Sequence File Formats

Sequence File Formats

• Different formats for different uses
• Competing formats developed in parallel
• Some easy to read, some easy to write

programs

• Don’t have to stick to these formats, but parsers

already written!

• Most formats are plain text (not .bam files!)

Id’s versus accessions

• When people first started, they were using gene

names as id’s

• But too few gene names, and databases require

unique ids

• Now have a variety of accession numbers
• The simplest id is a number that you increment,

as you can (almost) never run out of IDs.

Standard genetic code

Symbol Meaning Origin G G Guanine A A Adenine C C Cytosine T T Thymine R G or A puRine Y T or C pYrimidine M A or C aMino K G or T Keto N G or A or T or C aNy

One Three Amino acid One Three Amino acid A Ala Alanine M Met Methionine C Cys Cysteine N Asn Asparagine D Asp Aspartic acid P Pro Proline E Glu Glutamate R Arg Arginine F Phe Phenylalanine S Ser Serine G Gly Glycine T Thr Threonine H His Histidine V Val Valine I Ile Isoleucine W Trp Tryptophan K Lys Lysine Y Tyr Tyrosine L Leu Leucine X Xaa Unknown

Standard protein codes

Fasta

• Simplest file format. Easy to parse, easy to use

>identifier [optional information] ATGACTAGCATGCATCGATCGATCGACTAGCATG ACTGCACTACGACGACAGCAAC >identifier2 [optional information] ACTAGCTCAGCTAGAGAGCTACGATCAGCACTAC atccgatagcatgacttactACGCTAGCATCAGTCATA CAT

GenBank

• More complex, includes detailed information on

genes, cds, annotation etc

• Human readable
• Difficult to parse
• Use standard parsers (bioperl, biojava, etc)

LOCUS NC_001418 5833 bp ss-DNA circular PHG 17-APR-2009 DEFINITION Pseudomonas phage Pf3, complete genome. ACCESSION NC_001418 VERSION NC_001418.1 GI:9626316 DBLINK Project:14061 KEYWORDS . SOURCE Pseudomonas phage Pf3 ORGANISM Pseudomonas phage Pf3 Viruses; ssDNA viruses; Inoviridae; Inovirus. FEATURES Location/Qualifiers source 1..5833 /organism="Pseudomonas phage Pf3" /mol_type="genomic DNA" /host="Pseudomonas aeruginosa" /db_xref="taxon:10872" /note="Pf3 bacteriophage DNA from P.aeruginosa infected with plasmid RP1." gene join(5763..5833,1..106) /locus_tag="Pf3_1" /db_xref="GeneID:1260905" CDS join(5763..5833,1..106) /locus_tag="Pf3_1" /note="orf 58, part 2" /codon_start=1 /transl_table=11 /product="hypothetical protein" /protein_id="NP_040651.1" /db_xref="GI:9626317" /db_xref="GeneID:1260905" /translation="MSYYVCVQLVNDVCHEWAERSDLLSLPEGSGLQIGGMLLLLSAT AWGIQQIARLLLNR"

3241 aggtcctgtt ggccttaaga tcacccaagg gcatcttgcc agatggtacc gtcattactt 3301 atgagaaaat atcctcaatg ggtaatggct ataccttcga gcttgagtcg cttatatttg 3361 cggctcttgc tcggtcttta tgcgaattac tgggcttacg accgtcagat gttacggtct 3421 atggcgatga cataatattg ccatcagacg cgtgcagtcc tctagttgaa gttttctcct 3481 atgttggttt tcgtaccaac aagaagaaaa cgttttctag tggaccgttc cgagagtcgt 3541 gcggaaagca ctactttttg ggcgttgacg tcacaccttt ctacatacgt cgccgtatag 3601 tgagtccctc cgatctcata ctggttttga accagatgta tcgttgggcc acaattgacg 3661 gcgtatggga tcctagggta tatcctgtat acaccaagta tagacgttac cttccggaaa 3721 ttctccggag gaatgtcgtg cctgatggat acggtgatgg tgccctcgtc ggatctgtct 3781 taatcagtcc tttcgcagaa aatcgcggtt gggttcggcg tgtgccgatg attatagaca 3841 agaggaaaga ccgagttcgt gacgaatatg gttcgtatct ctacgagcta tggtcgttgc 3901 agcaactcga atgtgacagt gagttcccct ttaacgggtc gctggtcgtt ggttccactg 3961 atggcactct cgcttacgca caccgagaac ggttacctac cgttatcagt gatgccgtaa 4021 gtgcgtttga catcatgtgg ataccgtgca gtagtcgtgt cctggctccc tacggggatt 4081 tccggaggca cgaaggctct atcctaaaaa tggggtagcg cctgggaggg gtgcattatg 4141 caccctaggt tagcaatact taaactaacc ttctcaaaag agagagtgaa ggctctgctt 4201 tgccctcact cctccca // LOCUS NC_003301 3192 bp ds-RNA linear PHG 23-AUG-2008 DEFINITION Pseudomonas phage phi8 segment S, complete sequence. ACCESSION NC_003301 VERSION NC_003301.1 GI:17736965 DBLINK Project:14731 KEYWORDS . SOURCE Pseudomonas phage phi8 ORGANISM Pseudomonas phage phi8 Viruses; dsRNA viruses; Cystoviridae; Cystovirus.

GFF3

• Tab separated format
• Easy to parse
• Attributes are tag/value

pairs separated by “;”

• Columns:
• 1. Contig
• 2. Source database
• 3. Feature type
• 4. Start
• 5. Stop
• 6. Score
• 7. Strand
• 8. Phase
• 9. Attributes

ASN.1

• Developed as computer readable form of

GenBank

• Not widely used

seq { id { local id 1 }, descr { title "" }, inst { repr raw, mol aa, length 131, topology linear, { seq-data iupacaa "TSPASIRPPAGPSSRPAMVSSRRTRPSPPGPRRPTGRPCCSAAPRRPQA TGGWKTCSGTCTTSTSTRHRGRSGWSARTTTAACLRASRKSMRAACSRSAGSRPNRFA PTLMSSCITSTTGPPAWAGDRSHE" } } , seq { id { local id 1 }, descr { title "" }, inst { repr raw, mol aa, length 131, topology linear, { seq-data iupacaa "TSPASIRPPAGPSSR---------RPSPPGPRRPTGRPCCSAAPRRPQAT GGWKTCSGTCTTSTSTRHRGRSGW----------RASRKSMRAACSRSAGSRPNRFAPTL MSSCITSTTGPPAWAGDRSHE" } }

ASN.1

Base calling

 Need to be sure which base you have identified  Depends on the technology  Each machine includes software  Phred is an historical package developed by at

• U. Washington

 Phred scores are probability that the base is

correct

Quality values

 Phred 10: 1 x 101 chance that the base is wrong  Phred 20: 1 x 102 chance that the base is wrong  Phred 30: 1 x 103 chance that the base is wrong  Phred 40: 1 x 104 chance that the base is wrong  Phred 99: the base is correct!  Fastq scores are the score + 33 then converted

to ascii text

FastQ

• Based on fasta format
• Contains information about the quality of the

sequence

• Quality comes from sequencing machines!
• Four lines per sequence:
• Line starting @ = identifier line before the sequence
• DNA sequence
• Line starting + = identifier line before the quality scores
• String = quality scores as ASCII + 33

ASCII Char ASCII Char ASCII Char ASCII Char ASCII Char 33 ! 50 2 70 F 90 Z 110 n 34 " 51 3 71 G 91 [ 111

• 35

# 52 4 72 H 92 \ 112 p 36 $ 53 5 73 I 93 ] 113 q 37 % 54 6 74 J 94 ^ 114 r 38 & 55 7 75 K 95 _ 115 s 39 ' 56 8 76 L 96 ` 116 t 40 ( 57 9 77 M 97 a 117 u 41 ) 58 : 78 N 98 b 118 v 42 * 59 ; 79 O 99 c 119 w 43 + 60 < 80 P 100 d 120 x 44 , 61 = 81 Q 101 e 121 y 45

• 62

> 82 R 102 f 122 z 46 . 63 ? 83 S 103 g 123 { 47 / 64 @ 84 T 104 h 124 | 48 65 A 85 U 105 i 125 } 49 1 66 B 86 V 106 j 126 ~

ASCII character codes

@SRR014849.1 EIXKN4201CFU84 length=93 GGGGGGGGGGGGGGGGCTTTTTTTGTTTGGAACCGA AAGGGTTTTGAATTTCAAACCCTTTTCGGTTTCCAA CCTTCCAAAGCAATGCCAATA +SRR014849.1 EIXKN4201CFU84 length=93 3+&$#"""""""""""7F@71,'";C?,B;?6B;:E A1EA1EA5’9B:?:#9EA0D@2EA5':>5?:%A;A8 A;?9B;D@/=<?7=9<2A8==

fastq

Note: Illumina has a format of fastq that is not compatible with everyone else’s format! DNA sequence Quality scores

How to convert fastq to fasta

• prinseq-lite.pl -fastq input.fastq -out_format 2
• https://edwards.sdsu.edu/research/fastq-to-

fasta/
