Air irCare Automation USP797 / USP800 Monitoring Systems Field Configurable & Flexible Monitoring Options for Existing Cleanrooms and New Construction
ACC1005 Single Room Monitoring AC Power Comm Jct Box Connction Room Pr, T/ RH CAT5e cable connection FFU Control and Monitoring optional Wall Mount Twisted pair and differential tubing ACC1005 Console Monitor & Alarm • Hi/Lo limits on sensors • Buzzer alarm on Console • Alarm relay output • Backlight flashing on alarm
ACC1005 Single room Monitoring/Control Single Room – Monitoring Pkg Console- Pr + T + RH Wall mount T/RH sensor Monitor & Alarm • Hi/Lo limits on sensors • Buzzer alarm on Console Wall mount • Alarm relay output ACC1005 Console • Backlight flashing on alarm FFU control for EC – incl. DM01 Junction Box – SMPS, Comms, Pr Sensor Add VariPhase for AC FFU 14A/ 20A VariPhase ADD AC FFU Control VariPhase Mounts in AC Path
Cleanroom Monitoring, Data-log and Alarm KIT Temperature, Relative Humidity, Differential Pressure 1-3 Room Systems ACC7019 KIT ACC7039 KIT 2.4” Graphic 3.5" color Screen touchscreen Remote Data Access - PC E-mail Alarm Notification KIT Enclosure for Console and Sensors 3 diff pressure sensors, 1 Temperature/humidity sensor Datalog and SD card storage (52 weeks) Alarm limits and alarm output (relay output) Temp & RH Combo Ethernet – Remote Access Remote Data Access - PC ACC7039 E-mail Alarm Notification Only Diff. Pressure
DSM01 - Dis istri ributed Sensor Module Pressure Sensor added here Room Mounted Temp/RH sensor Connects here Communication (twisted pair wiring) Card to capture sensor values (daisy chain connection) Ease of Installation/Use AC Power 1. Attach Pressure tubing to room location (Kit included) Adapter 2. Attach twisted pair wiring to room T/RH sensor 3. CAT5e Daisy chain connect J-Box to FFU network 4. Run AC power to Power Adapter
“ Ze Zeph phyr ” Monitoring & Control Deli Delivering all all you our monitorin ing nee needs with th the ease ease of of ad addin ing dis distr tributed sen sensor modules whic hich expands the sen sensor ors per per console, , red educe the nee need for or cu custom mon onitoring pac packages, , eli elimin inates s com omplex pa panel l bo box asse assemblie ies an and mor ore importantly ly reduces har hardware an and installation cos ost Zephyr r 4 Zep ephyr r 3 Zep ephyr r 2 Zep ephyr r 1 1 12.1” Color 7” Color 3.5” Color 4 room 20 room 6 room 12 room Up to 12 sensors Up to 60 sensors Up to 36 sensors Up to 18 sensors Console supplied In Steel Panel Graphic screen Data-Log Color Touchscreen Audible Alarm Alarm Relay Data-Log E-mail alarm notification ADD SENSORS PER ROOM AS NEEDED
Zephyr hyr 1 2-4 Room (50 FFU) Monitoring/Control Control /Monitor • 4Groups Graphic screen • Console in 50 FFU Units • Clock Calendar Set-back white steel • Remote relay set-back panel box • 2-4 rooms w Pr, T, RH monitor • Hi/Lo limits on sensors • Alarm relay output • Emergency Shut-Down • Data-Log (SD Card) • Backlight flashing on alarm FFU control for EC – incl. Add VariPhase for AC FFU Panel Box with Pressure sensor Wall mount and Room Control interface T/RH sensor 14A/ 20A VariPhase ADD AC FFU Control VariPhase Mounts in AC Path
Zephyr hyr 2 2-6 Room (100 FFU) Monitoring/Control Control /Monitor Color TouchScreen Console • 6 Groups in white steel panel box • 100 FFU Units • Clock Calendar Set-back • 2-6 rooms w Pr, T, RH monitor • Hi/Lo limits on sensors • Alarm relay output • Data-Log (SD Card) • Remote Data-log Access • Ethernet – e-mail notification • Audible Alarm • Backlight flashing on alarm FFU control for EC – incl. Panel Box with Pressure sensor Wall mount and Room Control interface Add VariPhase for AC FFU T/RH sensor 14A/ 20A VariPhase ADD AC FFU Control VariPhase Mounts in AC Path
Zeph phyr yr 3 2- 12 room -up to 120 FFU Monitoring/Control Control /Monitor • 7” Color Touchscreen In Medium White steel panel box Up to 12 Groups • Up to 200 FFU Units • Field Configure FFU Grouping • Clock Calendar Set-back • Remote Relay Set-Back • Up to 12 room Pr, T, RH • Hi/Lo limits on sensors • Alarm relay output • Emergency Shut-Down Relay • Data-Log (SD Card) • Remote Data-log Access • Ethernet – e-mail notification Panel Box with Pressure sensor Wall mount • Audible Alarm and Room Control interface T/RH sensor • Backlight flashing on alarm I/O Option Add remote set-back, alarm relay trip and emergency shut-down
Ze Zephy phyr r 4 4 2- 20 room - up to 200 FFU Monitoring/Control 12.1” Color Touchscreen in Large White Steel panel box Control /Monitor • Up to 20 Groups • Up to 200 FFU Units • Field Configure FFU Grouping • Clock Calendar Set-back • Remote Relay Set-Back • Up to 20 room Pr, T, RH • Hi/Lo limits on sensors • Alarm relay output • Emergency Shut-Down Relay Panel Box with Pressure sensor Wall mount • Data-Log (SD Card) and Room Control interface T/RH sensor • Remote Data-log Access • Ethernet – e-mail notification • Audible Alarm • Backlight flashing on alarm
Monitoring Systems Product Li Line-Up • Single Room - ACC1005 - w/ DSM01 + T/RH sensor • set alarm limits – audible alarm , flashing screen • 1-3 Room - All-in-One Panel Assembly • ACC7019 – Graphic Screen 1-3 Pressure sensors 1 T/RH sensor • Data-Log (SD Card) Alarm Relay output • ACC7039 – Color Touchscreen Screen 1-3 Pressure sensors 1 T/RH sensor • Data-Log, remote data download, e-mail alarm notification, audible alarm Zephyr Flex Line-up 6 Room Color (3.5”) 4 Room Graphic Up to 6 Rooms / 100 FFU Up to 4 Rooms / 50 FFU Up to 18 sensors Up to 12 sensors 1-3 SENSOR per Room DM01 + T/RH DM00 + T/RH 12 Room Color (7”) 20 Room Color (12”) Up to 12 Rooms / 120 FFU Up to 20 Rooms / 200 FFU Up to 36 sensors Up to 60 sensors
Cleanroom System – Facility Specific
Facility Specific Consoles 7” Color Touchscreen CUSTOMIZE to your unique facility? Require animated ceiling grid ? Adding complex sensors like Particle Counters ? 12.1” Color Touchscreen Need Dynamic (Automatic) Control of cleanroom? Want BMS information exchange ? Graphic Screen ACC7020, ACC7022 Color Touchscreen ACC7032 Animated Ceiling Grid – Color ACC7072 / ACC7152 Sensors/BMS etc. 5.7” - 7” ACC7052/ACC7072 12.1” ACC7152
Air irCare Automation USP797 / USP800 Monitoring Systems Contact: sales@aircareautomation.com Tel: (855) 234-9237 www.aircareautomation.com
