Turning the Lights On Where does our energy come from? Tyler - PowerPoint PPT Presentation

Turning the Lights On Where does our energy come from? Tyler Josephson Graduate Student at University of Delaware Chemical Engineering Presentation at Newark High School February 9, 2012 What do we use energy for? Where does it come from?


  1. Turning the Lights On Where does our energy come from? Tyler Josephson Graduate Student at University of Delaware Chemical Engineering Presentation at Newark High School February 9, 2012

  2. What do we use energy for? Where does it come from?

  3. The Big 3 • >80% of our energy comes from fossil fuels: – Coal – Petroleum – Natural Gas

  4. Coal

  5. Electricity Coal Petroleum Renewable Energy Nuclear Natural gas Hydroelectric Wind Geothermal Solar

  6. Inside a Coal Power Plant • http://www.tva.gov/power/coalart.htm

  7. Coal Use in the USA • Math Problem – unit conversions • The United States used 3.6 billion MW-hrs of electricity in 2009 • 50% of this electricity comes from coal • Coal has 6.67 kW-hrs of energy per kg • A coal power plant is typically 30% efficient • You can fit 120,000 kg of coal in a railcar • How many railcars of coal are used in 1 day? Sources: eia.gov for energy use, coal and railroad numbers from Wikipedia

  8. Coal Use in the USA • 20,000 railcars of coal per day • Coal is 10% ash by weight • 2,000 railcars of ash per day • 750,000 railcars of ash per year

  9. Coal Pros and Cons • Cons: – Ash – SO 3 → Acid rain – Mercury emissions – CO 2 → most emissions/energy produced • Pros: – Abundant supply – $$ - Cheapest energy source for electricity

  10. Petroleum

  11. Transportation Natural Gas Petroleum Renewable Energy Corn Ethanol Biodiesel

  12. Petroleum Sources Land Drilling Tar Sands Ocean Drilling

  13. A Petroleum Refinery http://science.howstuffworks.com/environmental/energy/oil-refining5.htm

  14. Where Do We Get It?

  15. Peak Oil? World Crude Oil Production The U.S. is running out, and eventually, the world will run out, too! Data from U.S. Energy Information Administration, www.eia.gov

  16. Petroleum Pros and Cons • Pros – Highest energy density – Most suitable fuel for transportation – Chemical feedstock • Cons – Expensive – Limited supply – CO 2 → 2 nd in emissions after coal – Oil spills

  17. Global Warming Images created by Robert A. Rohde / Global Warming Art

  18. The Big 3 • Coal • Petroleum • Natural Gas

  19. What does the future look like?

  20. Future of Energy • By 2050, global energy demand is expected to increase 40% from what it is today • We are going to live in a world that uses energy in a very different way than we do today Today 2050

  21. Future of Energy Transportation - Today Transportation – 2050? Natural Gas Natural Gas Petroleum Petroleum Renewable Energy Renewable Energy • Something big is going to happen in transportation fuels in the next 40 years

  22. Future of Energy Transportation - Today Transportation – 2050? Natural Gas Natural Gas Petroleum Petroleum Renewable Energy Renewable Energy • Fuel-efficient cars • More public transit • Expensive fuel means people drive less • More biomass-derived fuels • Electric cars or plug-in hybrids powered by electricity from natural gas or nuclear power

  23. What alternatives do we have? Alternative Electricity Heating Fuels/Chemicals Solar X X Nuclear X Biomass X X X Wind X Hydroelectric X Geothermal X Improvements X X X in Efficiency • Others?

  24. Future of Energy Electricity - Today Electricity – 2050? Coal Coal Petroleum Petroleum Renewable Energy Renewable Energy Nuclear Nuclear Natural gas Natural gas Coal Coal Petroleum Petroleum Renewable Energy Renewable Energy Nuclear Nuclear Natural gas Natural gas

  25. Future of Energy • To reduce pollution from coal and oil, reduce impact of global warming, create local, secure, stable sources of energy, we will need to: • Improve efficiency of alternatives • Reduce costs • Discover new alternatives • Advancements in science and engineering are critical for shaping the future of energy • YOU could be a part of the future of energy

  26. Questions?

  27. Image Credits • Lightbulb: http://dsmy2muqb7t4m.cloudfront.net/tuts/118_Lightbulb_Icon/32.jpg • Coal Train: http://transitionlummiisland.com/wp-content/uploads/2011/04/buffettt-coal-train.jpg • Gas burner flame: http://www.livetradingnews.com/wp-content/uploads/natural-gas_43.jpg • Oil Drums: http://www.amoilresources.com/wp-content/uploads/2010/09/Oil-drums-Company.jpg • Coal Power Plant: http://upload.wikimedia.org/wikipedia/commons/d/d6/Coal_power_plant_Datteln_2_Crop1.png • Petroleum Refinery: http://www.elpower.net/samson/images/refinery.jpg • World Oil Map: http://tkcollier.files.wordpress.com/2008/06/world-oil_31948a.jpg • Land Drilling: http://www.horizontaldrilling.org/horizontal-drilling.jpg • Ocean Drilling: http://static.guim.co.uk/sys-images/guardian/About/General/2011/7/13/1310579782034/Offshore-drilling- rig-wit-007.jpg • Tar Sands: http://www.myessentia.com/blog/wp-content/uploads/2011/09/TarSands.jpg • Refinery: http://static.ddmcdn.com/gif/oil-refining-diagram.gif • Peak Oil: http://upload.wikimedia.org/wikipedia/commons/thumb/c/c5/US_Oil_Production_and_Imports_1920_to_2005.png/250px- US_Oil_Production_and_Imports_1920_to_2005.png • Grand Prix: http://cdn.getauto.com/photos/2/156022/1c/1G2WP1213VF305423-1c.jpg • Gas Can: http://www.blitzusa.com/products/fuel/Containment/images/50805%201%20plus%20Self- %20Venting%20Gas%20Can.jpg • Graduated Cyliners: http://www.benmeadows.com/images/xl/KIMAX-Graduated-Cylinders-BEN-_i_LBD48808.jpg • Ruler: http://static.www.odcdn.com/pictures/us/od/sk/lg/279944_sk_lg.jpg • Natural Gas Drilling: http://geology.com/articles/oil-and-gas-investments/natural-gas-and-oil-drawing.jpg
