Cooperative Environment for Traffic Systems that improves energy efficiency of vehicles - eCoMove Project Overview Detlef Kuck Ford Research & Advanced Engineering www.ecomove-project.eu www.ecomove-project.eu

EC co-funded research project “eCoMove” 22.5 M � • Total budget: 13.7 M � (DG-INFSO) • EC funding: • Project duration: 1. April 2010 – 31. March 2013 • 32 Partners: • OEMs (Ford, Fiat, BMW, Volvo Trucks, DAF Trucks) • Automotive suppliers (e.g. Continental, Bosch, Magneti Marelli) • Map suppliers (NavTeq, TomTom) • Traffic system suppliers & Road operators (e.g. Peek traffic, PTV) • Communication systems & Network suppliers (e.g. NEC) • Universities & Research Institutes (e.g. DLR, IKA, TNO, TU Munich) 2

Vision and motivation Energy eCoMove Solutions �������������������� � - Inefficient deceleration - Wrong gear & engine speed eCoMove benefit - Excessive speed, acceleration - Poor anticipation ��������������� - Congestion - Poorly synchronised signals ���������������������� - Choice of inefficient route ������������������������������ ���������������������� - Lack of know-how, motivation ~ ~ ~ ~ Energy consumption of Energy consumption of ~ ~ ~ ~ “perfect eco-driver” “perfect eco-driver” Situation today The future Time

Research questions 1. To what extent can eCoMove solutions decrease fuel consumption / CO 2 emissions of vehicle/fleet/network with cooperative technologies ? 2. How can eCoMove sustainably change the behaviour of private and professional drivers into a more eco- friendly driving style ? 3. What impact have eCoMove solutions in a cooperative environment for the traffic system of a city/region/network (smoother flows, congestion avoidance, shorter travel distances and times)? Our challenge as a project: to have all sectors working towards integrated solutions and standards

Integrated approach for “Green Mobility” �������� �������������!��������������� Factors "������������ inefficient route choice • ������������������������������������������� • �������������������������� excess acceleration/speed �����������������#�������� wrong gear/speed choice • ����������������������������������������� • ������������������������������ inefficient deceleration eCoMove $�������!���������#������� savings target = 20% • �������������� !�������"������# improvement not sustained • $���%���������&������������ of total energy use �������������������� lack of motivation • ���������������������� • "������������������������&��� #��!�����%������������������ too many stops • '������������������������ • ����������(��� • ���������������������� non-optimised signals ����������������������� unstable flow, speed too high • )���������&���(���������� • *������������������������ congestion ���������������������� • ��������������������� ���������������!!��� Theoretical minimum Theoretical minimum • ���������������������������������������� fuel consumption for • ������������������ fuel consumption for specific ~ ~ ~ ~ specific vehicle, driver vehicle, driver ����������������� and journey and journey Situation today The future

Finding the answer: Focus on existing inefficiencies • Pre-trip inefficiencies – Vehicle condition – Trip planning • On-trip inefficiencies – Primary driving tasks • Accelerating/decelerating • Gear changing • Idling • Keeping speed • Unnecessary stops – Secondary driving tasks • Inefficient routing (due to unexpected events) – Non-driving tasks • Vehicle condition & (electrical) energy consumers

Project objectives To develop a combination of cooperative systems and tools using V2V and V2I communication to help: • drivers sustainably eliminate unnecessary fuel consumption; • fleet managers manage their vehicles more economically and promote eco-driving through feedback & incentives; • road operators balance traffic flows in the most energy efficient way. Target is to reduce up to 20% fuel consumption and therefore CO 2 emission

Status: what do we have today Logistics Transport Route Traffic Planning Centre Data Management Office (pre trip) Centre Traffic management centers broadcasting Traffic management centers broadcasting Traffic often jammed, mostly uncoordinated Traffic often jammed, mostly uncoordinated Traffic management centers controlling Traffic management centers controlling Logistic centers for commercial transport Logistic centers for commercial transport A road network A road network Traffic lights Traffic lights traffic messages traffic messages traffic lights traffic lights

eCoMove System Concepts Logistics Traffic Situations Route Traffic Centre Data Transport Management (pre trip) Planning Centre Office Post trip data collection eco horizon Maneuver & Traffic Data Request for Green Remaining Red/Green Time

Cooperative data exchange as enabler

ecoSmartDriving applications • ecoTripPlanning (pre trip) application to enable green routing • ecoSmartDriving (on trip) comprising three applications – dynamic ecoNavigation : integrating information from the traffic centre, infrastructure, ecoMaps, ecoCooperative Horizon – ecoDriving support : dynamic advice to drive with least fuel consumption based on driving context, traffic, driving tasks and strategies, driver’ driving style, vehicle typology and fuel usage – ecoInformation : information to tune other vehicle functions to minimise fuel consumption • ecoPostTrip (post trip) driver’s record used to optimise eco-driving coaching • ecoMonitoring relevant eco floating car data distributed anonymously to the traffic control centre

ecoFreight & Logistics • in-vehicle Truck ecoNavigation, i.e. most efficient route for trucks • ecoDriver Coaching System for goods vehicle drivers: – Pre-trip : ecoDriving training system with virtual simulator where the driver experiences the eCoMove system and its use cases – On-trip : real-time eco driving advice on in-vehicle display – Post-trip : fleet management backoffice to analyse trends, give feedback to the drivers, handle incentives • cooperative ecoTour Planning taking into account previous missions – Find the best combination of vehicle, trailer, route, driver, system configuration based on Mission information, Traffic Management data, Truck & driver models and Routing system – Feedback from previous missions to adapt /optimise the planning & routing system

ecoTrafficManagement & Control • ecoAdaptive Balancing & Control strategies for traffic control, improving traffic network energy efficiency through traffic signal optimisation • ecoAdaptive Traveller Support to drivers through information on traffic state, route recommendations and speed profile data needed by on-board assistance systems • ecoMotorway Management combining energy-optimised flow management on interurban network with ramp metering and merging assistance at vehicle level

Validation & Evaluation • Conduct a study on European level on driver motivation and behavioural change • Validate that eCoMove technologies, applications and services meet the functional and non-functional requirements (e.g. data privacy and protection) • Demonstrate that the eCoMove framework supports the interaction of the applications and services to meet the expectations of all stakeholders • Show that eCoMove technologies, applications and services enable a more energy efficient land-based transport of passengers and goods

eCoMove IP Milestones � � � � 11/2010: Use cases & requirements � � � � 02/2011: Architecture & system specification � � � � 09/2011: eCoMove communication platform � � � � 04/2012: Applications ready for integration 07/2012: Applications and test vehicles ready for evaluation 10/2012: ITS World Congress Vienna demonstration 03/2013: Evaluation results 2013: eCoMove final event
