Aeroqual AQY 1 micro air quality monitoring system Our Vision To make air quality information relevant to people wherever they live, work, and play. 2 Aeroqual in Numbers 2001 2017 Founded by Prof. New global HQ in David Williams and

  1. Aeroqual AQY 1 micro air quality monitoring system

  2. Our Vision To make air quality information relevant to people wherever they live, work, and play. 2

  3. Aeroqual in Numbers 2001 2017 Founded by Prof. New global HQ in David Williams and Auckland, New Dr Geoff Henshaw Zealand #1 10,000 Most Innovative More than 10,000 Product, NZ High instruments in use Tech Awards 2016 around the world 7 1,000 Patents covering No. of cities we have sensor fabrication, successfully delivered instrument design projects in 3

  4. U.S. EPA R&D Collaboration • 5-year Cooperative Research and Development Agreement signed late 2017 between U.S. EPA and Aeroqual official announcement • Objective: to accelerate new applications, methods and technologies for low-cost air quality monitoring • Aeroqual – contribute air sensor technology, application expertise, and data interpretation experience • U.S. EPA – provide air monitoring infrastructure and air pollution measurement capabilities • Location: U.S. EPA Ambient Monitoring Innovative Research Station (AIRS) in Research Triangle Park, North Carolina, USA 4

  5. Our Customers 5

  6. Our Products AQM 65 AQY 1 Portable Dust+Gas Sentry Dust Sentry Product Air Quality Station Micro Station Air Monitors PM 10 , PM 2.5 , PM 1 , TSP, NO 2 , CO, PM 10 , PM 2.5 , PM 1 , TSP, PM 10 , PM 2.5 , NO 2 , CO, O 3 , SO 2 , Measurement PM 10 , PM 2.5 , PM 1 , TSP, PM 2.5 , NO 2 , O 3 , O 3 , SO 2 , NOx, VOC, H 2 S, CO 2 , VOC, NO 2 , O 3 , VOC, H 2 S, CO 2 , NH 3 , CH 4 , Cl 2 , Parameters Meteorological, Noise Temp, RH NH 3 ,Meteorological, Noise Meteorological, Noise Temp, RH User Configurable Yes Yes Yes No Yes Power Supply Mains recommended Mains, solar, battery Mains, solar, battery Mains, solar, battery Mains, solar, battery -35 ° C to +50 ° C -10 ° C to +45 ° C -10 ° C to +50 ° C -10 ° C to +40 ° C 0 ° C to +40 ° C Operating Range IP 3 3 IP Rating IP65 IP65 IP65 IP31 Weight <50KG <13KG <13KG <1KG <1KG Design Life - System 10 years 10 years 10 years 5 years 5 years - Sensors 2 yrs (gas) to 5+ yrs (PM) 2 yrs (gas) to 5+ yrs (PM) 5+ years (PM) 1 to 2 years 1 to 3 years Sampling Method Pump Pump Pump Fan / Diffusion Fan / Diffusion Pre-shipment, Pre-shipment, Pre-shipment, Pre-shipment, Pre-shipment, Calibration Field (certified gas) Field (certified gas) Field (co-location) Field (co-location) Factory / Lab Approvals MCERTS, FCC, CE MCERTS, Rule 1466, FCC, CE MCERTS, Rule 1466, FCC, CE FCC, CE FCC, CE ★★★★★ ★★★★ ★★★★ ★★★ ★★ Typical Data Quality Maintenance Cost 20% p.a. 20% p.a. 10% p.a. 15% p.a. 10% p.a. % of purchase price Indicative Price US$ $20 to 50K $8 to 18K $6 to 12K $3 to 4K $1 to 3K *all information indicative only, subject to change without notice

  7. New: AQY 1 A ‘low cost’ micro air quality monitor that produces scientifically credible data, yet is simple to set up and easy to use. “The Aeroqual AQY multi-sensor units performed very well compared to more expensive FEM/FRM instruments and overall showed excellent correlation for ozone, and very good correlation and high accuracy for NO2 and PM2.5 .” - AQ-SPEC: Air Quality Sensor Performance Evaluation Center 7

  8. AQY roadmap Developed under a multi-year R&D project funded by NZ government 2015 Field tested in NZ, US and China 2016 Designed to give indicative measurement of key pollutants at 2017 an affordable price point Available for pilot scale evaluation. 100 node network in Los Angeles. 2018 Commercial release of full production version 1 June 2018 8

  9. AQY – applications Roadside traffic Emergency response / Community groups / Smart city grid networks emissions event monitoring citizen science Schools and childcare Community exposure Mapping smog formation Validation of air quality health and safety studies and distribution models 9

  10. AQY 1 specifications Parameters O 3 , NO 2 , PM 2.5 , Temp, RH, dew point Power 12V DC plug pack, 24W Dimensions 215H x 170W x 125D mm Calibration Factory calibration, remote calibration optional On-board PC 1.2GHz quad-core, 1GB SDRAM, 16GB SDHC Storage, Linux OS Comm’s WIFI, cellular Software Aeroqual Connect / Cloud, API For complete specifications please use the following link. 10

  11. AQY – API • Access the API on our cloud servers (AWS) • Rest API - use any programming language that supports HTTP requests/replies with cookies • Supports up to one API call per second per username • Through the API you can: • Get a list of devices, • Get data for each of those devices • Get and set settings for those devices • Full details on the API available HERE. 11

  12. Aeroqual Care Aeroqual’s support plan – two years included with purchase of the device Aeroqual Connect and Cloud Secure data storage and backup Remote technical support software licenses to third party servers Free upgrades to the latest sensor Discounts on replacement sensors Get sent automatic alerts on algorithms and spare parts device diagnostics 12

  13. Maintenance & Servicing • AQY intended to be ‘no touch’ for 12 months+ • Sensor life is key determinant of unscheduled maintenance; it varies by level of PM pollution* • When sensor fails, an alert is sent, and standard operating procedure is to: • Return whole device to base • Replace failed sensors (simple mechanical process) • Return device to field. • Annual maintenance ~10% of purchase cost typical. *sensor life ~12months based on 0-50 μg /m3 annual average PM10 13

  14. Independent test AQ-SPEC was set up by South Coast AQMD in Los Angeles to provide independent testing of low cost air quality sensing devices. All manufacturers are invited to send devices for testing. Results are made publically available on the AQ-SPEC website. AQ- SPEC’s summary report on the AQY : • Minimal down-time : data recovery from each unit was higher than 90% • Low intra-model variability for all measured pollutants • Ozone sensors showed excellent correlation with a more expensive FEM instrument (R 2 > 0.95) • NO2 V2 sensors showed very good correlation with a more expensive FRM instrument (R 2 > 0.74) and high accuracy • PM2.5 sensors showed very good correlation with more expensive FEM instruments (GRIMM: R 2 > 0.84 and BAM: R 2 > 0.83) and high accuracy • Temperature and relative humidity sensors showed excellent correlation with the SCAQMD Met Station sensors (T: R 2 > 0.91 and RH: R 2 > 0.94) Full report available here. 14

  15. AQY – unique technology • O 3 sensor uses Aeroqual’s patented gas sensitive semiconductor (GSS) for unrivalled sensitivity, stability and selectivity • NO 2 sensor combines patented algorithms with our O 3 sensor to eliminate cross interferences common to other ‘NO 2 ’ sensors • Automatic baseline correction (ABC) modulates between sample and zero flow conditions to remove diurnal and seasonal temperature and humidity effects • Light-scattering optical particle sensor has algorithms for humidity and temperature compensation, and an anti-static inlet • 1 part-per-billion (ppb) detection of O 3 and NO 2 . 15

  16. AQY vs other low cost monitors • Advanced measurement techniques – not off the shelf sensors • All measurement is done on the device – many other devices rely on data processing in the cloud before outputting a measurement • More than 2 years’ data storage on the device, allowing for fail- safe back-up • Aeroqual Cloud is used for data acquisition and display and remote diagnostics. Software is bundled with the instrument providing a complete product package , • Product is backed by a decade of field experience deploying and supporting sensor-based instruments in a wide range of outdoor ambient applications. 16

  17. Los Angeles AQY network • 100 AQY devices deployed across Los Angeles in partnership with South Coast Air Quality Management District (SC AQMD) and UCLA • Funding provided through EPA Star Grant and NZ Government R&D funding • First 25 units have been operational since Dec 2017, network complete by March 2018 • SC AQMD is under pressure to show progress towards rule AB617 a state law that requires ‘community - level’ air quality monitoring. 17

  18. LA – device locations Riverside Downtown - Port Imperial County 18

  19. LA – data flows • SC AQMD has access to the data via API for their own analysis • Citizens and schools are logging in via Aeroqual Cloud • Aeroqual is applying third party software tools to analyse and visualise the data • A richer picture is emerging of PM 2.5 , O 3 , and NO 2 patterns in the region. 19

  20. Smart Cities Case Study • Itron (ITRI: NASDAQ) is a leading provider of smart meters and networks for utilities and cities • Aeroqual partnered with Silver Spring Networks, acquired by Itron early 2018 • Aeroqual has integrated Silver Spring Network’s mesh radio, enabling two - way communication over the network • AQY units are installed on smart lights that operate on Itron’s network • Demonstration projects established in San Antonio, New Orleans, and Chicago 20

  21. Aeroqual Lim imit ited 460 Rosebank Rd, Avondale, Auckland, New Zealand t. +64 9 623 3013 e. sales@aeroqual.com www.aeroqual.com Keep in in touch
