New Venice Your Address In Space Master Thesis Defense Suzana Bianco May 3rd, 2018 sdbianco@uh.edu
Imagine... It is the year 2070. The existing space economy is thriving. There are many facilities scattered across Cislunar space providing services to space companies. Colonies on the Moon and Mars have been running continuously for at least a decade. Lunar and asteroid ISRU produce enough surplus material to be commercialized. Humans are ready to begin deep space settlement. 01 Art by Robert McCalll
In this context, there is a growing demand for a large space facility where multiple space companies can conduct their activities and ofger their services, establish their market, and settle their workers. This thesis presents one concept for such a facility : New Venice Multi-Industry Space Outpost New Venice is a physical address where companies can explore the space environment . They will be able to lease space on-board without the cost and burden of constructing and launching their own space facilities. The community village ofgers comfortable amenities for the employers and visitors, and is a popular tourist destination. 02 Art by Robert McCalll
Agenda Problem Statement Design brief Phasing Economics and People Functional Allocation Design concept Life in the Community 03 Conclusion
Problem statement Problem 1 Problem 2 Problem 3 How to incorporate micro-gravity in comfortable, How to cater to the great diversity of functions and How to change the status quo of space station assembly stimulating living environments, breaking free from uses, each with its unique requirements, restrictions based on chamber-to-chamber/corridor environments? the usual concepts of either adapting Earth to space or and peculiarities without interfering with each other? Humans to machines? 04
Design Brief Main Assumptions • Year 2070 ; • Thriving cislunar economy; Concept • Advanced colonies on the Moon and Mars; • Functional separation; • Lunar and asteroid ISRU are producing surplus; • Simultaneous activities; • Space contractors build and outfjt structures in space; • Balance of private vs public; • Large infmatables are proven technology; • Mix of launched modules and in- • NASA’s SLS is the main large payload provider; space construction; • New technologies in material and medicine ofger • Commercially operational from suffjcient protection against cosmic radiation; start, no interruption for growth; • Future expansion capabilities; Project parameters: • Multiple circulation routes; • Population: 400 people; • Multiple escape possibilities. 87% working (economic or support activities) 13% visiting (tourists, training, students) • 3 year permanence limit; • Micro gravity environment; 05
Location u n a r O r b L i t L4 Earth - Moon L5 m a g n s e ´ t h o t s r p a h E e r e G E O • Stable orbit; • Little to no attitude control and orbit correction boosts needed; • Little to no gravity gradient; • No atmospheric drag; L3 L1 L2 • No orbital debris; • Advantageous ΔV for travel between Earth/Moon/Cislunar; LEO • Convenient location for commercialization of lunar and asteroid HEO materials; MEO • Convenient location for way-station for deep space; Van Allen Radiation Belts • Simultaneous Earth and Moon gazing opportunities. L5: Your address in space! 06
Initial Growth Phase 2 Phase 4 • Logistics • Research • Shipyard • Space Health • Temp housing • Institutional • Temp housing Phase 1 Phase 3 • Fuel depot • Spaceport • Servicing • Light industries • Ore processing • Nuclear power • Heavy industries 07
Community Growth Phase 5 Phase 7 • Industry expansion • Tourism • Remote operation support • Entertainment • Shopping Phase 6 • Food/water production • Space commerce 08
Future expansion 09
Economic Activities Primary Activities Support Activities Space mobility: Community: Shipyard Housing Spaceport Wellness Leisure Production: Manufacturing Management: Material processing Administration Food/Water Operations Energy Logistics: Research: Maintenance Education Supply Research Security Health Mobility Entertainment: Tourism Sports Ceremonial Space Experience Film studio 10
Functional Analysis Estimated Estimated Workforce Workforce 181 Primary Activities Support Activities 169 Space Mobility 52 Community 45 Fuel depot 2 Housing Housing 4 Shipyard Maintenance/ servicing 17 Medical 10 Spacecraft assembly 17 Wellness Fitness 2 Interplanetary spaceport 2 Eating 5 Spaceport Cargo terminal 4 Commerce 15 Space tra ffic control 10 Cultural 2 Leisure Recreation 2 Production 59 Parks 5 Pharmaceuticals 4 Crystal growth 4 Management 58 Manufacturing Nanostructures 4 Administration Administration 37 Spacecraft components 5 Operations 6 Textiles (composites) 4 Operations Engineering 8 Mat. Process. Material processing 16 Systems 6 Food production 16 Logistics 66 Food/Water Water production 2 Maintenance/ Repair 11 Maintenance Energy Power plant/ export 3 Housekeeping 34 Research 59 Supply Supply/distribution 5 University 2 Security Security 13 Education Zero G training 2 Mobility Internal circulation 3 Science 13 Technology 13 Research Institutional 13 Health 13 Health Space tech treatment 4 Entertainment 11 Total workforce 350 Tourism Tourism 7 Simultaneous visitors limited to 50 Sports Space sports 0 Marriage 1 Total population: 400 Cerimonial 11 Burial 2 Space exp. Zero g/playground 0 Film studio Film studio 0
Functional allocation POPULATION s e S i u t i p v p i t o c r A t Visitors Cluster 1 A y r c a t m i v i i t r i P e s Cluster 4 Cluster 2 Cluster 3 1 2 3 4 130-200 people/day Cluster 1: Cluster 2: Cluster 3: Cluster 4: 50-129 people/day Fuel depot Space mobility Housing Institutional 1-49 people/day Heavy Industry Logistics Leisure Health Emergency escape Sensitive Industry Management Entertainment Production 12
Cluster configuration Cluster 1: Fuel depot Heavy Industry Sensitive Industry Cluster 2: Space mobility Logistics Management Cluster 3: Housing Leisure Entertainment Cluster 4: Institutional Health Production 13
Cluster 1 Workforce: 25 people Fuel depot: Fuel station and deposit Satellite Industries: Production or research requiring absolute isolation 14 Orion MPCV courtesy of NASA
Cluster 2 Workforce: 170 people Ufficio Administrative offjces and housekeeping Mestre Colombo, Vespucci, Polo Command Systems engineering, backup Shipyard and maintenance workshops, Command center, bridge, customs, airlock and systems, control center warehouse. ceremonial venue Guglie Rialto Solarium Porto: 15 Transformers, electric panels and Node, welcome center Space gazing, Spaceport, cargo bays, security, brig, morgue batteries, airlock emergency escape
Cluster 3 Workforce: 45 people Users: 400 people Murano, Giudeca, Lido Community Islands Living, wellness, entertainment and tourismW 16
Cluster 4 Workforce: 110 people Vaporetto Pressurized cabs Galileo, Cassini Paglia, Scalzi Leased chambers Nodes and leased chambers Industrial Belt Leased modules Laguna Sicilia, Asti, Campania Solarium 17 Water treatment plant and fjsh culture Green houses, Food processing and packaging, waste Space gazing, emergency management escape
Breaking the Status Quo Hard Shell modules Hybrid modules Pressure vessels Detached modules 18
Hard Shell Modules 8m 8m 4.3m Access/Cafe/WC Access/Cafe/WC 23m 23m 8.4m All uses Labs/Offjces Labs/Offjces ISS Destiny Module Ufficio, Galileo, Cassini Mestre Access/labs Utility run Utility run Chamber 19 Equipment People Circulation
Hybrid modules Equipment/ring access Greenhouses 30.5m 25m 7m 6m Assessment bubbles Water treatment tank Equipment/ring access Equipment/ring access Assessment bubbles 11m 11m Equipment/ring access 8m 9.5m Water treatment tank Greenhouses Food production/waste management Quality lab 20 Laguna Sicilia, Asti, Campania
Detached modules Vaporetto Truss attachment Docking truss with vibration dampeners 21 Infmatable modules similar to B330 arranged in a ø 77m circle Emergency escape 21 Industrial belt pods 3 Vaporetto cabs circling around the belt
Pressure Envelopes 22 Community islands Spaceport
Frame Thrower Pressure Envelopes Material tanks Spinner Frame Thrower Frame printing head Guide legs Secondary frame printing head Spinner Membrane spool Filament tanks Membrane Filament Frame: Anhydrous glass fjbers Frame Filament: Anhydrous glass fjbers 23 Membrane: Woven basalt fjbers Filament printing head
Spaceport People Docking Command center Docking ring Circulation Airlock 8m 11m Airlock Command center Cargo bay Cargo bays Service bays Service bays Docking ring Docking ring 24 Cargo bays Cargo bays Viewport 76m
Utility run Utility run Toilets Community Island Service/technical People Circulation Radiators Individual living pods Projected sky Park/commons Projected sky Individual living pods 15m PLAN - A Expressway PLAN - B Technical area Park/commons Technical area Expressway Park/commons 25 Arc length 76m
