CS5530 Mobile/Wireless Systems Using Google Map in Android Yanyan Zhuang Department of Computer Science http://www.cs.uccs.edu/~yzhuang UC. Colorado Springs CS5530 Ref. CN5E, NT@UW, WUSTL

Setup • Install the Google Play services SDK o Tools > Android > SDK manager CS5530 2 Ref. CN5E, NT@UW, WUSTL

Create a Google Maps project • Select Google Maps Activity in the 'Add an activity to Mobile' dialog • When build finished, Android Studio opens google_maps_api.xml and MapsActivity.java o google_maps_api.xml contains instructions on getting a Google Maps API key before you try to run the application. CS5530 3 Ref. CN5E, NT@UW, WUSTL

Get a Google Maps API key • Apps need an API key to access Google Maps servers The key is free. You can use it with any of your applications that call the Google Maps o Android API, and it supports an unlimited number of users 1. Copy the link in google_maps_api.xml, paste it into browser 2. Follow the instructions to create a new project on the Google API Console or select an existing project 3. Create an Android-restricted API key for your project 4. Copy the resulting API key, go back to Android Studio, and paste the API key into the <string> element in google_maps_api.xml May use the same key for more than one app CS5530 4 Ref. CN5E, NT@UW, WUSTL

Run the app • By default, the XML file that defines the app's layout is at res/layout/activity_maps.xml • The simplest way to see your app in action is to connect an Android device to your computer • You can use Android Emulator to run app o When choosing an emulator, use Android 4.2.2 or higher, and be careful to pick an image that includes the Google APIs, or the application will not have the runtime APIs in order to execute CS5530 5 Ref. CN5E, NT@UW, WUSTL

Run the app (2) • You should see a map with a marker positioned over Sydney, Australia o If you don't see a map, check that you've added an API key as described o Check the log in Android Studio's Android Monitor for error messages about the API key o Different ways to get the API key https://developers.google.com/maps/documentation/android- api/signup CS5530 6 Ref. CN5E, NT@UW, WUSTL

Understand the code • AndroidManifest.xml o <meta-data android:name="com.google.android.geo.API_KEY" android:value="@string/google_maps_key" /> (generated for you) • activity_maps.xml o <fragment> element to your activity's layout file o Defines a SupportMapFragment to act as a container for the map and to provide access to the GoogleMap object <fragment name="com.google.android.gms.maps.SupportMapFragment" android:layout_width="match_parent" android:layout_height="match_parent"/> CS5530 7 Ref. CN5E, NT@UW, WUSTL

Understand the code • What is a fragment? o A Fragment represents a behavior or a portion of user interface in an Activity o Can combine multiple fragments in a single activity to build a multi-pane UI and reuse a fragment in multiple activities o Can think of a fragment as a modular section of an activity, which has its own lifecycle, receives its own input events, and which you can add or remove while the activity is running } sort of like a "sub activity" that you can reuse in different activities CS5530 8 Ref. CN5E, NT@UW, WUSTL

Understand the code • MapsActivity’s onCreate() o @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); // set the layout file as the content view setContentView(R.layout.activity_maps); // get a handle to the map fragment SupportMapFragment mapFragment = (SupportMapFragment) getSupportFragmentManager().findFragmentById(R.id.map); // use getMapAsync() to register for map callback (when map is ready) mapFragment.getMapAsync(this); } CS5530 9 Ref. CN5E, NT@UW, WUSTL

Understand the code • Implement OnMapReadyCallback interface & override onMapReady(): set up the map when GoogleMap object is available public class MapsActivity extends AppCompatActivity o implements OnMapReadyCallback { // OnCreate() method here: as described on last slide @Override public void onMapReady (GoogleMap googleMap) { // Add a marker in Sydney, Australia, and move map's camera LatLng sydney = new LatLng(-33.852, 151.211); googleMap.addMarker(new MarkerOptions().position(sydney) .title("Marker in Sydney")); googleMap.moveCamera(CameraUpdateFactory.newLatLng(sydney)); } } CS5530 10 Ref. CN5E, NT@UW, WUSTL

Understand the code • By default, the Google Maps API displays the content of “title” when the user taps a marker o googleMap.addMarker(new MarkerOptions().position(sydney) .title("Marker in Sydney")); • There's no need to add a click listener for the marker if you’re happy with the default behavior CS5530 11 Ref. CN5E, NT@UW, WUSTL

Summarize • The basic steps for adding a map (You only need to do this once) Get Google Play Service SDK, obtain a 1. key and add the required attributes to Android manifest Add a <fragment> element to the layout file for the Activity 2. Call getMapAsync() on the fragment to register the callback 3. Implement the OnMapReadyCallback interface and use 4. the onMapReady(GoogleMap) callback to get a handle to the GoogleMap object CS5530 12 Ref. CN5E, NT@UW, WUSTL

Map Types • Normal • Hybrid • Terrain • Satellite • None o GoogleMap map; ... // Sets the map type to be "hybrid" map.setMapType(GoogleMap.MAP_TYPE_HYBRID); CS5530 13 Ref. CN5E, NT@UW, WUSTL

Markers • You can customize markers by changing the default color, or replacing the marker icon with a custom image o Info windows can provide additional context to a marker • Markers are objects of type Marker o Added to map with the GoogleMap.addMarker(markerOptions) method o Receive click events by default, and are often used with event listeners to bring up info windows o Previous example } googleMap.addMarker(new MarkerOptions().position(sydney).title("Marker in Sydney")); CS5530 14 Ref. CN5E, NT@UW, WUSTL

Markers • Some other examples o Marker marker = googleMap.addMarker(new MarkerOptions().position(new LatLng(-34, 151))); o marker.revmote(); o Setting a marker to be invisible, and transparency Marker marker = googleMap.addMarker(new MarkerOptions().position(new LatLng(-34, 151)). visible(false).alpha(0.8f) ); CS5530 15 Ref. CN5E, NT@UW, WUSTL

Markers • Once a marker is created, you can change its property o marker.setAlpha(1.0f); o marker.setVisible(true); o marker.setPosition(new LatLng(-34, 151)); • Why marker visibility? o Faster to make an invisible marker visible, than creating a new marker • Show information o googleMap.addMarker(new MarkerOptions().position(sydney).title("Sydney").snippet(“Population: 4.5 million in 2015”)); CS5530 16 Ref. CN5E, NT@UW, WUSTL

Markers • Respond to click events o Activity must implement GoogleMap.OnMarkerClickListener o Set a listener for marker click } @Override public void onMapReady(GoogleMap googleMap) { …... mMap.setOnMarkerClickListener(this); } o Implement callback function onMarkerClick() CS5530 17 Ref. CN5E, NT@UW, WUSTL

Markers • Respond to click events o Implement callback function onMarkerClick() } @Override public boolean onMarkerClick(final Marker marker) { if (marker.equals(myMarker)) { Toast.makeText(this, marker.getTitle() + " has been clicked!", Toast.LENGTH_LONG).show(); } return false; } CS5530 18 Ref. CN5E, NT@UW, WUSTL

Toasts • A toast provides simple feedback about an operation in a small pop-up o Only fills the amount of space required for the message and the current activity remains visible and interactive o Toasts automatically disappear after a timeout • Instantiate a Toast object with makeText() method o 3 parameters: the application Context (usually this), the text message, and the duration for the toast o Toast.LENGTH_SHORT and Toast.LENGTH_LONG CS5530 19 Ref. CN5E, NT@UW, WUSTL

Toasts • Example o Context context = getApplicationContext(); CharSequence text = "Hello toast!"; int duration = Toast.LENGTH_SHORT; Toast toast = Toast.makeText(context, text, duration); toast.show(); o Toast.makeText(context, text, duration).show(); CS5530 20 Ref. CN5E, NT@UW, WUSTL

Toasts • Positioning your Toast o A standard toast notification appears near the bottom of the screen, centered horizontally o You can change this position with the setGravity(int, int, int) method: a Gravity constant, an x-position offset, and a y-position offset o If the toast should appear in the top-left corner } toast.setGravity(Gravity.TOP|Gravity.LEFT, 0, 0); } If you want to nudge the position to the right, increase the value of the second parameter. To nudge it down, increase the value of the last parameter CS5530 21 Ref. CN5E, NT@UW, WUSTL

Select Current Place • Create a Google API client o Also known as the Google API client: connect with fused location provider and Google Places API } private GoogleApiClient mGoogleApiClient; CS5530 22 Ref. CN5E, NT@UW, WUSTL
