UNIX Basics

UNIX Basics CIS 218 Oakton Community College

slide-2
SLIDE 2

History

  • UNIX was invented in 1969 at AT&T Bell Labs
  • Ken Thompson and Dennis Ritchie are credited as

the original architects and developers of “C”.

  • Written in the C programming language in 1973
  • Resold under UNIX System License (USL)
  • Current USL version SystemV R4
  • Different commercial flavors: Solaris (Sun), AIX

(IBM), Irix (SGI), HPUX (Hewlett Packard), SCO

  • Academic version – BSD (Mac OS X base)
  • UNIX Variants – LINUX,
  • UNIX “ports” – Android, MAC OSX
slide-3
SLIDE 3

Unix Design

  • Modularity

– Each part of the Unix system is a system unto itself

  • printing, networking, mail, file management,

accounting, etc. – Many Unix systems can be run in different modes. This allow for a certain set of modules to be run based on usage (workstation, server). – UNIX utilities are independently developed packages

UNIX Design

slide-4
SLIDE 4

UNIX Layers

slide-5
SLIDE 5
  • UNIX – everything is a file
  • UNIX is case sensitive, DOS is not
  • UNIX searches $PATH for executables, DOS starts

in current directory, then PATH.

  • UNIX is multi-user, DOS is not. Windows is (kind
  • f)
  • UNIX GUI sits “on top of” the OS - same as

Windows thru ME). This changed After NT.

  • UNIX directory has one starting point – root “/”.

Windows has multiple A:, C:, D: etc.

UNIX Versus DOS/Windows

slide-6
SLIDE 6
  • DOS

UNIX Command Description

  • CD

pwd Display current directory

  • CD \

cd / Moves to the root directory

  • CD ..

cd .. Moves up one level in the directory structure

  • CD path

cd path Sets the current directory to a new directory

  • CHKDSK

du Displays disk usage

  • CLS

clear Clear the screen

  • COMMAND

sh, csh .. Start a new shell (command processor)

  • COMP

cmp Compares two files and shows the difference

  • COPY

cp Copy a file

  • DATE

date Displays the date

  • DEL or ERASE

rm Deletes a file

  • DELTREE

rm -r Deletes a directory tree ( CAREFUL ! ! ! )

  • DIR

ls -l Lists the directory in a long format

  • DIR /W

ls Lists the directory in a short format

  • ECHO

echo Displays a message or a variable

  • EXIT

exit End a shell

  • FC

diff Displays differences between two files

  • FIND

grep Displays lines matching a given pattern

  • HELP

man Display information about a command

  • MD or MKDIR

mkdir Creates a directory

  • MORE

more Displays text a page at a time

  • MOVE

mv Moves a file

  • PRINT

lpr Prints a file

  • RD or RMDIR

rmdir Removes a directory

  • REN

mv Renames a file

  • SET

set Sets a variable to a given value

  • SORT

sort Sorts a data

  • TIME

date Displays the time

  • TYPE

cat Displays a file

UNIX Versus DOS/Windows

slide-7
SLIDE 7

Shells

  • Shell – “sh” original interface to UNIX
  • Bourne Shell added some desirable features

but has different syntax for some things

  • Newer Bourne Shell variants are Korn Shell

(ksh) and Born Again Shell (bash)

  • C Shell – C program language syntax, tcsh,
  • Perl – Program Extract and Reporting

Language

  • Some systems allow user to chose which

shell you prefer with “chsh”. The full path to the shell must be given

slide-8
SLIDE 8

The Shell

  • When you log in to interact with UNIX, you see a

“shell prompt” ($ or %)

  • A “word” is a text string separated by white

space – space, Tab or IFS

  • The shell is a program that runs constantly and

executes the commands you give it

  • A command is the first “word” on a line. All

following words are command line parameters

  • Commands terminators: “<LF>” – Enter or

Return, “;”, “|”, “>”

slide-9
SLIDE 9
  • You interact with the Unix by entering commands

thru thee shell. The line is parsed as text sepaated by whitspace caracters into words or tokens. The first word is always a command.

  • The basic form of any Unix command is:

Command Option(s) Argument(s)

  • Most commands provide integral help or on-line

Manual (man page)

  • Options or flags modify the way that a command
  • works. They usually consist of a hyphen followed by

a single letter.

UNIX command line

slide-10
SLIDE 10
  • d: Directory - holds other files or directories.
  • -: Normal Files

Text files - text that is “human readable”. Binary files - executable files

  • l: Link - allows space efficient copying of

files/directories.

Symbolic or “soft” - may span file systems. Hard - is indistinguishable from the original file/directory.

  • .: Hidden File - any file that begins with a “.” (dot).
  • c,b: Character or Block Special Files – hardware

interface.

  • “virtual” files – pipes, semaphores, sockets.

Unix file types (ls –l)

slide-11
SLIDE 11

Files and Directories

  • UNIX uses a single hierarchy to store files

beginning with root “/”

  • Files are a named collection of bytes
  • Directories contain other files (or not)

File1 juliana Project File2 File3

slide-12
SLIDE 12

Basic Directory Terms

  • Home directory (~ ) - top of your file tree:
  • Root directory (/ ) - top of a file tree:
  • Current directory (.) - directory you’re in now

(pwd)

  • Dot (.) - current directory
  • Dot-dot (..) - parent of current directory
  • Path - Where to find file or directory

– Absolute path: /fs/scd/home0/juliana/myfile – Relative path: ./myfile

  • “Standard files” – STDIN, STDOUT, STDERR
slide-13
SLIDE 13

Managing Files and Directories

  • cd - change directories (built into shell)
  • pwd – present working directory
  • mkdir - creates a directory
  • rmdir - removes a directory (must be empty first)
  • rm myfile1 - remove a file
  • rm -fr - removes directory and everything below
  • touch <filename> - creates an empty file
  • cat <filename> - displays a file on screen
  • more <filename> - to see a screenful at a time
  • mv myfile1 myfile2 - renames (moveas) a file
slide-14
SLIDE 14

Tar and Compress

  • Tar stands for “tape archive” but is more often used to gather

files into one bundle. Equivalent of a ZIP file, without the compression.

  • cd to the directory above the one you want to archive

tar cvf - diry_name > diry.tar

  • To “list” the archive, use

tar -xvf diry.tar

  • To “untar” the archive, use

tar -xvf diry.tar

  • Compressed files take up less space. To compress a tar file, use

compress diry.tar or gzip diry.tar

  • To uncompress, use

uncompress diry.tar.Z or gunzip diry.tar.gz

  • Note equivalent gzip commands: zcat, zgrep, zmore, zdiff
slide-15
SLIDE 15

File Permissions

  • You “own” your files and directories
  • user-group-other read/write/execute permissions
  • rw-r--r-- 1 jsmith staff 164870 27 Feb 17:58 6.bmp
  • rw-r--r-- 1 jsmith staff 164870 27 Feb 17:57 5.bmp
  • + to add, - to remove alphabetic permissions
  • r=4, w=2, x=1 so rwx: 4+2+1=7 for numeric
  • chmod command changes permissions

chmod 604 6.bmp chmod g-rw 6.bmp

  • rw----r-- 1 jsmith staff 164870 27 Feb 17:58 6.bmp
slide-16
SLIDE 16
  • Access rights on files.

r : indicates read permission (or otherwise), that is, the presence or absence

  • f permission to read and copy the file

w : indicates write permission (or otherwise), that is, the permission (or

  • therwise) to change a file

x : indicates execution permission (or otherwise), that is, the permission to execute a file, where appropriate

  • Access rights on directories.

r : allows users to list files in the directory; w : allows users to delete files from the directory or move files into it; x : allows users the right to access files in the directory (e.g. cd into directory), read files in the directory provided you have read permission on the individual files.

File Permissions

slide-17
SLIDE 17

Symbol Meaning u user g group

  • ther

a all r read w write (and delete) x execute (and access directory) + add permission

  • take away permission

File Permissions

slide-18
SLIDE 18

User Commands for Files

What’s in my directory?

  • ls

db5-24 nwade.txt schumacher5-19.txt kirsh5-12.txt nwade5-13a.txt sheu5-20.txt

  • ls -alt
  • rw-r--r-- 1 jsmith staff 712 24 May 09:12 db5-24
  • rw-r--r-- 1 jsmith staff 1660 12 May 12:12 kirsh5-12.txt
  • rw-r--r-- 1 jsmith staff 3610 11 May 08:16 ming.txt
  • rw-r--r-- 1 jsmith staff 2444 10 May 16:53 mingrep
  • Wildcard - * stands for any (# of) character(s)
  • Wildcard - ? stands for any single character
  • [abcde…] selection set, any single character within

the brackets

slide-19
SLIDE 19
  • wc - word, line, character, and byte count
  • echo - echo characters back (print)
  • sort - sort lines of a text file
  • uniq – remove consecutive duplicats lines
  • cut/paste/join – manipulate data by physical location in a record or file
  • sed – stream editor, vi commands in a batch file
  • awk – string manipulation
  • tr – translate from one character to another
  • strings – review a binary file for text
  • d – examine a file for binary contents
  • head, tail – display begin and end of a file
  • cat – copy to stdout
  • cp – copy a file

User Commands for Files

slide-20
SLIDE 20

Finding and Searching

  • diff – find differences between two text files
  • find - a tricky but useful command

find . -name myfile -print

find . -name ‘*name*’ –print –exec “cmd” {} \;

  • grep - stands for “general regular expression print”

Search all files for a pattern: grep -i “lightning system” * grep -v “lightning system” *

grep -c “gee whiz” *

slide-21
SLIDE 21
  • Wildcard characters can be used to represent many other

characters in listing filenames.

– Use them whenever you need to define a string of characters, such as a filename, for use with a command.

– Useful wildcards are:

* matches any characters, zero or more. ? match any single character. [...] matches any character in the enclosed list or range. Examples:

– ls *.txt # Lists all the files in the current directory # that have the extension .txt. – cat memo? # Concatenate files that start with “memo” # and are followed by any one character. – rm part[1-3] # Remove files: part1, part2 and part3

Wildcard characters

slide-22
SLIDE 22

Input/Output (I/O) and Redirection

  • By default, a terminal keyboard is the standard input file

(STDIN) from which to read in information

  • Terminal is also the standard output file (STDOUT) to

which information is sent from the command.

  • Input can be given from the command line, or from a file:

a.out < inputfile

  • Output goes to your screen, or you can “redirect” it to a

file: echo “hi there” > out.file

  • To append, use >>

echo “hi back at you” >> out.file

  • “here” document for inline stdin << EOF
  • Use the “tee filename” command to redirect out put to both

STDOUT and a file.

slide-23
SLIDE 23
  • “<& m” Duplicates standard input from file descriptor

m

  • “[n] >& m” Duplicates standard output or file

descriptor n if specified from file descriptor m i.e. 2>&1

  • “[n] <&-” Closes standard input or file descriptor n if

specified

  • “[n] >&-” Closes standard output or file descriptor n if

specified.

  • “|” or pipe (prior slide) is also redirection. It redirects

STDOUT from the preceding command to STDIN of the following command. The general term for the following command is called a filter as it modifies or filters the output of the preceding command..

Input/Output (I/O) and Redirection

slide-24
SLIDE 24

Pipes

  • You can string commands together into a single

command using pipes ( | ) ps | grep juliana - what am I running now

  • Save the results in a file:

“who | wc > usercount”

  • Used with file manipulation commands as “filters”

“who | wc” - count how many users on the system

slide-25
SLIDE 25

System Info Commands

  • System Uptime

uptime

  • What time is it?

date

  • Where is a command?

which ls whereis ls

  • How do I use a command?

man ls

slide-26
SLIDE 26

System Info Commands

  • Where am I?

pwd - print working directory cwd - current working directory

  • Who am I?

whoami

  • Who is on the system? What’s running?

who, w ps –ef, -aux

slide-27
SLIDE 27

More Useful Commands, cont.

  • passwd - change password
  • chsh – change default shell
  • lpr - print a file (printer at OCC)
  • history - (C shell builtin) - list of previous

commands

  • alias - create a pseudonym or shorthand for

a command (behaves differently for C versus Bourne shell)

slide-28
SLIDE 28

Editing - vi

  • Front end to ed
  • Universal among UNIX and it’s variants
  • vi somefilename (copies file into memory

buffer)

  • Three modes – command mode, text

mode(Esc), operator line(:) determines how keystrokes are interpreted by vi

slide-29
SLIDE 29
  • i – insert text
  • x – delete a character
  • r – replace a character
  • R – replace text
  • yy p – copy a line
  • dd – delete a line
  • /text – locate text
  • / - repeat last find
  • <Enter> or <Return> - ends a line
  • :wq – save results and quit (:wq! – force overwrite of file)
  • :q - quit (no save)
  • Navigation: arrow keys or HJKL

Editing – vi (commands)
