BR/BH/Hof 2009/D/11.11.2009 1

Worldwide locations of Trützschler Germany BR/BH/Hof 2009/D/11.11.2009 Subsidiaries: Production factories: Turkey • Mexico • Italia Germany • USA • Spain • Uzbekistan Brazil • India • China 2

Trützschler Nonwovens Group TNW Consists of  Truetzschler Nonwovens GmbH, Dülmen, Germany (formerly Erko-Trützschler)  Truetzschler Nonwovens GmbH, Egelsbach, Germany (formerly Fleissner)  Truetzschler Nonwovens GmbH, Bielefeld, Germany (formerly Bastian)  Trützschler Card Clothing Complete Technology for Nonwovens Lines  Fiber Opening, Blending, Web Forming,  Mechanical Needling  Binderbonding  Thermobonding BR/BH/Hof 2009/D/11.11.2009  Spunlacing  Winding  Finishing 3

Trützschler Nonwovens GmbH, Dülmen, Germany BR/BH/Hof 2009/D/11.11.2009 Location: Dülmen // Founded: 1993 // Employees: appr. 100 4 4

Trützschler Nonwovens GmbH, Egelsbach, Germany BR/BH/Hof 2009/D/11.11.2009 Location: Egelsbach // Founded: 1848 // Employees: appr. 250 5 5

R&D Center of TNW in Dülmen New opened in 2011 Erko Web Drafter EVST Erko Fiber Opening + Blending Erko Card 150 Erko Needle Loom ENL1 BR/BH/Hof 2009/D/11.11.2009 Erko Airlay Card EHLA Fleissner Belt Oven Erko Crosslapper EKL 439 6

R&D Center of TNW in Egelsbach Fleissner Throughair Bonding Erko Fiber Opening and Blending BR/BH/Hof 2009/D/11.11.2009 Fleissner AquaJet Truetzschler Card TC07H ERKO Card EWK 413 Fleissner Drum Dryer Fleissner Airlaid (Fluff Pulp) 7

Nonwovens in Hi-GrowthApplication Challenges and New Developments India Situation BR/BH/Hof 2009/D/11.11.2009 8

To have a sustained growth, India will require Investments to develop a strong support pillar-  GEOTEXTILE  FILTER  AUTOMOTIVE BR/BH/Hof 2009/D/11.11.2009 Source BCH

Emerging nations- China, Indonesia, Mexico, Turkey, Brazil, Russia, India Developed nations will be dependant on the emerging markets to take the opportunities available BR/BH/Hof 2009/D/11.11.2009 Source BCH

MEXICO In Mexico, the toll roads are being re-privatised and Mexican market players – construction companies, operators, banks and institutional investors – are enthusiastically looking for these investment opportunities, often in partnership with foreign investors. INDIA The government has announced in huge amounts to support and construct the infrastructure. Discussed in detail in following slides. BR/BH/Hof 2009/D/11.11.2009 Source BCH

CHINA China alone plans to spend $730 billion into infrastructure sector over the next three to five years, in a bid to stimulate domestic demand; to increase connectivity between towns & villages China plans to almost double its investment in railways to about 87.9 billion U.S. dollars a p art of this will be used to build a total of 5,148 km of new RUSSIA rails, To create economic activity, Russia plans to invest $6 trillion over the next 20 years in order to connect Europe and Western China and allow for the BR/BH/Hof 2009/D/11.11.2009 development of new territories and mineral deposits, producing a positive economic effect. Source BCH

Nonwoven Geotextiles:  The separation of water and land is one of the important requirements of mankind  Geotextiles manufactured by using nonwoven technology are mainly used for the application like separation and filtration.  Nonwovens are classified based on the way the fibres are bonded together  Thermally bonded  Chemically bonded  Mechanically bonded  Spun laid and spun bonded  For Geotextiles, needlepunch technology is in the forefront BR/BH/Hof 2009/D/11.11.2009 of production Source BCH

Geotextiles are textile structures such as fabrics, mesh materials, nonwovens, nets, and composites which are deployed in various areas of underground construction for separation, support, protection, filter and/or drainage functions. BR/BH/Hof 2009/D/11.11.2009 Source BCH

Geotextiles- Applications vis-à-vis Functions Application Function Roads Reinforcement, Separation, Filtration Railways Reinforcement, Separation, Filtration Foundations Reinforcement, Separation, Filtration Drainage Systems Separation, Drainage, Filtration Erosion Control Reinforcement, Separation, Filtration Basins & dams Reinforcement, Protection, Separation, Filtration Canals Reinforcement, Protection, Separation, Filtration Tunnels & underground Protection works BR/BH/Hof 2009/D/11.11.2009 Solid waste Reinforcement, Protection, Separation, Filtration Liquid waste Reinforcement, Protection, Filtration Source BCH

Different technology for manufacturing Geotextiles Technology General functions of geotextiles Warp Knitted Woven Barrier function Non Woven  Produced by  Continuous filament  Monofilament, interloping one or more staple fiber multifilament slit Surface erosion control  Fabric and Raw fibres, yarns, filaments  Base fibres is film fabricated material or other elements.  Base fibres is polyester, PP& PE Polyester, Jute Protection  Warp knitted  Needle Punched  Weaving  Warp knitted with  Thermal bonded  Process Weft insertion  Spun bonded Separation  180-200 GSM  330 GSM  340 GSM  Commonly used GSM Filtration  Niche applications in  Reinforcement,  Sub-grade golf course fields, geo separation, reinforcement, nets for Rock fall Embankment are embankments, woven  Applications protection major applications geogrids for ballistic BR/BH/Hof 2009/D/11.11.2009  Geogrids are mainly  Roads, highways as reinforcement Drainage made up of knitted separation, paving geotextile fabric Reinforcement Source BCH

Applications for Geotextiles BR/BH/Hof 2009/D/11.11.2009 Source BCH

Roofing membranes with PES nonwovens carrier fabric BR/BH/Hof 2009/D/11.11.2009

Nonwoven Geotextiles: Application of Nonwoven needle punched Geotextiles :  Separation  Filtration  Barrier fabrics for roads, rails, erosion control and irrigation Properties for Geotextiles :  Tenacity  Elongation  Accuracy in terms of weight distribution BR/BH/Hof 2009/D/11.11.2009 Source BCH

Geotextile Lines Applications for Geotextiles Waterways Liquid waste Solid Waste Damms Anti-Erosion Ground Support Streets Railway BR/BH/Hof 2009/D/11.11.2009 Draining Tunnels Installations Source BCH

Geosynthetics  Material used with soil for civil engineering applications  Geotextiles are textile materials manufactured by using synthetic fibres like  Polyester  Polyamide  Polypropylene  Polyethylene  Geotextiles are non-visible, permeable fabrics used for dams embarkment etc. BR/BH/Hof 2009/D/11.11.2009 Source BCH

Requirements of Geotextiles:-  Choice of fibre type and tenacity are determining factors for the product tenacity  Fibre orientation at the card as the starting point of product property  Fleece orientation after the crosslapper ( laying Angle with condensed web )  Felt stability in needling process  Control during heat setting process Benefits of Truetzschler Nonwovens Line  Less Draft : Less Shrinkage  More control on the fibre orientation BR/BH/Hof 2009/D/11.11.2009  Constant control over the elongation Source BCH

Properties for Geotextiles between 100 – 200 g/m² such as :  Tenacity  Elongation  Production  Accuracy in terms of Weight Distribution blend of fibres:  PP 4,4 – 6,7 dtex 90 -120 mm  High tenacity min. 4,7 cN/dtex BR/BH/Hof 2009/D/11.11.2009 Source BCH

The Fibre Choice as the Key to achieve the Properties  By the Drafting of the Fibre the Tenacity will be influenced  This Tenacity determines the Tenacity of the Product significantly and thus the Product Properties  This Treatment requires a very accurate Heat Setting if applied BR/BH/Hof 2009/D/11.11.2009  The precise Dosing and Blending of different fibre types is essential to achieve „designed“ Product Properties

Geotextile / Roofing Lines Carded and Needle Punched BR/BH/Hof 2009/D/11.11.2009 Carded with Spunlace Spunbond and Needle Punched 25

Geotextiles- Key Advantages • Increasing life of the structure- Structures made more reliable • Reduces cost in long term- lowers frequency of maintenance BR/BH/Hof 2009/D/11.11.2009 Source BCH

Indian Infrastructure- Opportunities Key Sectors Estimated investments 2008-2012 (US $ bn) Airports 8 Irrigation 54 Ports 18 Railways 63 Roads 76 Water Supply & 49 BR/BH/Hof 2009/D/11.11.2009 Sanitary Source- Government of India, Committee on Infrastructure

India… developing to developed • India is the second fastest growing economy with an annual growth rate of 8-9% in the last three years & can sustain a 7- 8 per cent growth rate till 2020 • Will overtake UK, Germany, Japan and finally the US before 2050, to emerge as the second-largest economy after China • Is witnessing the highest rate of returns on investments India: 19.33% ; China: 14.25% BR/BH/Hof 2009/D/11.11.2009 Motivating for investors and active players!!! Source BCH
