LAYOU LAYOUT D T DATA P ATA PREPAR ARATION ATION: DATA DATA SOUR URCES, WO WORKFLOWS WS & COMMO MMON PROBL BLEMS MS ROB MILLER DIRECTOR OF PARTNERSHIPS & TriBuild, Inc. INTEGRATIONS ABO ABOUT ME Bachelors degree in


  1. LAYOU LAYOUT D T DATA P ATA PREPAR ARATION ATION: DATA DATA SOUR URCES, WO WORKFLOWS WS & COMMO MMON PROBL BLEMS MS ROB MILLER DIRECTOR OF PARTNERSHIPS & TriBuild, Inc. INTEGRATIONS

  2. ABO ABOUT ME • Bachelors degree in Geomatics (Surveying & Mapping) • Majority of my construction career has been spent with Trimble • 13 ½ years in support & training and product development • 3 ½ years at BuildingPoint • Involved in the development of LM80 Layout Manager, RTS series instruments, Trimble Field Link, RPT600 and many other projects • Spent 1 ½ years working as a Topcon distributor • Named as an inventor on multiple US patents related to construction positioning • Currently work in business development for TriBuild, Inc. • Married for 19 years, two sons, volunteer with the Boy Scouts of America

  3. LE LEAR ARNING OBJE BJECT CTIVE VES 1. Understand how a robotic total station is used for laying out on a construction site 2. Understand the different data file formats used to prepare data for layout 3. Understand some of the layout data preparation software tools available 4. Understand the basic workflow for preparing data for layout on the jobsite

  4. IN INTROD ODUCT UCTION ION T TO CON O CONST STRUCT UCTION ION LA LAYOUT OUT

  5. EV EVOL OLUTION TION OF OF CONS ONSTRU TRUCTION TION LAYOU YOUT • Legacy tools & methods still dominate but are not sufficient for many current projects • While adoption of digital layout solutions started around 2000, half the industry still hasn’t invested in the technology • An aging workforce is hesitate (even obstinate) to adopting new tools & technology • Layout is one of the few places on a job where a contractor can increase their margin

  6. CO COMMON LAY LAYOUT AP APPLI LICAT CATIONS • Foundations / Footers • Anchor bolts • Walls • Hangers • Sleeves • Lights (poles, hanging) • Stub-ups • Electrical boxes • Runs (pipe, conduit, duct, etc.) • Equipment locations

  7. CO CONST STRUCT CTION LAY LAYOUT WITH A A TOTAL AL ST STAT ATION • A total station is a surveying instrument which measures angles & distance (not satellites) to determine positions • Each measurement from a total station is radial and independent from the others – errors don’t compound • Robotic total stations are motorized and only require 1 person to operate • Laying out with a total station offers increased speed and accuracy over traditional tools • Investing in a robotic total station can pay for itself in only a couple of months • Layout is performed directly from a digital file and is not likely affected by missing dimensions on a drawing or human errors in calculating lengths

  8. ROB ROBOTI OTIC TOTA TOTAL S STA TATI TIONS ONS

  9. “Tru “Truck Argu rgument” ment”

  10. SE SETU TUP I INSTR STRUMENT A T AND M D MEASU SURE TH THE F FIRST R ST REFERENCE CE P POINT

  11. ME MEAS ASURE RE A A SECON OND RE REFERE RENCE POI OINT TO O DETERMI RMINE THE INSTRU RUME MENT LOC OCAT ATION ON

  12. SE SELECT A CT A P POINT TO T TO L LAY O Y OUT A T AND F D FOLLOWI WING TH THE G GUIDA DANCE CE O ON TH THE SCR SCREEN Away: 5’ 1/4” Left 30’ 2 3/8” Forward: 0” Right 1/8”

  13. LA LAYOUT OUT D DATA SOUR SOURCE CES & S & SOF SOFTWARE T TOOLS OOLS

  14. DA DATA SO SOURCE CES: S: FILE LE FORMATS, S, APPLI LICA CATIONS S & People le Engineer Architect General Contractor

  15. DESIGN & ENGINEERING DWG RVT ✘ FABRICATION, COLLABORATION IFC DWG RVT DXF NWD PDF & SHARING IMAGE LAYOUT DATA PREP IFC RVT NWD DWG DXF FIELD LAYOUT IFC DWG DXF

  16. PDF LAYOUT DATA PREP RVT NWD DWG DXF

  17. LAY LAYOUT DAT DATA A PREPAR ARAT ATION • Preparing for field layout consists of creating points at critical locations from a design (2D or 3D) • Points serve as a task list of the work that needs to be performed • Organizing and managing points by assigning points names / numbers, descriptions and groupings (layers) aids in field operations • Creating layout points can be done in a variety of applications • Design applications with add-on tools • Standalone office software • Layout field software • The majority of points should be created before going to the field

  18. LAY LAYOUT DAT DATA A PREPAR ARAT ATION (Co (Cont.) • There are a number of software applications available to support for a variety of file types, workflows and contractor needs • As discussed, there are only a design file types that are used for preparing layout data – PDF, DWG/DXF, RVT, NWD • If a standalone application is used, they rely on libraries, APIs, SDKs (or other means) to work with the design file • Any time a conversion occurs, there is a potential risk for loss of data or other errors

  19. Lay Layout Dat Data a Prep Ap Appli licat cations STANDALONE SOFTWARE DESIGN PLUG-INS • Trimble Field Link Office • TriBuild Layout Design • Leica iCON Office • eVolve Mechanical & Electrical • HILTI PROFIS Layout Office • Trimble Field Points • Topcon MAGNET Layout • Autodesk Point Layout • HILTI PROFIS Field Points • DeWalt HangerWorks

  20. LA LAYOUT OUT D DATA P PREPARATION ION W WOR ORKFLOW LOW

  21. PDF LAYOUT DATA PREP RVT NWD DWG DXF

  22. VE VECT CTOR VS. VS. RAST ASTER PDF • Vector PDFs are comprised of geometries and are generated by “exporting” from a design application • Raster PDFs are “pictures” of drawings and are generated by scanning a document or through a software conversion • Raster PDFs are not usable for layout because points cannot be “snapped” to locations and drawing scales are not accurate (or consistent) • Raster PDFs are the equivalent of other image files (TIFF, JPG, GIF) • Stamped drawings are most likely raster format • Some drawings are intentionally converted to raster format to prevent their use for more than visual reference

  23. VE VECT CTOR VS. VS. RAST ASTER PDF VE VECT CTOR OR

  24. VE VECT CTOR VS. VS. RAST ASTER PDF RAS RASTER TER

  25. PDF TriBuild Layout Design Trimble Field Link Office Trimble Field Points Leica iCon Office HILTI PROFIS Layout HILTI PROFIS Field Points Office Autodesk Point Layout Topcon MAGNET Layout

  26. “P “PDFIMP FIMPORT” ORT”

  27. RES RESULTI TING NG L LAYERS YERS, I , IF P F PDF L F LAYERS YERS NOT P NOT PRES RESENT ENT

  28. NWD DWG DXF RVT TriBuild Layout Design Trimble Field Link Office TriBuild Layout Design Autodesk Point Layout Trimble Field Points Leica iCon Office eVolve Mech. & Elec. HILTI PROFIS Layout HILTI PROFIS Field Points Trimble Field Points Office Autodesk Point Layout Topcon MAGNET Layout HILTI PROFIS Field Points Autodesk Point Layout

  29. DA DATA LO LOSS SS FROM IMPORT / CO CONVERSI SION • Software applications use libraries, APIs or SDKs to tell it how to represent the non-native files • Libraries may be outdated or possibly intentionally missing capabilities (to protect intellectual property) • Incomplete libraries could result in inaccurate data (scale or location) • Imported or converted files should be carefully reviewed to ensure there are no errors which could lead to problems on the jobsite

  30. DA DATA LO LOSS SS FROM IMPORT / CO CONVERSI SION

  31. DA DATA LO LOSS SS FROM IMPORT / CO CONVERSI SION

  32. “INS “INSUNITS NITS” • Blag

  33. WH WHERE A ERE ARE P RE POINTS OINTS A ARE C RE CREA REATED TED • Snap locations • Endpoints (e.g. foundation, equipment pads, walls) • Intersections (e.g. grids) • Arc / Circle Center (e.g. columns, sleeves, hangers, stub-ups) • Block Insertions (e.g. sleeves, hangers, floor boxes) • Family Insertions (e.g. sleeves, hangers, floor boxes) • Custom locations in AutoCAD blocks (e.g. top & bottom of footers, square columns, suspended lights) • Custom locations in Revit families using Markers (e.g. piping transitions, square columns)

  34. CR CREAT ATE POINTS S AT AT INTERSE SECT CTIONS

  35. CR CREAT ATE POINTS S AT AT BLO BLOCK CK INSE SERTION

  36. CR CREAT ATE POINTS S INSI SIDE DE A A BLO BLOCK CK

  37. INS INSID IDE E A BLOC OCK

  38. INS INSID IDE E A BLOC OCK

  39. INS INSID IDE E A BLOC OCK

  40. INS INSID IDE E A BLOC OCK

  41. CON CONCLUSION CLUSION

  42. KE KEY TAKE AKE-AW AWAY AYS • Traditional layout tools are often insufficient for modern projects • Laying out with a total station provides an opportunity to improve profitability • Prepare data for layout inside design applications whenever possible – avoid unnecessary conversions • Total station manufacturers are not the only providers of layout data prep software • Not all file sources and formats are created equal

  43. TH THING NGS TO C TO CONS ONSIDER ER • Is your current process the right process? • Are you converting files unnecessarily? • What are your data sources? Are you sure they are your only / best data sources? • What functionality do you need? • Who / how many people will be preparing data? • Costs

  44. LE LEAR ARN MORE FROM EXHIBI BITORS S ABO ABOUT THEIR SO SOLU LUTIONS
