Toroidal Axion Haloscope Development at CAPP Harry W Themann - PowerPoint PPT Presentation

Toroidal Axion Haloscope Development at CAPP Harry W Themann Center for Axion and Precision Physics Daejeon, ROK LLNL-Microwave Cavity Workshop 2017 1/11/2017 Harry W Themann CAPP 1 Why Toroid? 2 Axion Power


  1. Toroidal Axion Haloscope Development at CAPP Harry W Themann Center for Axion and Precision Physics Daejeon, ROK LLNL-Microwave Cavity Workshop 2017 1/11/2017 Harry W Themann CAPP 1

  2. Why Toroid? 𝑏 ∝ 𝑅𝐷𝐢 2 π‘Š Axion Power 𝑄 β€’ Larger cavities, higher field magnets, preserve Q & C β€’ Larger cavities -> problem at higher frequencies β€’ Multiple Cavities (see SW Youn) β€’ What about Toroids? β€’ No endcaps, can I get something for nothing? β€’ With a toroidal magnet the 𝐢 field is, at least nominally, parallel to all conductive surfaces β€’ Lends itself to superconductive films? 1/11/2017 Harry W Themann CAPP 2

  3. Toroid Modes β€’ No pure TM or TE modes β€’ Inverse toroid aspect ratio 𝜍 0 = 𝑠 𝑆 β€’ Bicycle tubes are better than truck tubes β€’ 𝐹 field lines of desired mode similar to applied B field β€’ No mode crossings 1/11/2017 Harry W Themann CAPP 3

  4. Analytic Modes β€’ Cap and Deutsch lEEE Transactions on Microwave r Theory and Techniques Vol MTT-26,NO.7, JULY1978 β€’ Janaki & Dasgupta IEEE Transactions on Plasma Science, VOL. I X . NO. I . FEBRUARY 1990 𝑠 𝑆 β€’ Inverse toroid aspect ratio 𝜍 0 = β€’ J & D expand in 𝜍 0 R ∞ ∞ β€’ π‘ˆπ‘ "π‘šπ‘—π‘™π‘“" ∝ 𝑏=0 𝑏 𝑗 TM + 𝑐=0 𝑐 𝑗 TE β€’ As 𝑆 β†’ ∞ 𝜍 0 β†’ 0 π‘ˆπ‘ "π‘šπ‘—π‘™π‘“" 𝑐𝑓𝑑𝑝𝑛𝑓𝑑 π‘ˆπ‘ β€’ For the dimensions contemplated there are no degeneracies, no crossings β€’ We used simulation to verify this 1/11/2017 Harry W Themann CAPP 4

  5. Effective Volume B 2 VC B. R. Ko; Axion Dark Matter Workshop, Stockholm 1/11/2017 Harry W Themann CAPP 5

  6. Low Fringe Fields R = 200cm R = 50cm B avg = 5T 9 coils 1/11/2017 Harry W Themann CAPP 6

  7. Q Factor B. R. Ko; Axion Dark Matter Workshop, Stockholm 1/11/2017 Harry W Themann CAPP 7

  8. Assembly Concept 1/11/2017 Harry W Themann CAPP 8

  9. Assembly Concept 1/11/2017 Harry W Themann CAPP 9

  10. Assembly Concept 1/11/2017 Harry W Themann CAPP 10

  11. First Toroid β€œSUB” β€’ Driven by a desire to be able to mount in a cryocooler available to us β€’ R=4cm r=2cm 𝜍 0 = 0.5 β€’ Simulation verifies no mode crossing 1/11/2017 Harry W Themann CAPP 11

  12. Cappuccino β€œSUB” β€’ Early iteration of design β€’ Simulation β€’ Dimensions of SUB β€’ Dimensions of tune hoop β€’ Antenna sizes and shapes β€’ Antenna placement (we had them at angles in the beginning) 1/11/2017 Harry W Themann CAPP 12

  13. Design Challenges β€’ Three sections not necessary for this model but we decided to have a learning experience β€’ One challenge was to exert force to push ends together 1/11/2017 Harry W Themann CAPP 13

  14. Photo 1/11/2017 Harry W Themann CAPP 14

  15. CAD Pictures 1/11/2017 Harry W Themann CAPP 15

  16. First Look β€’ Coupling issues, cross talk with each other with hoop, sim vs data β€’ Best antenna shape/size, reality vs simulation β€’ Q factor β€’ Calculated 20 000 β€’ Alignment issues, best 6000 β€’ Indium β€œgaskets” were a failure β€’ Bagel cut achieved 20 000 w/o hoop β€’ The simulations predicted that the hoop must go upwards but doesn’t seem to matter 1/11/2017 Harry W Themann CAPP 16

  17. Finished Product 1/11/2017 Harry W Themann CAPP 17

  18. Q = 10,700 CF = 8.159GHz 1/11/2017 Harry W Themann CAPP 18

  19. B. R. Ko; Axion Dark Matter Workshop, Stockholm 1/11/2017 Harry W Themann CAPP 19

  20. Pictures 1/11/2017 Harry W Themann CAPP 20

  21. Future 500mm Major Radius β€’ Continue to develop flanging β€’ Scale up tuning β€’ Cryogenic ready β€’ Packaging β€’ Physical placement β€’ Placement WRT to cooling β€’ Cable routing β€’ Actuation routing 1/11/2017 Harry W Themann CAPP 21

  22. Conclusion β€’ We have a working toroidal cavity β€’ Learned a lot but this has also made us realize that there are some daunting challenges in front of us. β€’ CAPP LVP Hall is building momentum rapidly 1/11/2017 Harry W Themann CAPP 22

  23. BACKUP 1/11/2017 Harry W Themann CAPP 23

  24. Assembly Concept 1/11/2017 Harry W Themann CAPP 24

  25. Challenges 1/11/2017 Harry W Themann CAPP 25

  26. 1/11/2017 Harry W Themann CAPP 26

  27. 1/11/2017 Harry W Themann CAPP 27

  28. 1/11/2017 Harry W Themann CAPP 28

  29. B. R. Ko; Axion Dark Matter Workshop, Stockholm 1/11/2017 Harry W Themann CAPP 29
