Neuro-Inspired Processor Design for On-Chip Learning and Classification with CMOS and Resistive Synapses

Jae-sun Seo

School of ECEE, Arizona State University The 13th Korea-U.S. Forum on Nanotechnology September 26, 2016

2

ML Literature (DNN) Neuromorphic (SNN)

Song, PLoS Biol. 2005 Courtesy: Nuance

• Dense connectivity
• Learning done offline
• Back-propagation

(requires labeled data)

• MNIST 99.79%, ImageNet 95%
• What about unlabeled data
• r customization?
• Full computation on each layer

→ high power

• Sparse connectivity
• Online learning
• STDP, SRDP, Reward

(biological evidence)

• MNIST 99.08%, ImageNet N/A
• Cont. learning & detection
• Adaptable for input change
• Sparse spiking, attention

→ low power

3

2.05mm 2.05mm

Base design Slim neuron variant 4-b synapse variant Low leakage variant

64K synapse array 256K synapse array 64K synapse array 64K synapse array

Neuromorphic Core with On-Chip STDP

• Under STDP learning, when neuron K spikes, all

synapses on row K and column K may update

• Transposable SRAM: single-cycle read & write in

both row and col. directions

• Efficient pre- and post-synaptic update
• Near threshold operation
• Pattern recognition

20X

fully functional

retention mode

Seo, CICC, 2011

4

Versatile Learning in Neuromorphic Core

• A versatile neurosynaptic core to support various learning rules,

large fan-in/-out, sparse connectivity

• Triplet STDP (Pfister, J. of Neuroscience, 2006, Gjorgjieva, PNAS 2011)
• post-pre-post: post nrn. spike & pre nrn. timing & post nrn. timing
• pre-post-pre: pre nrn. spike & post nrn. timing & pre nrn. Timing

Various STDP Learning Rules (Feldman, Neuron 2012) Multi-factor Triplet-STDP

N2

N3_0 N3_1

wb0

N3_2 N3_3

wb1 wb2 wb3

N1_0 N1_1

wa0

N1_2 N1_3

wa1 wa2 wa3

spike LTD LTP pre-synaptic neurons post-synaptic neurons cnt. cnt. cnt. cnt. cnt. cnt. cnt. cnt. Δw Δw Δt Δt

When N3 sp wb* synaps subject to L

LTP: w = w + [pre cnt.] + [post cnt.] LTD: w = w – [post cnt.] – [pre cnt.]

when N3 spikes

5

decoder

Axons w/ timing info.

Synapse Array

1024x256

spike packet spike packet

recurrent connection Synapses: TX => Inhib.

Inh. nrn Synapses

• Inh. => RX neuron

256 Neurons

spike timing info.

Layer (i) neurons Layer (i+1) neurons Inhibition

Feedforward Excitation & Inhibition

[1] Diehl, Front. of Neuroscience, 2015

• Joint feed-forward excitation and inhibition
• For a small number of inhibitory neurons,

add pre=>inh, inh=>post synapses

• Balance excitatory & inhibitory synaptic inputs

Vogels, Science, 2011

6

Neural Spike Sorting Processor (for deep brain sensing & stimulation)

• Signals from invasive electrodes: spikes from multiple neurons
• Online, unsupervised neuromorphic spike-sorting processor

Collaboration with Columbia University (ISLPED 2015)

Input: Raw Signal Detection & Alignment Clustering Sorting Processor Output

neuromorphic

Encoder H1 Z1 ZK

...

H2 H3 HN I

...

I1 I2 I3 Im

8 bits 32 samples

• Weight update through STDP
• Start with K=2, automatically

increases # of output neurons if the spike difference is large enough (self-organized map)

7

• Exp. Results: Clustering Accuracy

D2 D3 D4 D4* W-D1 W-D2 20 40 60 80 100 Accuracy(%) Dataset

• Proposed. Avg acc.= 91%

Osort based. Avg acc.=69%

Receptive field of dataset that contains 4 clusters in 3000 spikes

Spike sorting accuracy more reliable than other low-complexity algorithms such as O-sort

• Avg. accuracy: 91% vs. 69%

Synapse Array Input Neurons

Output Neurons Output Neurons Others Decoder

0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 0.01 0.1 1 10 100 9.3W/ch 70 spikes/s/neuron ([4]) Frequency(MHz) VDD (V) 2.5 spikes/s/neuron (D2, D3, D4, D4*) 26W/ch

• 65nm GP, high-Vth, 0.5x0.5mm2
• 9.3µW/ch at 0.3V
• Layout of the design is

dominated by memory elements, as well as power.

8

Neuromorphic Computing w/ NVMs

• Emerging NVMs (e.g.

RRAM) could alleviate power/area bottleneck

• f conv. memories
• Read rows in parallel:

weighted sum current

• Peripheral CMOS read:

current-to-digital converter

130nm RRAM array + CMOS read circuits (under testing)

0.50 0.53 0.0 1.5 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 RE RE Vspike Vspike Vin Vin

Time (ns) Voltage (V)

Simulation results for 4ns read timing window

9

Summary

• Neuromorphic computing hardware
• 45nm testchip with on-chip STDP learning
• Versatile learning neuromorphic core & architecture
• 65nm spike clustering processor
• Emerging NVM arrays + peripheral read/write circuits
• Future research with circuit-device-architecture co-

design and optimization

10

Collaborators

• ASU
• Faculty: Yu Cao, Shimeng Yu, Chaitali Chakrabarti, Sarma

Vrudhula, Visar Berisha

• Students: Minkyu Kim, Deepak Kadetotad, Shihui Yin,

Abinash Mohanty, Yufei Ma

• Intel: Gregory Chen, Ram Krishnamurthy
• Columbia University: Mingoo Seok, Qi Wang
