Ge orgia Conne c te d Ve hic le s Conne c te d Ve hic le s Progr ogress and P and Plans ans
Point – to – point c ommunic ations V2X is this: Not this: OBU PED OBU PED OBU RSU OBU RSU Info fota tain inment vs. vs. S Saf afet ety C Cri ritical al
Source: Toyota InfoTech
AASHT O SPaT Challe nge To challenge state and local public sector transportation Infrastructure Owners and Operators (IOOs) to deploy DSRC infrastructure with SPaT (and MAP) broadcasts in at least one corridor or network (approximately 20 signalized intersections) in each state by January 2020 20 int 20 ntersection ons in n 50 50 st states by by 2020 2020! 26 26 States Committed 450 450+ Signals Operating 3,800+ 00+ Signals Planned
Pilot De ployme nt Obje c tive s Primary goal: Develop back-end infrastructure, network components, and business processes to support broad vehicle to infrastructure applications that is broadcast-medium agnostic, scalable, and sustainable. Secondary goal: Begin broad installation of available roadside units and on-board units to facilitate applications that improve safety and mobility. Primary Application Spaces: Mobility Safety Freight Partnerships
Initial De ployme nt Phas hase 1: P Pilot ot – Active June une 2018 2018 • SR 141 (Peachtree) from SR 9 to I-285 • SR 8 (Ponce de Leon) from Peachtree to SR 42 • 54 traffic signals • 12 ramp meters • Signal Phasing and Timing (SPaT) • Red light warning • Pedestrian in signalized crosswalk (in development) • Phase termination/next signal phase • Green-band speed (Green light optimal speed)
Pha se 1 SPa T / MAP Applic a tions Safety for drivers – alerts of Red light warning inability to safely clear intersection Safety for drivers and pedestrians – Pedestrian in crosswalk turning vehicles have additional awareness of other users Efficiency for drivers – alert drivers Phase service remaining for safe intersection passage or efficient stopping Efficiency for drivers – inform Green speed for drivers of the optimal driving speed through coordinated signals to coordinated signals minimize stops ACTIVE RSUs IN METRO ATLANTA • SR 141 (Peachtree) – 39 intersections • SR 8 (Ponce de Leon) – 15 intersections • North Ave – 22 intersections (Renew)
HTTPS/ HTTPS GDOT CV Ar c hite c tur e JSON /WS Signal Open Data • CV Application resides on signal controller Central API System • No additional hardware (outside of RSU) required • Open access to third parties HTTPS HTTPS/ /WS WS NTCIP • Confo onformity to to nati national stan tandards and and open open ac access 1201 1202 1211 ATC Signal CV App DSRC Controller Radio SAEJ2735 SAEJ2735 SPaT MAP BSM BIM/RSM TIM
De ployme nt
De ployme nt
De ployme nt
Intersection name Phase Debug service information remaining Minimum speed required to clear green Vehicle speed
Red light running warning
Validation and T e sting • Properly formatted, J2735-compliant messages • Ingress lanes that include a ConnectsTo but that egress lane is not defined (or is not defined as an egress) • Ingress lanes that do not include a ConnectsTo • Ingress lanes that do not include a signal phase/approachId • Incorrect or missing ingress/egress definitions for each approach • Overlap/underlap of lanes and widths • Incorrect ‘ConnectsTo’ lanes • General layout and structure of lane paths/geometries • Signal phases being reported as “dark” or “unavailable” • Correctness of the time remaining values • Inconsistency of the reported minTime and maxTime (ie. min greater than max) • Unexpected changes in minTime and maxTime • Accuracy of the reported phase vs the actual signal • Transmit rate of each message type
Pr oje c t Challe nge s • Device interoperability • Controller to RSU • RSU to OBU • OBU to OBU • MAP message creation and validation • Protected/permissive left turns • Application deployments • Security credentialing • Data • Limited fleet • Regional communications network • Technol hnology ogy r risk and S Spec ectrum um Uncer ertai taint nty
Phase 2 De ployme nt • Communications Scalable Broad deployment • ATC Signal Deployment Controller potential in Strategy • DSRC Radio Georgia
Phase 2 De ployme nt Phas hase 2: RT RTOP P – June une 2020 2020 GDOT Inves estm tment ent + USDO USDOT AT ATCM CMTD Grant 1,600 traffic signals in metro Atlanta • 185 ramp meter locations • Regional onal d depl ploy oyment ent • Not a pilot program: a deliberate inter-agency • deployment across the entire metro Atlanta region
Inte r ope r able E c osyste m Road W oad Weath eather Transit P t Prior ority ty GA Conne c te d V2V/V /V2I 2I Wor ork Z Zone one Ve hic le E c osyste m 0 Freight ght P Priority ty Preem empti ption on Regional onal inter erope operabi ability ty throu ough gh standar ndards ds-bas based, ed, non-pr propr oprieta etary technol nology ogy deploy oyments ents
Phase 2 De ployme nt Phas hase 2. 2.1: 1: RTOP – Fall all 2019 2019 Additional 600 of FY 2019 to be installed by Fall 2019 • 305 RSUs operational as of July 2019 • Connectivity on every major arterial in metro Atlanta • Open data stream to third parties also available • ADDITIONAL APPLICATIONS Preemption at select signals to Emergency vehicle improve emergency vehicle preemption response time Priority requests to signal Transit signal priority controllers for specific transit applications and routes Signal priority for freight vehicles Freight signal priority that are operating in cooperative platooning mode
ATCMTD 2018 Phase 2 De ployme nt Phase 2 Deployment Est. FY 2019 (600) FY 2020 (1000) RSU Equipment $780,000 $1,300,000 RSU Deployment $510,000 $850,000 RSU Configuration & Support $1,200,000 $2,000,000 ATCMTD OBUs (1000) - $1,000,000 TOTAL $2,490,000 $4,150,000 $6,640,000 • 1,600 Roadside units at $1,300 per device. Total: •RSU deployment at $850 per location. 654 RSUs to be operational •RSU configuration at $2,000 per device. by Fall 2019 •OBU costs at $1,000 per device (optional).
CV, AV, & CAV
Alan Davis, PE, PTOE Assistant State Traffic Engineer 404-635-2832 aladavis@dot.ga.gov
