Generation of Verification Conditions Andreas Podelski November 15, 2011

mechanization of correctness proof ◮ given a Hoare triple { φ } C { ψ } , a derivation is a sequence of Hoare triples, each Hoare triple is an axiom (skip, update) or it is inferred by one of the inference rules (seq, cond, while)

mechanization of correctness proof ◮ given a Hoare triple { φ } C { ψ } , a derivation is a sequence of Hoare triples, each Hoare triple is an axiom (skip, update) or it is inferred by one of the inference rules (seq, cond, while) ◮ mechanization:

mechanization of correctness proof ◮ given a Hoare triple { φ } C { ψ } , a derivation is a sequence of Hoare triples, each Hoare triple is an axiom (skip, update) or it is inferred by one of the inference rules (seq, cond, while) ◮ mechanization: ◮ construct a derivation assuming that side conditions hold, ◮ and then check side conditions “discharge the verification condition”

mechanization of correctness proof ◮ given a Hoare triple { φ } C { ψ } , a derivation is a sequence of Hoare triples, each Hoare triple is an axiom (skip, update) or it is inferred by one of the inference rules (seq, cond, while) ◮ mechanization: ◮ construct a derivation assuming that side conditions hold, ◮ and then check side conditions “discharge the verification condition” ◮ if check does not succeed: try another derivation

mechanization of correctness proof ◮ given a Hoare triple { φ } C { ψ } , a derivation is a sequence of Hoare triples, each Hoare triple is an axiom (skip, update) or it is inferred by one of the inference rules (seq, cond, while) ◮ mechanization: ◮ construct a derivation assuming that side conditions hold, ◮ and then check side conditions “discharge the verification condition” ◮ if check does not succeed: try another derivation ◮ next: deterministic strategy to construct unique derivation

System H (1) ◮ Hoare triple { φ } C { ψ } derivable in H if exists a derivation using the axioms and inference rules of H

System H (1) ◮ Hoare triple { φ } C { ψ } derivable in H if exists a derivation using the axioms and inference rules of H ◮ skip { φ } skip { φ }

System H (1) ◮ Hoare triple { φ } C { ψ } derivable in H if exists a derivation using the axioms and inference rules of H ◮ skip { φ } skip { φ } ◮ assignment { ψ [ e / x ] } x := e { ψ }

System H (2) ◮ sequential command C ≡ C 1 ; C 2 { φ } C 1 { φ ′ } { φ ′ } C { ψ } { φ } C { ψ }

System H (2) ◮ sequential command C ≡ C 1 ; C 2 { φ } C 1 { φ ′ } { φ ′ } C { ψ } { φ } C { ψ } ◮ conditional command C ≡ if b then C 1 else C 2 { φ ∧ b } C 1 { ψ } { φ ∧ ¬ b } C { ψ } { φ } C { ψ }

System H (3) ◮ while command C ≡ while b do { θ } C 0 { θ ∧ b } C 0 { θ } { θ } C { θ ∧ ¬ b }

System H (3) ◮ while command C ≡ while b do { θ } C 0 { θ ∧ b } C 0 { θ } { θ } C { θ ∧ ¬ b } ◮ strengthen precondition, weaken postcondition { φ } C { ψ } { φ ′ } C { ψ ′ } if φ ′ → φ and ψ → ψ ′

System H (3) ◮ while command C ≡ while b do { θ } C 0 { θ ∧ b } C 0 { θ } { θ } C { θ ∧ ¬ b } ◮ strengthen precondition, weaken postcondition { φ } C { ψ } { φ ′ } C { ψ ′ } if φ ′ → φ and ψ → ψ ′

System H (3) ◮ while command C ≡ while b do { θ } C 0 { θ ∧ b } C 0 { θ } { θ } C { θ ∧ ¬ b } ◮ strengthen precondition, weaken postcondition { φ } C { ψ } { φ ′ } C { ψ ′ } if φ ′ → φ and ψ → ψ ′ ◮ Hoare triple derivable in all logicals models in which implications in side condition are valid

backward construction of derivation ◮ given Hoare triple { φ } C { ψ } , “guess inference rule and guess assumptions” generate Hoare triples from which we could infer { φ } C { ψ } . . . and collect side conditions of inference rule (if any)

backward construction of derivation ◮ given Hoare triple { φ } C { ψ } , “guess inference rule and guess assumptions” generate Hoare triples from which we could infer { φ } C { ψ } . . . and collect side conditions of inference rule (if any) ◮ repeat on generated Hoare triples to generate new Hoare triples until every Hoare triple is an axiom

mechanize backward inference ◮ given Hoare triple { φ } C { ψ } , from what Hoare triples could we have inferred it? . . . using what inference rule?

mechanize backward inference ◮ given Hoare triple { φ } C { ψ } , from what Hoare triples could we have inferred it? . . . using what inference rule? ◮ next: go through each form of command C (skip, update, seq, cond, while)

backward inference ◮ ??? { φ } skip { ψ }

backward inference ◮ ??? { φ } skip { ψ } ◮ derivation can use what axiom and what inference rule?

backward inference ◮ ??? { φ } skip { ψ } ◮ derivation can use what axiom and what inference rule? ◮ axiom for skip { φ } skip { φ }

backward inference ◮ ??? { φ } skip { ψ } ◮ derivation can use what axiom and what inference rule? ◮ axiom for skip { φ } skip { φ } ◮ ‘strengthen precondition, weaken postcondition’ inference rule { φ } C { ψ } { φ ′ } C { ψ ′ } if φ ′ → φ and ψ → ψ ′

backward inference ◮ ??? { φ } skip { ψ }

backward inference ◮ ??? { φ } skip { ψ } ◮ possible derivation sequence: axiom for (skip), followed by weaking of postcondition { φ } skip { φ } { φ } skip { ψ }

backward inference ◮ ??? { φ } skip { ψ } ◮ possible derivation sequence: axiom for (skip), followed by weaking of postcondition { φ } skip { φ } { φ } skip { ψ } ◮ side condition: φ → ψ

backward inference ◮ ??? { φ } skip { ψ } ◮ possible derivation sequence: axiom for (skip), followed by weaking of postcondition { φ } skip { φ } { φ } skip { ψ } ◮ side condition: φ → ψ ◮ possible derivation sequence: axiom for (skip), followed by strengthening of precondition { ψ } skip { ψ } { φ } skip { ψ }

backward inference ◮ ??? { φ } skip { ψ } ◮ possible derivation sequence: axiom for (skip), followed by weaking of postcondition { φ } skip { φ } { φ } skip { ψ } ◮ side condition: φ → ψ ◮ possible derivation sequence: axiom for (skip), followed by strengthening of precondition { ψ } skip { ψ } { φ } skip { ψ } ◮ same side condition: φ → ψ

new axiom for skip ◮ { φ } skip { ψ } if φ → ψ

new axiom for skip ◮ { φ } skip { ψ } if φ → ψ ◮ old axiom & strengthening of precondition

new axiom for skip ◮ { φ } skip { ψ } if φ → ψ ◮ old axiom & strengthening of precondition ◮ φ is a precondition for ψ under skip if and only if φ → ψ is valid

new axiom for skip ◮ { φ } skip { ψ } if φ → ψ ◮ old axiom & strengthening of precondition ◮ φ is a precondition for ψ under skip if and only if φ → ψ is valid ◮ ψ is the weakest precondition for ψ under skip

new axiom for update ◮ { φ } x := e { ψ } if φ → ψ [ e / x ]

new axiom for update ◮ { φ } x := e { ψ } if φ → ψ [ e / x ] ◮ old axiom & strengthening of precondition

new axiom for update ◮ { φ } x := e { ψ } if φ → ψ [ e / x ] ◮ old axiom & strengthening of precondition ◮ φ is a precondition for ψ under x := e if and only if φ → ψ [ e / x ] is valid

new axiom for update ◮ { φ } x := e { ψ } if φ → ψ [ e / x ] ◮ old axiom & strengthening of precondition ◮ φ is a precondition for ψ under x := e if and only if φ → ψ [ e / x ] is valid ◮ ψ [ e / x ] is the weakest precondition for ψ under x := e

new rule for seq ◮ old rule: { φ } C 1 { θ } { θ } C 2 { ψ } { φ } C 1 ; C 2 { ψ }

new rule for seq ◮ old rule: { φ } C 1 { θ } { θ } C 2 { ψ } { φ } C 1 ; C 2 { ψ } ◮ new rule: { φ 1 } C 1 { φ 2 } { φ 2 } C 2 { ψ } φ → φ 1 { φ } C 1 ; C 2 { ψ }

new rule for seq ◮ old rule: { φ } C 1 { θ } { θ } C 2 { ψ } { φ } C 1 ; C 2 { ψ } ◮ new rule: { φ 1 } C 1 { φ 2 } { φ 2 } C 2 { ψ } φ → φ 1 { φ } C 1 ; C 2 { ψ } ◮ let φ 2 be the weakest precondition of ψ under C 2 and let φ 1 be the weakest precondition of φ 2 under C 1

new rule for seq ◮ old rule: { φ } C 1 { θ } { θ } C 2 { ψ } { φ } C 1 ; C 2 { ψ } ◮ new rule: { φ 1 } C 1 { φ 2 } { φ 2 } C 2 { ψ } φ → φ 1 { φ } C 1 ; C 2 { ψ } ◮ let φ 2 be the weakest precondition of ψ under C 2 and let φ 1 be the weakest precondition of φ 2 under C 1 ◮ φ is a precondition for ψ under C 1 ; C 2 if and only if φ → φ 1 is valid

new rule for seq ◮ old rule: { φ } C 1 { θ } { θ } C 2 { ψ } { φ } C 1 ; C 2 { ψ } ◮ new rule: { φ 1 } C 1 { φ 2 } { φ 2 } C 2 { ψ } φ → φ 1 { φ } C 1 ; C 2 { ψ } ◮ let φ 2 be the weakest precondition of ψ under C 2 and let φ 1 be the weakest precondition of φ 2 under C 1 ◮ φ is a precondition for ψ under C 1 ; C 2 if and only if φ → φ 1 is valid ◮ the weakest precondition of ψ under C 1 ; C 2 is the weakest precondition of (the weakest precondition of ψ under C 2 ) under C 1

new rule for cond ◮ old rule: { φ ∧ b } C 1 { ψ } { φ ∧ ¬ b } C 2 { ψ } { φ } if b then C 1 else C 2 { ψ }
