Semantic Markup for Secure Survivable Enterprise Applications Anya Kim, Amit Khashnobish, Jim Luo, Bruce Montrose, Myong Kang US Naval Research Laboratory Code 5542 Washington, DC Introduction Service-oriented architectures Relies


  1. Semantic Markup for Secure Survivable Enterprise Applications Anya Kim, Amit Khashnobish, Jim Luo, Bruce Montrose, Myong Kang US Naval Research Laboratory Code 5542 Washington, DC

  2. Introduction • Service-oriented architectures – Relies on the ability to communicate relevant security information in a machine-understandable manner • Resources are protected by security mechanisms – Can act as barriers to access • Interoperability requires semantic markup of resources with security-related metadata – Enable dynamic discovery and invocation of services in a secure and trusted environment

  3. Security in SOA Specification & Matchmaking Current Standard Our Contribution Enterprise Application Level BPEL Augment with T2 T4 security-related markup in the context of the T1 T3 T5 application Infrastructure UDDI Add semantic markup and query capabilities D1 D2 WSDL Semantic description of security-related concepts D3 D4 using ontologies Web-service Level

  4. Security Specifications in SOA • More complex than functional descriptions – Security Requirements and Capabilities – Matchmaking is different Service Consumer Service Provider Security Requirements Security Requirements Security Capabilities Security Capabilities

  5. NRL Security Ontology • Ontologies provide fine-grained semantic description and discovery • Used at all levels of SOA for security specification Password Certificate Cookie name minLength value path X.509Certificate version Organizational ontology serialNumber issuer notBefore notAfter Date/time ontology

  6. Infrastructure level • Industry standard UDDI repositories cannot store ontology information • OWL2UDDI – Provide capabilities for ontology-based service description and discovery in UDDI using client-side modules

  7. Web Services Level and Enterprise Application Level • Web Services Level – Describe security capabilities and requirements using NRL Security Ontology – GUI to browse ontologies, specify security, and discover services • Enterprise Application Level – Created a simple GUI that represents data flow among tasks to specify security requirements: – Capturing mission software logic that spans multiple organizations and multiple applications – Consider security requirements in the context of mission software – Bridge the gap between operational community and security community

  8. Beyond the Paper Compose Mission Logic Goal: functional & (Business Logic) security descriptions P2 P1 P4 P3 Search Service Check status criteria selector QoS 2 Security List of 1 Service Status potential 3 Invoke the Registry services best service Web Service

  9. Questions?
