Sustainability Sustainability Alyssa Dolher + Elenor Methven ARC 503

Sustainability For the purposes of this research, sustainability is the practice of implementing strategies to minimize building energy and environmental impact , preserve resources , and promote health . Defjnition Defjnition

Active Energy Strategies Passive Energy Strategies Using technology and additive building Using the building envelope and orientation elements to achieve reductions in energy to achieve reductions in energy use. use. Natural Thermal Solar Energy Bio PV Panels Solar Wind Reflective Roof GeoThermal Daylighting Ventilation Mass Storage Shading Energy Thermal Turbines

Water Resources Material Resources Reducing daily water demand by collecting, Selecting materials for building based on treating and reusing water that falls on the their contribution to landfjlls and global site. carbon dioxide levels. Low Embodied Renewable Pervious Water Bioswales Prefabrication Disassembly Compost Toilets Rain Barrels Energy Resources Surfaces Treatment

Smart Growth Minimizing Disturbance Planning for the increased density of the Mitigating the byproducts of building on the urban environment to minimize destruction site by preserving existing wind and water of green fjelds patterns. Construction Floating Balancing Waste Foundations Cut and Fill “Right Size” Brownfield Zoning for Designing for Infrastructure Housing Sites Density Redevelopment

Promoting Health Introducing initiatives to promote healthy lifestyles and healthy buildings through lifestyle changes, as well as air and water quality measures. Agriculture/planting Water Quality Low VOCs and Air Quality

Precedents Precedents

Hammerby Sjostad White Arkiteckter Stockholm, Sweden

Public transit used for Community was constructed on a commuting. previous hazardous waste site. Waste is burned to create Water is treated and recycled energy. within the community

The Great Wall of Western Australia LUIGI ROSSELLI North Western Australia

High Thermal Mass takes Large southern overhangs prevent advantage of cool desert nights. direct solar gain. Abundant Local Materials Public and private greenspaces were used . encourage interaction.

Beddington Zero Energy Development BILL DUNSTER London, England

Solar panels on the units feed the Public transit and pedestrian onsite electrical grid. travel are encouraged. Greywater is treated and Tree Waste is brought in from a local reused for irrigation lumber company to heat units.

Regen Villages EFFEKT Almere, Netherlands

Solar panels on the units feed the Agriculture and Aquaponics onsite electrical grid. Greywater is treated and Waste is converted to energy reused for irrigation in biogas plant.

Grow Community DAVIS STUDIO A&D Bainbridge, Washington

Local waste is converted to Greywater is treated and bioenergy reused for irrigation Solar Panels are installed on Site was chosen for its each unit. proximity to transit

Applications Applications

650 98 225 80 gallons a day square feet kwh/month square feet of windows exterior watering, dishwasher, washing machine (13.5 kwh/mo cooling) Typical House (per person)

60 400 250 50 square feet of gallons a day square feet kwh/month +25 windows -38 -250 -60% (2.93 kwh/mo cooling) Typical Tiny House

30 60 22 400 gallons a day kwh/month square feet of square feet -107% windows -250 -38 -228 composting toilet Energy Effjcient Tiny House

Location Based Strategies Off grid energy and water active and passive energy water quality minimal disturbance smart growth air quality local material resources local materials public transportation healthy environments active and passive energy RURAL SUBURBAN URBAN

Designers’ Toolbox Active Strategies Water Preservation Smart Growth Promoting Health Passive Strategies Resource Preservation Minimizing Disturbance

THERMAL CAPACITY: Thermal Mass specifjc heat X density X thickness Material Specific Heat Density Thickness High thermal mass walls absorb and hold heat (BTU/lbºF) (lb/ft³) (FT) during hot days, reducing indoor temperature Concrete .239 124.85 Brick .191 106.13 fmuxuations. Green Globes requires walls with a Wool Batt Insulation .239 1.56 Rigid Insulation .310 1.56 heat capacity of 5 BTU/ft² ºF and gives maximum (XPS) Concrete Block .239 143.5 points for walls with 7 BTU/ft² ºF or higher. Air .239 .076 Sheathing .322 31.8

Designers’ Toolbox Active Strategies Water Preservation Smart Growth Promoting Health Passive Strategies Resource Preservation Minimizing Disturbance

Calculate Length: Bioswales Flow rate*540 seconds (9 minutes) For an unconnected bioswale, the fmow rate Calculate Flow Rate: (C*I*A) should be below 1 ft/s and the swale must be large enough to accommodate the 100 year I = inches per hour = 4 (North Carolina av) storm. Bioswales are usually trapezoidal, C = (.95*%impervious surface) + (.30*%pervious surface) with a minimum width of 4ft and a maximum A = area in acres (multiply SF by .000023) width of 8ft.

Designers’ Toolbox Active Strategies Water Preservation Smart Growth Promoting Health Passive Strategies Resource Preservation Minimizing Disturbance

Brownfjeld Sites Brownfjeld sites are contaminated sites from industrial or hazardous waste. Repairing them prevents voids in the urban fabric. 1 acre of rehabilitated brownfjeld sites can Zidell Yards save up to 4.5 acres of greenfjelds. Oregon

Designers’ Toolbox Active Strategies Water Preservation Smart Growth Promoting Health Passive Strategies Resource Preservation Minimizing Disturbance

Volatile Organic Compounds The Living Building Challenge requires operable windows, and compliance with ASHRAE 62. LEED requirements for credit are listed.

Designers’ Toolbox Active Strategies Water Preservation Smart Growth Promoting Health Passive Strategies Resource Preservation Minimizing Disturbance
