Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) HW Hig igh-Availability and Li Link Aggregation for Eth thernet switch and NIC IC RDMA usin ing Li Linux bonding/team Tzahi


  1. Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) HW Hig igh-Availability and Li Link Aggregation for Eth thernet switch and NIC IC RDMA usin ing Li Linux bonding/team Tzahi Oved tzahio@mellanox.com ; Or Gerlitz ogerlitz@mellanox.com Netdev 1.1 | 2016

  2. Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) Bonding / Team drivers • both expose software netdevice that provides LAG / HA toward the networking stack • team/bond is considered “upper” device to “lower” NIC net -devices through which packets are flowing to the wire • different modes of operation: Active/Passive, 802.3ad (LAG) and policies: link monitoring, xmit hash, etc • Bonding – legacy • Team - introduced in 3.3, more modular/flexible design, extendable, state-machine in user-space library/daemon

  3. Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) HW LAG using SW Team/Bond • Idea: use SW LAG on netdevices to apply LAG into HW offloaded traffic • offloaded traffic – doesn’t pass through the network stack 100Gbs Switch • each port is represented by netdevice • SW LAG on few ports netdevs  set HW LAG on physical ports (mlxsw, upstream 4.5) 40/100Gbs NIC • each port of the device is Eth netdevice • RDMA traffic is offloaded from the network stack • port netdevice serves for plain Eth networking and control pass for the RDMA stack • SW LAG on two NIC ports netdevs  HW LAG for RDMA traffic (mlx4, upstream 4.0) • under SRIOV, SW LAG on PF NIC ports  HW LAG for vport used by VF (mlx4, upstream 4.5) • for 100Gbs NIC (mlx5) – coming soon…

  4. Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) Network notifiers && their usage for HW LAG • notification sent to subscribed consumers in the networking stack on a change which is about to take place, or that just happened • the notification contains events type and affected parties • Notifications used for LAG: pre change-upper, change-upper HW driver usage for LAG notifications: • pre-change upper: refuse certain configurations, NAK the change • change upper: create / configure HW LAG

  5. Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) Switch HW driver • ip link set dev sw1p1 master team0 • NETDEV_PRECHANGEUPPER • if lag type is not LACP, etc - NAK team  operation fails • NETDEV_CHANGEUPPER • observe that new lag is created for the switch  create HW LAG and add this port there • ip link set dev sw1p2 master team0 • NETDEV_PRECHANGEUPPER switch driver • […] • NETDEV_CHANGEUPPER • observe that this lag already exists  add this port there

  6. Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) RDMA over Ethernet (RoCE) / RDMA-CM • The upstream RDMA stack supports multiple transports: RoCE , IB, iWARP • RoCE – R DMA o ver C onverged E thernet, RoCE V2 (upstream 4.5), IBTA RDMA headers over UDP. Uses IPv4/6 addresses set over the regular Eth NIC port netdev • RoCE apps use RDMA-CM API for control path and verbs API for data path • RDMA-CM API (include/rdma/rdma_cm.h ) • Address resolution – Local Route lookup + ARP/ND services (rdma_resolve_addr()) • Route resolution – Path lookup in IB networks (rdma_resolve_route()) • Connection establishment – per transport CM to wire the offloaded connection (rdma_connect()) • Verbs API • Send/RDMA – Send message or perform RDMA operation (post_send()) • Poll – Poll for completion of Send/RDMA or Receive operation (poll_cq()) • Async completion handling and fd semantics are supported • Post Receive Buffer – Hand receive buffers to the NIC (post_recv()) • RDMA Device • The DEVICE structure, exposes all above operations • Associated with net_device • Available for both RoCE and user mode Ethernet programming (DPDK)

  7. Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) Nativ ive Model l – HW Teamin ing • Configuration • Native Linux administration RDMA • RoCE Bonding is mainly auto configured Device • RoCE Linux Bonding/ • Use transport object (QP, TIS) attribute: port affinity Teaming • RDMA devices associated with eth0, eth1 will be used for port management only (through Immutable caps) • And will unregister and register to drop existing consumers • Register new ib_dev attached to the bond eth1 eth0 • eth0, eth1 will listen on Linux bond enslavement netlink events • New RDMA device will always use vendor pick of PCIe Function (PF0/1 or both) • LACP ((802.3ad) PCIe PCIe • Either handled by Linux bonding/teaming driver PF1 PF0 • Or in HW/FW for supporting NICs (required for many PFs to single phys port configurations) HW • HW Bond Bond • NIC logic for HW forwarding of ingress traffic to bond/team NIC RDMA device Phys • net_dev traffic is passed directly to owner net_dev Phys Port1 according to ingress port Port2

  8. Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) eSwitch Software Model l – Optio ion I VM3 VM2 Native OS SRIOV SRIOV VM0 VM1 Linux/OVS Bridge RDMA Device br0 eth0 rep_vf0 rep_vf1 Linux Switch Device PCIe PF0 PCIe VF0.0 eSwitch PCIe VF0.1 NIC Phys Port

  9. Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) eSwitch Software Model l – Optio ion II VM3 VM2 Native OS SRIOV SRIOV VM0 VM1 Linux/OVS Bridge RDMA Device eth0 rep_eth0 rep_phy0 rep_vf0 rep_vf1 Linux Switch Device PCIe PF0 PCIe VF0.0 eSwitch PCIe VF0.1 NIC Phys Port

  10. Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) eSwitch Software Model l wit ith HA Linux/OVS Bridge Native OS SRIOV SRIOV VM0 VM1 Linux Bonding RDMA Linux Switch Device Device rep_vf0 rep_vf1 eth0 rep_eth0 rep_phy0 rep_phy1 PCIe PCIe PF0 PF1 PCIe VF0.0 eSwitch PCIe HW VF1.0 Bond NIC Phys Phys Port1 Port2

  11. Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) eSwitch Software Model l wit ith Tunneli ling VM3 VM2 SRIOV SRIOV VM0 VM1 OVS-VX Linux/OVS Bridge Bridge vxlan net_device VNI (Key) UDP/IP Stack rep_eth0 rep_phy0 rep_vf0 rep_vf1 Linux Switch Device RDMA PCIe Device PF0 eth0 PCIe eSwitch VF0.0 HW Tunnel PCIe VF0.1 NIC Phys Port

  12. Proceedings of NetDev 1.1: The Technical Conference on Linux Networking (February 10th-12th 2016. Seville, Spain) Multi-PCI Socket NIC QPI CPU CPU • Multiple PCIe end point NIC - NIC can be connected through one or more PCIe buses • Each PCIe bus is connected different NUMA node • Exposed as 2 or more net_device each with it’s own associated RDMA device RDMA Device • Enjoy direct device to local NUMA access Linux Bonding/ Teaming • Application use & feel – would like to work with single net interface • Use Linux bonding with RDMA device eth1 eth0 bonding • For TCP/IP traffic on TX, select slave according to PCIe PCIe calling context affinity PF1 PF0 • For RDMA traffic select slave according to: HW • Transport object (QP) logical port affinity Bond • Or transport object creation thread CPU affinity NIC • Don’t share HW resources (CQ, SRQ) on different CPU Phys sockets – each device has it’s own HW resources Port
