DepED Computerization Program (DCP) Batch 7 FERDINAND Q. SAN JOSE, MIT Project Development Officer II, Assistant Officer-In-Charge Information & Communication Technology Unit Technical Service

Outline of Presentation • D epED C omputerization P rogram – Counterpart requirements of the recipient schools – Multimedia Classroom Package – 3-Day Face to Face Lecture and Hands-on Training Package

Counterpart requirements of the recipient schools

Multimedia Classroom • The Multimedia Classroom should be 9 m X 7 m or approximately 63 sq. m. in floor area and should be ready to house two (1) Host PC and twelve (6) Computer Terminals

2. (7) pieces of Computer Tables and (35) pieces of Chairs

Cables for the Ceiling Mounted Projector • (1) VGA Cable (15 meters)- A VGA cable is a lead used for transmitting video signals. It is most commonly used to link computers with monitors. However, it is now used on some high definition televisions.

• (1) Extension Cord (15 meters)-An extension cord , power extender , or extension lead is a length of flexible electrical power cable (flex) with a plug on one end and one or more sockets on the other end (usually of the same type as the plug).

Note: Aircon is NOT REQUIRED

4. (2) units of Stand Fan

5. Sufficient Lighting

6. Window and Door Grills

7. Proper electrical wirings with circuit breaker

8. Standard electrical outlets with appropriate load capacity

9. Electrical Grounding

10. Engaging the Assistance of Barangay Tanods

Multimedia Classroom Package for 2,837 Elementary Schools

Scope of Work of the Supplier for the Multimedia Classroom Package 1. Supply of the ICT Equipment 2. Delivery of the ICT Equipment 3. Installation of the ICT Equipment 4. Testing ICT Equipment 5. Conduct a 3-day Face to Face Lecture and Hands-on Training

Brand and Model: Acer Veriton M490 Others : With Recovery CDs (Burned copy is acceptable containing the Microprocessor: 2.66 Ghz, 6MB L2 cache, 1333MHz FSB, Operating System, Virtualization Software, Microsoft Office, Anti- Number of Core 4 virus and Device Drivers. (per school) (DEPED TO PROVIDE THE Motherboard: INSTALLER AND THE LICENSE KEY OF THE SOFTWARE BUT THE Memory: Two 240-pin DDR SDRAM Dual Inline Memory SUPPLIER SHALL BE TASKED TO REPLICATE THE SAID INSTALLER) Module and Supports DDR3 1333Mhz DIMM Classroom Management Software Audio: On board 2 channel audio system or 2-channel Audio •Can Broadcast Lessons Card •Can call attention of individual or all students Video: On board graphics subsystem •Monitor and Control student PCs •Can shutdown the terminal from the Host PC LAN Support: On board 10/100 Mbps LAN Utility and Manufacturer’s Logo/Name must be etched or printed in Peripheral Interfaces: 10 USB 2.0 ports (4 in front and 6 at the the motherboard back), 2 Serial ATA interface Motherboard, Monitor, Casing, Keyboard, Mouse and Speaker must Memory: 4GB DDR3 be of the same brand Hard Disk: 320 GB 7200 rpm (SATA) Copy the Open Desk Kit into the computer hard disk to be provided Optical Drive: DVD-/+RW (SATA) by DepEd Central Office. Monitor: 19” LCD Wide Shall install and provide recovery discs (burned copy acceptable) of Video: Support up to 1.7GB (Graphics memory is shared with the Operating/Application System: (DEPED TO PROVIDE THE system memory) INSTALLER AND THE LICENSE KEY OF THE SOFTWARE BUT THE Speaker: External (For Host PC only) SUPPLIER SHALL BE TASKED TO REPLICATE THE SAID INSTALLER) Keyboard: at least 104 keys, USB interface WITH INSTALLATION OF WINDOWS MULTI-USER APPLICATION SUITE PROVIDED BY DEPED Mouse: Optical PS/2 or USB interface w/ mouse pad Windows Multi-user application Suite (1:6) Warranty: 3 yrs warranty on parts, labor and on site service •WinMultipointSvr 2010 ALNG MVL •WinMultipointSvr 2010 ALNG MVL DvcCAL wWinSvrCAL •Office Enterprise ALNG LicSAPk MVL Partners in learning • Forefront Client Security Suite (1 year subscription)

Brand and Model: NComputing U170 ACCESS TERMINAL Ports: (1) VGA monitor port, (2) PS/2 keyboard and mouse port, (1) USB port, (1) headphone out port, (1) mic in port Input power: No external power adapters are required, power to the access devices is provided by the USB ports With LED Power/Connection: Yes Video resolution: 1280x1024, 1440x900 , 32 bit Connection to Shared PC: 6 pcs USB Cable (10 meters each, without signal loss) with USB booster (Third Party branded USB Booster is Acceptable) Software CD: Soft copy driver and user’s manual Certifications: FCC Class B, CISPR Class B, CISPR 24 Supported Operating systems: Multi Point Server Warranty: 3 yrs warranty on parts, labor and on site service

Brand and Model: Acer V193HQVb 18.5” LCD Monitor Standard or Wide VGA cord Power cord Other: LCD monitor must be of the same brand with the LCD Monitor of the host PC Warranty: 3 yrs warranty on parts, labor and on site service Brand and Model: Acer Keyboard and Mouse At least 104 keys for keyboard PS2 or USB for keyboard and mouse Other: Keyboard and Mouse must be of the same brand with the Keyboard and Mouse of the host PC Warranty: 3 yrs warranty on parts, labor and on site service

Brand and Model: Emerson Liebert PS500-PH Output Typical Backup Time at Full load: 1min Output Power capacity: 300Watts/500VA (300watts) Max Configurable Power: 300Watts/500VA Communication and Management Nominal Output Voltage: 230V Control Panel Output Connections LED Status display with On Line: On (2) NEMA 5-15R (Battery Backup) Battery Nominal Output Voltage: 230V Audible Alarm Input Frequency: 60Hz Alarm when on battery: distinctive Input Connections: NEMA 5-15P low Cord Length: 1.00 meter Battery alarm: overload continuous Input Voltage range for main operations: 180- tone alarm 260V Surge Protection and Filtering Batteries and Runtime Surge energy rating: 180joules Battery Type: Maintenance-free sealed Warranty: 2 years including the Typical recharge time: 24hrs batteries (Automatic Replacement) Typical Backup Time at Half load: 11mins (150watts)

Brand and Model: Promethean ActivBoard 587 Pro Operating System Requirements: Windows XP, Win Server, MAC OS System Component: Board Size 87" diagonal Type of Operation: Touch Based System Pointing Device: Pen or Finger (NOTE: The Interactive White Board that comes with a pen can also be activated by means of touch or finger and shall not be dependent on the pen alone) Connection: USB Cable or Cat5 Cable with USB adaptor Accessories: System/Driver and Authoring Software and Educational Resources for Windows Server Must have an online community of educational resources and lessons of at least 1,000 pieces that are ready to be used. A list of these resources should be submitted Must be in the Top 5 Interactive Whiteboards in the world and at least 8 years in the market With Wall mounting Bracket With Interactive Pen Term and Conditions: 3 years service and parts

Brand and Model: Brother DCP-J125 Up to Resolution: 6000 x 1200 Scan Technology (Interchageable) Scanner Type: Flatbed Black and Color: Yes Scanning Resolution: Up to 600dpi Paper size: A4, Letter, Legal PC Interface: USB 2.0 or high-speed USB Print speed Cables: USB cable and Power cord Black Text (A4): Approx. 33 ppm Power Voltage: 220-240v 50/60Hz Color Text (A4): Approx. 27 ppm OS Compatible: Windows Vista / Windows XP / Photo 10x15cm / 4x6in: Approx. 60 sec per Mac OS photo (Draft) (THE COUNTING OF TIME Warranty: 2 years service and parts SHALL COMMENCE FROM THE TIME THE Others PRINTER HEAD STARTS TO MOVE) With driver software CD Copy Technology Black Text (A4): Approx. 22 cpm (Draft) Color Text (A4): Approx. 20 cpm (Draft)

Brand and Model: Acer X1261P Projector type: DLP ANSI Lumens: 2700 ANSI Lumens Native Resolution: 1024 x 768 pixels Lamp Hrs: 5000hrs Contrast Ratio: 3700:1 Others: With power cable, VGA cable, Remote Control, CDs and User’s Manual (hard copy and softcopy), carrying case and With projector ceiling mounting kit Warranty: 2 years warranty on the unit, on parts and service except for the lens, 90calendar days or 500hours warranty on the lamp

Brand and Model: Acer Mouse and 10-port USB Hub Interface: USB for mouse (same brand as host PC) For 10-Port USB Hub: USB Interface: USB 2.0 High-Speed Interface, backwards compatible with USB 1.1 USB Ports: 10 USB Port LED: LED Blinks when data is accessed WARRANTY: One (1) year warranty for USB and mouse.

Multimedia Classroom Layout

Classroom Instruction Model

Multimedia Classroom Layout
