Linux Plumbers Conference 2016 Enabling Fast Per-CPU User-Space Algorithms with Restartable Sequences mathieu.desnoyers@efcios.com
What are Restartable Sequences (rseq) ? ● Idea originating from Paul Turner and Andrew Hunter (Google), ● Synchronization mechanism for per-CPU data, ● Collaboration between kernel and user-space, – Shared Thread-Local Storage (TLS) between kernel and user-space, – Registered through a new system call, – Kernel and user-space restart critical section if preempted or interrupted by a signal. ● Accelerate algorithms which make use of per-CPU data. 2
Problems Addressed by Restartable Sequences ● Modifying per-CPU data from user-space is slow compared to Thread-Local Storage (TLS) data updates, – Due to atomicity requirements caused by preemption and migration, – A thread can be preempted at any point, requiring cpu-local atomic operations, – A thread can be migrated at any point between getting the current CPU number and writing to per-CPU data, – Requires lock-prefixed atomic operations on x86, load-linked/store- conditional on ARM, PowerPC, ... 3
Problems Addressed by Restartable Sequences ● Modifying data shared between threads and signal handlers requires cpu-local atomic operations, – Due to atomicity requirements caused by signal delivery, – A thread can be interrupted by a signal handler at any point (unless signals are explicitly ignored or blocked), requiring cpu-local atomic operations, – Requires cpu-local atomic operations on x86, load-linked/store- conditional on ARM, PowerPC, ... – Those are slower than normal load/store operations, – Affects both TLS and per-CPU data structures. 4
Problems Addressed by Restartable Sequences ● User-space cannot efficiently disable preemption, migration, nor signal delivery, for short critical sections, ● On x86, LOCK-prefixed and cpu-local atomic operations are costly compared to non-atomic operations, ● On Power8, Load-Linked/Store-Conditional atomic operations are costly compared to non-atomic operations, – May also be the case on large ARM 32/64 SoCs ? 5
Use-Cases Benefiting from per-CPU data over TLS ● Memory allocators speed and memory usage, – Workloads with more threads than CPUs, – Workloads with blocking threads, – E.g. webserver performing blocking I/O, databases, web browsers, ● Ring buffers speed (tracing), – http://lttng.org user-space tracer, ● RCU grace-period tracking in user-space, – Speed and facilitates implementation of multi-process RCU, – http://liburcu.org 6
Restartable Sequences Algorithm Commit Nestable C.S. Critical section protected by kernel Sequence counter protected critical moving instruction pointer to abort section. Can be implemented in C. handler. Needs to be implemented Sequence counter comparison done in assembly. Ends with a single store within IP-fixup critical section. instruction. Preemption or signal delivery restarts the critical section constructed from the two overlapping regions. 7
ABI: Restartable Sequences TLS Structure Commit Nestable C.S. store PTR load+compare load load struct rseq { int32_t cpu_id; uint32_t event_counter; struct rseq_cs *rseq_cs; }; (simplified: pointers are actually 64-bit integers) 8
ABI: RSeq Critical Section Descriptor struct rseq_cs { void *start_ip; void *post_commit_ip; void *abort_ip; }; Commit Nestable C.S. (simplified: pointers are actually 64-bit integers) 9
Using Restartable Sequences ● Intended to be used though library – librseq.so / rseq.h ● Register/unregister threads: – rseq_register_current_thread() – rseq_unregister_current_thread() – Can be done lazily with pthread_key ● Mark beginning of Nestable C.S. – rseq_start() 10
Using Restartable Sequences ● Commit sequence: – rseq_finish() ● Single-word store (final commit) – rseq_finish2() ● Speculative single word store followed by final commit single-word store ● Can be used for ring buffer pointer push: – Speculative store to next slot (pointer) followed by final store to head offset, – rseq_finish_memcpy() ● Speculative copy of an array followed by final commit single-word store, ● Can be used for ring buffer inline data push: – Speculative memcpy into ring buffer, followed by final store to head offset. 11
Interaction with Debugger Single-Stepping ● Restartable sequences will loop forever (no progress) if single-stepped by a debugger, ● Handling of debugger single-stepping can be performed entirely user- space, ● Three approaches: – Split counters fallback (fastest, only for split-counters), – Flag test with locking fallback, – Reference counter test and atomic operation fallback. 12
Per-CPU Counter Example: Split Counters Fallback struct test_data_entry { uintptr_t count; uintptr_t rseq_count; }; struct rseq_state rseq_state; intptr_t *targetptr, newval; int cpu; Read by summing bool result; count + rseq_count for rseq_state = rseq_start(); each CPU. cpu = rseq_cpu_at_start(rseq_state); newval = data->c[cpu]. rseq_count + 1; targetptr = &data->c[cpu]. rseq_count ; if (unlikely(!rseq_finish(targetptr, newval, rseq_state))) uatomic_inc(&data->c[cpu]. count ); 13
Per-CPU Counter: Locking Fallback struct test_data_entry { uintptr_t rseq_count; }; struct rseq_state rseq_state; intptr_t *targetptr, newval; int cpu; bool result; The do_rseq() macro do_rseq(&rseq_lock, rseq_state, cpu, result, does two attempts targetptr, newval, with rseq, then { fallback to locking. newval = data->c[cpu].rseq_count + 1; targetptr = &data->c[cpu].rseq_count; }); 14
Per-CPU Counter: Reference Count Fallback rseq_state = rseq_start(); if (!uatomic_read(&rseq_refcount)) { /* Load refcount before loading rseq_count. */ cmm_smp_rmb(); cpu = rseq_cpu_at_start(rseq_state); newval = data->c[cpu]. rseq_count + 1; targetptr = &data->c[cpu]. rseq_count ; if (likely(rseq_finish(targetptr, newval, rseq_state))) return; /* Success. */ } put_ref = refcount_get_saturate(&rseq_refcount); cpu = rseq_current_cpu_raw(); uatomic_inc(&data->c[cpu]. rseq_count ); if (put_ref) { /* inc rseq_count before dec refcount, match rmb. */ cmm_smp_wmb(); uatomic_dec(&rseq_refcount); } 15
Restartable Sequences: ARMv7 Benchmarks ARMv7 Processor rev 4 (v7l) Machine model: Cubietruck Counter increment speed (ns/increment) 1 thread 2 threads global volatile inc (baseline) 5.6 N/A percpu rseq inc 40.8 41.2 percpu rseq rlock cmpxchg 49.6 50.1 percpu rseq spinlock 95.9 96.7 percpu atomic inc 56.3 56.4 (__sync_add_and_fetch_4) percpu atomic cmpxchg 66.1 67.1 (__sync_val_compare_and_swap_4) global atomic inc 49.6 82.4 (__sync_add_and_fetch_4) global atomic cmpxchg 52.9 181.0 (__sync_val_compare_and_swap_4) global pthread mutex 155.3 932.5 16
Restartable Sequences: x86-64 Benchmarks x86-64 Intel(R) Xeon(R) CPU E5-2630 v3 @ 2.40GHz: Counter increment speed (ns/increment) 1 thread 8 threads global volatile inc (baseline) 2.3 N/A percpu rseq inc 2.1 2.6 percpu rseq rlock cmpxchg 3.0 3.4 percpu rseq spinlock 4.9 5.2 percpu LOCK; inc 6.2 6.9 percpu LOCK; cmpxchg 10.0 11.6 global LOCK; inc 6.2 134.0 global LOCK; cmpxchg 10.0 356.0 global pthread mutex 19.2 993.3 17
Restartable Sequences: Power8 Benchmarks Power8 Guest with 64 vcpus(8 vcores) (atomics implemented with relaxed ll/sc): Counter increment speed (ns/increment) 1 thread 16 threads 32 threads global volatile inc (baseline) 6.5 N/A N/A percpu rseq inc 6.8 7.1 8.4 percpu rseq rlock cmpxchg 7.0 10.0 15.3 percpu rseq spinlock 19.3 24.4 51.4 percpu atomic inc 16.3 17.5 21.1 percpu atomic cmpxchg 30.9 32.5 49.9 global atomic inc 18.5 1937.6 4701.8 global atomic cmpxchg 26.9 4106.2 12642.6 global pthread mutex 400.0 4167.3 8462.9 18
CPU Number Getter Speedup ● ARM32 currently reads current CPU number through system call, ● ARM32 cannot implement vDSO approaches similarly to x86, no segment selector, ● Solution: add a current CPU number field to the rseq TLS ABI, – Kernel updates the current CPU number value before each return to user-space, – User-space gets the current CPU number from a simple thread-local storage variable load. 19
CPU Number Getter Speedup on ARM32 ARMv7 Processor rev 4 (v7l) Machine model: Cubietruck - Baseline (empty loop): 8.4 ns - Read CPU from rseq cpu_id: 16.7 ns - Read CPU from rseq cpu_id (lazy register): 19.8 ns - glibc 2.19-0ubuntu6.6 getcpu: 301.8 ns - getcpu system call: 234.9 ns Speedup rseq over glibc getcpu: 35:1 20
