Dynamic Light – Final Conference , Germany 26 th – 27 th March 2019 Wismar Dynamic Light – Implementation of Dynamic Lighting Pilot System in Town of Čakovec Medjimurje Energy Agency Ltd. MENEA / Town of Čakovec Alen Višnjić, M.Sc. / Slobodan Veinović

BASIC INFORMATION Project partners involved PP15 Town of Čakovec - investor Pilot investment successfully implemented PP4 MENEA – technical support TAKING COOPERATION FORWARD 2

BASIC INFORMATION The Town of Čakovec North Croatia • Bordering Slovenia and Hungary • • 15,200 inhabitants • Area of 10 km 2 TAKING COOPERATION FORWARD 3

PREPARATORY STEPS FOR THE PILOT IMPLEMENTATION Field survey of current state of public lighting – Stakeholder analysis comparison with Energy audit Area functionality – land use and zoning Strategy of the public GIS – based Action plan of lighting database the public modernisation developed for lighting and decrease two districts modernisation of light in the Town of in the Town of pollution in Čakovec Čakovec the Town of Čakovec TAKING COOPERATION FORWARD 4

PREPARATORY STEPS FOR THE PILOT IMPLEMENTATION Planning of Analysis of the Analysis of the intelligent light global lighting specific lighting concepts for the situation situation pilot area TAKING COOPERATION FORWARD 5

PILOT AREA IN THE TOWN OF ČAKOVEC „Ring Čakovec” - Ivan Mažuranić Street, Eugen Kvaternik Square, Otokar Keršovani Street, Vladimir Nazor Street, Vukovar Street, Zrinski-Frankopan Street and Toma Masaryk Street TAKING COOPERATION FORWARD 6

PILOT INVESTMENT – TOWN OF ČAKOVEC Hiring external experts Coordination with external experts and Town of Čakovec Market research Creating project documentation Final meeting with Town of Čakovec regarding project documentation Technical support to Town of Čakovec for process of public procurement TAKING COOPERATION FORWARD 7

PILOT INVESTMENT – TOWN OF ČAKOVEC Intelligent light concept Current geometry of the streets and lightning infrastructure LED luminaires System for control and management of public lighting Wireless communication Weather sensors (rain and fog) TAKING COOPERATION FORWARD 8

PILOT INVESTMENT – TOWN OF ČAKOVEC Technical framework – Technical framework – lumminaires control and management system requirements TYPE 1 TYPE 2 TYPE 3 • 160 W • 130 W • 120 W Cloud based platform • 67 pieces • 75 pieces • 8 pieces • 3000 K • 3000 K • 3000 K • ≥90 lm/W • ≥110 lm/W • ≥110 lm/W • 50,000 h • 50,000 h • 50,000 h Wireless • IK 08, IP 66 • IK 08, IP 66 • IK 08, IP 66 communication • From -25°C • From -25°C • From -25°C to 35°C to 35°C to 35°C Openness of the system to other manufacturers TAKING COOPERATION FORWARD 9

PILOT INVESTMENT – TOWN OF ČAKOVEC Schreder Axia 2.2 OWLET IoT Rain and fog weather sensors TAKING COOPERATION FORWARD 10

PILOT INVESTMENT – TOWN OF ČAKOVEC Implementation of works TAKING COOPERATION FORWARD 11

PILOT INVESTMENT – TESTING REGIMES OWLET IoT interface – regime No.1 TAKING COOPERATION FORWARD 12

PILOT INVESTMENT – TESTING REGIMES OWLET IoT interface – regime No.2 TAKING COOPERATION FORWARD 13

PILOT INVESTMENT – FIELD TESTING Toma Masaryk Street 40% 70% TAKING COOPERATION FORWARD 14

PILOT INVESTMENT – FIELD TESTING TAKING COOPERATION FORWARD 15

PILOT INVESTMENT – TOWN OF ČAKOVEC Measurements Before After TAKING COOPERATION FORWARD 16

PILOT INVESTMENT – TOWN OF ČAKOVEC Comparative overview and expected results Before After Number of luminaires 160 150 Installed power kW 58.23 19.86 Annual consumption (kWh) 238,743.00 81,438.30 Annual costs (€/kWh) 28,070.00 9,574.50 CO 2 emissions (tCO 2 /a) 89.77 30.60 TAKING COOPERATION FORWARD 17

PILOT INVESTMENT – TOWN OF ČAKOVEC Financial overview Actual investment Return of Annual savings • 79.816,66 € (VAT investment • 18.500,00€ included) • 4,3 years TAKING COOPERATION FORWARD 18

PILOT INVESTMENT – TOWN OF ČAKOVEC Satisfaction of end users of pilot area Informed about light Awareness on Dynamic Light pollution concept? pilot installation? 19% 26% 74% 81% Yes No Yes No Better illumination with LED lighting? 14% 86% TAKING COOPERATION FORWARD 19 Yes No

PILOT INVESTMENT – TOWN OF ČAKOVEC Aerial view TAKING COOPERATION FORWARD 20
