HDR images acquisition dr. Francesco Banterle - PowerPoint PPT Presentation

HDR images acquisition dr. Francesco Banterle francesco.banterle@isti.cnr.it Current sensors No sensors available to consumer for capturing HDR content in a single shot Some native HDR sensors exist, HDRc by Omron, but some issues:


  1. HDR images acquisition dr. Francesco Banterle francesco.banterle@isti.cnr.it

  2. Current sensors • No sensors available to consumer for capturing HDR content in a single shot • Some native HDR sensors exist, HDRc by Omron, but some issues: • too much noise • low resolution (around 1024x768) • expensive to manufacture

  3. Exposure bracketing • Capturing many LDR images (8-bit) of the same scene: • from the darkest area in the scene • to the brightest area in the scene • The scene has to be static!!!

  4. Exposure bracketing t = 1/128s t = 1/32s t = 1/8s

  5. Exposure bracketing • Required equipment: • camera with the possibility to vary the exposure • tripod (avoid camera shake) • Optional equipment: • luminance meter • colorchecker chart • remote control for the camera

  6. How many exposures? • Brute force approach: • Select an exposure for the darkest/brightest area in the scene and take a shot • Double/half exposure and take a shot • Repeat until brightest/darkest are in the scene is captured

  7. How many exposures? • Some issue with this approach: • time consuming, especially if the camera is not programmable • we are making micro movements at every click! • over-sampling, maybe there is no need

  8. Exposure Metering • Exposure metering [Gallo et al. 2012]: • capturing histograms from the viewfinder (picture preview in a camera) - free! P n i =0 H ( i ) • computing CDF for each histogram F ( n ) = P N i =0 H ( i ) • obtaining the global CDF • differentiation —> HDR histogram

  9. Exposure Metering: LDR Histograms 0.04 0.06 0.08 0.09 0.08 0.035 0.07 0.05 0.07 0.03 0.06 0.04 0.06 0.025 0.05 0.05 0.02 0.03 0.04 0.04 0.015 0.03 0.02 0.03 0.01 0.02 0.02 0.01 0.005 0.01 0.01 0 0 0 0 − 11 − 10 − 9 − 8 − 7 − 6 − 5 − 4 − 3 − 2 − 12 − 11 − 10 − 9 − 8 − 7 − 6 − 5 − 4 − 3 − 13 − 12 − 11 − 10 − 9 − 8 − 7 − 6 − 5 − 4 − 13 − 12 − 11 − 10 − 9 − 8 − 7 − 6 − 5 1 0.5 0.35 0.08 0.9 0.45 0.07 0.3 0.8 0.4 0.06 0.25 0.7 0.35 0.05 0.6 0.3 0.2 0.5 0.25 0.04 0.15 0.4 0.2 0.03 0.3 0.15 0.1 0.02 0.2 0.1 0.05 0.01 0.1 0.05 0 0 0 0 − 2 − 1 0 1 2 3 4 5 6 − 8 − 7 − 6 − 5 − 4 − 3 − 2 − 1 0 1 − 9 − 8 − 7 − 6 − 5 − 4 − 3 − 2 − 1 0 − 10 − 9 − 8 − 7 − 6 − 5 − 4 − 3 − 2 − 1 0.9 1 0.8 0.9 0.9 0.8 0.8 0.7 0.8 0.7 0.7 0.6 0.7 0.6 0.6 0.5 0.6 0.5 0.5 0.5 0.4 0.4 0.4 0.4 0.3 0.3 0.3 0.3 0.2 0.2 0.2 0.2 0.1 0.1 0.1 0.1 0 0 0 0 − 4 − 3 − 2 − 1 0 1 2 3 4 − 3 − 2 − 1 0 1 2 3 4 5 − 6 − 5 − 4 − 3 − 2 − 1 0 1 2 3 − 5 − 4 − 3 − 2 − 1 0 1 2 3 4

  10. Exposure Metering: LDR CDFs 1 0.9 0.8 0.7 0.6 0.5 F 0.4 0.3 0.2 0.1 0 − 14 − 12 − 10 − 8 − 6 − 4 − 2 0 2 4 6 log 2 Irradiance

  11. Exposure Metering Algorithm 2.1: C OMP F ULL CDF( { B k } , { b ˜ E i , j } , F L 1 , F L 2 ,..., F L J ) for k ← 0 to K − 1 do F H ( B k ) ← 0 for j ← 0 to J − 1 8 for i ← 0 to I − 2 > < ( for each k : B k ∈ ( b ˜ i , j , b ˜ E E i + 1 , j ] do do j ( b ˜ do F H ( B k ) ← max ( F H ( B k ) , F L E > i , j )) : return ( F H )

  12. Exposure Metering: HDR CDF 1 0.9 0.8 0.7 0.6 0.5 F 0.4 0.3 0.2 0.1 0 − 14 − 12 − 10 − 8 − 6 − 4 − 2 0 2 4 6 log 2 Irradiance

  13. Exposure Metering: HDR Histogram 0.03 0.025 0.02 0.015 P 0.01 0.005 0 − 14 − 12 − 10 − 8 − 6 − 4 − 2 0 2 4 6 log 2 Irradiance

  14. Exposure Metering • Selection of exposure times based on: • HDR histogram • Noise model of the camera

  15. Exposure Metering: sampling 0.03 0.025 0.02 0.015 P 0.01 0.005 0 − 14 − 12 − 10 − 8 − 6 − 4 − 2 0 2 4 6 log 2 Irradiance

  16. Exposure Metering: sampling 0.03 0.025 0.02 0.015 P 0.01 0.005 exp 0 − 14 − 12 − 10 − 8 − 6 − 4 − 2 0 2 4 6 log 2 Irradiance

  17. Exposure Metering: sampling 0.03 0.025 0.02 0.015 P 0.01 0.005 exp exp 0 − 14 − 12 − 10 − 8 − 6 − 4 − 2 0 2 4 6 log 2 Irradiance

  18. Exposure Metering: sampling 0.03 0.025 0.02 0.015 P 0.01 0.005 exp exp exp 0 − 14 − 12 − 10 − 8 − 6 − 4 − 2 0 2 4 6 log 2 Irradiance

  19. Exposure Metering: sampling 0.03 0.025 0.02 0.015 P 0.01 0.005 exp exp exp exp 0 − 14 − 12 − 10 − 8 − 6 − 4 − 2 0 2 4 6 log 2 Irradiance

  20. Exposure Metering: sampling 0.03 0.025 0.02 0.015 P 0.01 0.005 exp exp exp exp exp 0 − 14 − 12 − 10 − 8 − 6 − 4 − 2 0 2 4 6 log 2 Irradiance

  21. Linear Images • What is a linear value? I = a E • where: • I the value recorded by the sensor • E is the radiance of the real value • a is a constant

  22. Linear Images • High-end or prosumer camera can save RAW: • advantage: storing linear values • disadvantage: a lot of memory; no compression and 12-14bit per color channel

  23. meanwhile in the real-word…

  24. Linear Images • Consumer cameras, smartphones, tables save typically JPEG at high quality (in the best case): • advantage: images are stored in little memory • disadvantage: • no linear values • images are stored applying an unknown function, f, called Camera Response Function (CRF)

  25. Linear Images: example 250 200 Pixel value 150 identity γ = 2.2 100 50 0 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Relative camera response

  26. Linear Images: example 250 200 Pixel value 150 red channel green channel blue channel 100 50 0 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Relative camera response

  27. Estimating CRF • What can we do? • We can estimate the CRF or perform a radiometric calibration • What can we do? • Taking a photograph with colorchecker and controlled environment • Taking photographs at different exposure times

  28. Estimating CRF

  29. Estimating CRF function to minimize smoothing term

  30. Estimating CRF • To minimize the objective function, a dense linear system needs to be solved using SVD: • (N exposures x N samples + D + 1) x (N samples + D + 1) • where D = 256 (discretization levels) • We cannot use all pixels in the image: • too large system

  31. Estimating CRF • To minimize the objective function, a dense linear system needs to be solved using SVD • We cannot use all pixels in the image: • too large system

  32. Estimating CRF • To minimize the objective function, a dense linear system needs to be solved using SVD • We cannot use all pixels in the image: • too large system

  33. Estimating CRF: samples selection • Idea1 : sampling in spatial domain

  34. Estimating CRF: samples selection • For each spatial sample ( i, j ) • Collect values at each exposure, , to obtain a Z i sample vector: [ Z 0 ( i, j ) , ..., Z n ( i, j )]

  35. Estimating CRF: samples selection • Idea2 : in histogram domain, to randomly subsample the image 1 0.8 0.6 F 0.4 Exposure 1 0.2 Exposure 2 Exposure 3 0 0 50 100 150 200 250 Pixel value

  36. Estimating CRF: samples selection • Idea2 : sampling in histogram domain 1 0.8 0.6 F 0.4 Exposure 1 0.2 Exposure 2 Exposure 3 0 0 50 100 150 200 250 Pixel value

  37. Estimating CRF: samples selection • Idea2 : sampling in histogram domain 1 0.8 0.6 F 0.4 Exposure 1 0.2 Exposure 2 Exposure 3 0 0 50 100 150 200 250 Pixel value

  38. Estimating CRF: samples selection • Idea2 : sampling in histogram domain 1 0.8 0.6 F 0.4 Exposure 1 0.2 Exposure 2 Exposure 3 0 0 50 100 150 200 250 Pixel value

  39. Estimating CRF: samples selection • Idea2 : sampling in histogram domain 1 0.8 0.6 F 0.4 Exposure 1 0.2 Exposure 2 Exposure 3 0 0 50 100 150 200 250 Pixel value

  40. Estimating CRF: samples selection • Idea2 : sampling in histogram domain 1 0.8 0.6 F 0.4 Exposure 1 0.2 Exposure 2 Exposure 3 0 0 50 100 150 200 250 Pixel value

  41. Estimating CRF: samples selection • Idea2 : sampling in histogram domain 1 0.8 0.6 F 0.4 Exposure 1 0.2 Exposure 2 Exposure 3 0 0 50 100 150 200 250 Pixel value

  42. Estimating CRF: samples selection • Idea2 : sampling in histogram domain 1 0.8 0.6 F 0.4 Exposure 1 0.2 Exposure 2 Exposure 3 0 0 50 100 150 200 250 Pixel value

  43. Estimating CRF: samples selection • Idea2 : sampling in histogram domain 1 0.8 0.6 F 0.4 Exposure 1 0.2 Exposure 2 Exposure 3 0 0 50 100 150 200 250 Pixel value

  44. Estimating CRF: weighting function • weighting function: • to avoid outliers during the estimate • shapes: tent, box with cut-off, Gaussian, etc. • outliers: • over-exposed pixels • under-exposed pixels

  45. Estimating CRF: samples selection 1 0.8 0.6 w(x) 0.4 0.2 0 0 50 100 150 200 250 Pixel value

  46. Estimating CRF: samples selection w ( x ) = 1 − (2 x − 1) 12 1 0.8 0.6 w(x) 0.4 0.2 0 0 50 100 150 200 250 Pixel value

  47. Estimating CRF: samples selection − 4 ( x − 0 . 5)2 w ( x ) = e 2(0 . 5)2 1 0.9 0.8 0.7 0.6 w(x) 0.5 0.4 0.3 0.2 0.1 0 50 100 150 200 250 Pixel value
