230V, 50Hz, 1500 W Service batteries 12 x Enersys 8 PzV480 2 V gel batteries Instrument batteries 12 x Enersys 4 PzV240 2 V gel batteries SPECIFICATION 13
