Johnson Control Building Automation System by Mr.Prasert - PowerPoint PPT Presentation

Johnson Control Building Automation System by Mr.Prasert Sutthiparinyanon Complete Electrical Solutions Co.,Ltd Introduction Johnson Controls: Building Efficiency How many system in your Building 1. Electrical System Energy Management


  1. Johnson Control Building Automation System by Mr.Prasert Sutthiparinyanon Complete Electrical Solutions Co.,Ltd

  2. Introduction Johnson Controls: Building Efficiency • How many system in your Building 1. Electrical System Energy Management MDB Generator Facility Management Lighting 2. Mechanical System Environmental Control Ventilation Air condition (Chiller , AHU , FCU ) Maintenance Mgmt 3. Sanitary System Plumb Water treatment 4. Information Technology Network & Communication 5. System Interface Fire Alarm System Security System Lighting System CCTV

  3. Intelligent Buildings Owners want to save costs – Energy costs – Operations costs – Retrofit costs Life Cycle Cost of an Life Cycle Cost of an 11% Office Building Office Building 25% (40 years) (40 years) 14% Construction Financing Energy 25% 25% Operations Retrofit

  4. Energy Monitoring Utility Profile NCM Definition Item Edit View Action Go To Accessory Item Description Status Value Date Time Current Period Since Total Consumption KWH at Measured Peak KW at Projected Peak KW at Previous Period Since Total Consumption KWH at Measured Peak KW at Projected Peak KW at Item Description Status Value Date Time Current Period Since Total Consumption KWH at Measured Peak KW at Projected Peak KW at

  5. Overview Enterprise Office Automation Ethernet TCP/IP Management Local Area Network System Operator Workstation Layer Building Automation Local Area Network BAS Controller Layer DDC Controller Layer Sensing and Actuating Layer

  6. BAS INTERFACE ALARM PTR. ALARM PTR. SECURITY EVEN PTR. FILE SERVER BAS WORKSTATION FIRE ALM. FIRE ALM. UPS UPS LOGGING PTR. EtherNet BACNet TCP/IP N2 BUS DDC DDC FCP ACS NCU INTERFACE VIA BACNet TCP/IP VAV BOX METER

  7. FILE SERVER BAS WORKSTATION EVEN PTR. LOGGING PTR. UPS UTP CAT5E. UTP CAT5E. HUB DI,AI DO,AO DDC DI,AI DO,AO DDC NCU DI,AI DO,AO DDC VAV BOX FI L TE R FI LTE R N2 BUS TWISTED PAIR SHIELD #18-22 AWG. VAV BOX BAS RISER DIAGRAM

  8. M-Trend The M-trend application of the Metasys Workstation provides users with features that aid in the analysis of data for effective energy management and equipment diagnostics. Special features contribute to a better understanding of how trended values relate to the task at hand and to each other: • Data point display • Data point detail • Data zoom

  9. M-Alarm M-Alarm allows the user to view and manipulate current alarms and has the capability to route alarm data to assigned destinations. • Alarm reporting • Display current alarm events • Storage and printing

  10. M-Password M-Password provides versatile and flexible security for your system. High performance features of M-Password include: • Management of groups and individuals • Control areas and points of access • Control times of user access • Administer account policies • Control application actions associated with individual users

  11. Project Reference Banyan Tree, Samui

  12. Project Reference Courtyard Marriott – Patong, Surin and Kamala

  13. Project Reference Four Point by Sheraton

  14. Thank you
