SLIDE 1
2
The motivations
128 microns
barium borosilicate glass SiO2 + BaO + B2O3
material images: from raw data to physical measurements Chloe - - PowerPoint PPT Presentation
material images: from raw data to physical measurements Chloe - - PowerPoint PPT Presentation
Segmentation of 3-D glass material images: from raw data to physical measurements Chloe Brillatz Surface du Verre et Interfaces 15/11/2018 The motivations 128 microns barium borosilicate glass SiO 2 + BaO + B 2 O 3 2 The motivations Thin
SLIDE 2
SLIDE 3
3
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
The motivations
Main glass Thin layer Nano-texture Super hydrophobic glass
SLIDE 4
4
From raw glass to physical measurements
SLIDE 5
5
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
Data acquisition
3D imaging by X-ray tomography at the Grenoble Synchrotron (European Synchrotron Radiation Facility):
Non-destructive method + evolution in time 900°C Nanometric resolution ( ESRF Beam 16b)
SLIDE 6
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
128 microns 108 microns
slice view
Full glass sample
Data: horizontal view
Movie
SLIDE 7
7
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
The goal
SLIDE 8
8
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
Raw Image
SLIDE 9
9
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
After local filter
ndimage.median_filter from scipy
- Computes the median
- f the voxel values in a given
window, the central voxel is replaced with this median value
After Before
SLIDE 10
10
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
After segmentation – 2D view – unsuccessful test
threshold_otsu from skimage.filters
- Reduces a gray level image
to a binary image
- globally calculates the
threshold
SLIDE 11
11
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
After segmentation – 2D view
rank.otsu from skimage.filters
- Reduces a gray level image
to a binary image
- locally calculate the
threshold
SLIDE 12
12
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
Raw image
SLIDE 13
13
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
The goal
Movie
mayavi 3D visualization mlab.pipeline.contour_grid_plane grid_plane.sync_trait
SLIDE 14
14
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
Some numbers
x 80
Time: 0 s Time: 4 hours
…………..
1.8 billions voxels
7 GB Total 560 GB Parallel from joblib 50 chunks
- verlap = 10 slices
30 cores Total running time for the segmentation: 17 hours
SLIDE 15
15
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
After segmentation – 3D view
marching_cubes_lewiner from skimage.measure
- finds surfaces in 3d
volumetric data mlab.triangular_mesh from mayavi
SLIDE 16
16
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
After segmentation – 3D view
Movie
marching_cubes_lewiner from skimage.measure
- finds surfaces in 3d
volumetric data mlab.triangular_mesh from mayavi
SLIDE 17
17
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
Labelling
label from scipy morphology.remove_small_objects from skimage
SLIDE 18
18
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
Data analysis
SLIDE 19
19
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
After segmentation – 4D view
Movie
TimeVisualizer - Mayavi
- A GUI for 3-D visualization
and exploration of a time series of 3-D images
SLIDE 20
20
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
What to take home
start simple compromise between quality and time Python simple and powerful tools
1 TB
SLIDE 21
21
SVI – CONFIDENTIAL – Disclosure or reproduction without prior written permission of Saint-Gobain Recherche is prohibited
Contact
I’d be happy to share more details, the codes and ideas: Please contact me: chloe.brillatz@gmail.com
