A simple, scalable app architecture with Android annotations Luke - PowerPoint PPT Presentation

A simple, scalable app architecture with Android annotations Luke Sleeman Freelance Android developer lukesleeman.com.au Image CC: https://flic.kr/p/6oqCZB

Agenda • Introduction • The architecture - an overview • Services • Domain object • Testing • UI • Other issues • Closing thoughts

Introduction - why we need this at all

Goals • Quick, simple • Typically data driven apps - get some stuff from a web service, store it locally, show it to the user, submit stuff back to the web service • Scalable - Handle small apps and big ones • Unsurprising, easy to jump in and out of, clear and concise, makes sense to anybody. ‘Obvious’. • Testable • Need to be able to incrementally evolve towards it from an existing codebase • Boring!

The architecture! User Interface Domain objects Services

This is what it looks like

So what about Android annotations? AndroidAnnotations User Interface Domain objects Services

What is AndroidAnnotations? • Annotate your code - works of JDK annotations • Code generation - you can look behind the curtain to see how the magic works. MyActivity_ • Includes annotation support for a lot of other libraries I use such as ormlite • You don’t have to use it • But you would be silly not to :-)

Services User Interface Domain objects Services

Typical methods List<Users> getUsersFromWebservice() � AndroidDatabaseResults searchForSite(String searchText) � UserInfo getInfoFromFacebook(int key)

A Simple Service public class PizzaService { private static List<Pizza> pizzas; public static List<Pizza> getPizzas(){ if(pizzas == null){ pizzas = new ArrayList<Pizza>(); pizzas.add(new Pizza("Luke Special", 10.50)); pizzas.add(new Pizza("Margherita", 9.50)); } return pizzas; } }

A more complex service @EBean(scope = EBean.Scope.Singleton)
 public class FriendService { @OrmLiteDao(helper = ExampleDBHelper.class, model = Friend.class)
 protected RuntimeExceptionDao<Friend, String> friendsDao; @RestService
 protected FriendListWebservice webservice; public List<Friend> getFriends(){
 return friendsDao.queryForAll();
 } public void downloadAndSaveFriend(int id)throws IOException {
 Friend newFriend = webservice.getFriend(id);
 friendsDao.create(newFriend);
 }
 }

Domain objects User Interface Domain objects Services

A simple domain object public class Pizza { � private String name; private double price; � public Pizza(String name, double price) { this.name = name; this.price = price; } � public String getName() { return name; } � public void setName(String name) {

A more complex domain object @DatabaseTable
 public class Friend { � @DatabaseField(generatedId = true)
 private int id; � @DatabaseField
 private String userName; � public int getId() {
 return id;
 } � public void setId(int id) {
 this.id = id;
 } � public String getUserName() {
 return userName;


Domain objects Relationships

Domain objects Relationships • Option 1 - In the objects @ForeignCollectionField(foreignFieldName = "user")
 private List<EmailAddress> addresses; • Option 2 - In the service public List<EmailAddress> getFriendEmails(int id)

Unit tests User Interface Domain objects Unit Tests Services

A basic test public class PizzaTest extends AndroidTestCase{ public void testGetPizzas(){ List<Pizza> pizzaList = PizzaService.getPizzas(); assertNotNull(pizzaList); } } � public class FriendTest extends AndroidTestCase { public void testFriend(){ FriendService friendService = FriendService_.getInstance_(getContext()); assertNotNull(friendService.getFriends()); } }

A more advanced test public class FriendTest extends AndroidTestCase { @Override
 protected void setUp() throws Exception {
 File database = getContext().getDatabasePath(ExampleDBHelper.DB_NAME);
 if (database.exists()) {
 database.delete();
 }
 } public void testSearchFriends(){
 FriendService service = FriendService_.getInstance_(getContext());
 service.createOrUpdateFriend(new Friend("Luke"));
 assertEquals(1, friendService.search("lu").size());
 } }

A nifty trick public void downloadAndPatchFriendList()
 throws IOException{ String patchFile = downloadPatchFile();
 List<Friend> updatedFriends = parsePatch(patchFile);
 mergeFriendsWithDB(updatedFriends); }

A nifty trick @EBean(scope = EBean.Scope.Singleton)
 public class TestFriendService extends FriendService { @Override
 public void mergeFriendWithDB(List<Friend> updatedFriends){
 super.mergeFriendsWithDB(updatedFriends);
 } @Override
 public List<Friend> parsePatch(String patchFile) {
 return super.parsePatch(patchFile);
 } }

A nifty trick private TestFriendService testFriendService =
 TestFriendService_.getInstance_(getContext()); � public void testParseEmpty(){ List<Friend> friends = testFriendService.parsePatch(EMPTY_PATCH); assert... } � public void testParseModifyFriends(){ List<Friend> friends = testFriendService.parsePatch(MODIFY_PATCH); assert... }

The UI User Interface Domain objects Services

This is where android annotations really shines • @EActivity, @EFragment, @EViewGroup • @ViewByID @FragmentByID, etc • @DrawableRes @AnimationRes, @HtmlRes • @Click, @ListClick

Getting services and domain objects @EActivity(R.layout.activity_best_friend)
 public class BestFriendActivity extends Activity { @ViewById(R.id.best_friend_text)
 protected TextView bestFriendText; @Bean
 protected FriendService friendService; private Friend bestFriend; @AfterViews
 protected void setupBestFriend(){
 bestFriend = friendService.getBestFriend();
 bestFriendText.setText(bestFriend.getName());
 } @Click(R.id.poke_friend_button)
 protected void poke(){
 friendService.poke(bestFriend);
 } }

Threading @EActivity(R.layout.activity_friend_list)
 public class FriendListActivity extends Activity { @ViewById(R.id.friend_list)
 protected ListView list; @ViewById(R.id.loading_progress)
 protected ProgressBar progressSpinner; @Bean
 protected FriendService service; @AfterViews
 protected void startDownload(){
 progressSpinner.setVisibility(View.VISIBLE);
 downloadFriends();
 }

Threading @Background
 protected void downloadFriends(){
 try{ List<Friends> friendList = service.downloadFriendList();
 displayFriends(friendList);
 }
 catch(IOException e){
 displayDownloadError();
 }
 } @UiThread
 protected void displayFriends(List<Friends> friendList){
 progressSpinner.setVisibility(View.GONE);
 …
 } � @UiThread
 protected void displayDownloadError(){
 progressSpinner.setVisibility(View.GONE);
 …
 } }

There is a bug!

Threading @Background
 protected void downloadFriends(){
 try{ List<Friends> friendList = service.downloadFriendList();
 displayFriends(friendList);
 }
 catch(IOException e){
 displayDownloadError();
 }
 } @UiThread
 protected void displayFriends(List<Friends> friendList){
 progressSpinner.setVisibility(View.GONE);
 …
 } � @UiThread
 protected void displayDownloadError(){
 progressSpinner.setVisibility(View.GONE);
 …
 } }



 Threading - dealing with activity shutdown • Option 1 - Let our background task run and don’t update ui @UiThread
 protected void displayFriends(List<Friend> friendList){
 if(isDestroyed()) return;
 … Option 2 - Cancel background task
 @Background(id = "download")
 protected void downloadFriends(){ …. }
 @Override
 protected void onDestroy() {
 BackgroundExecutor.cancelAll("download", false);
 super.onDestroy();
 }

Other issues

Evolving an existing apps architecture 1. Add in android annotations and clean out boilerplate 2. If you don’t have them start creating domain objects - move logic from UI into them. 3. If you don’t have them start creating services - have them mange your domain objects

Things to look at changing • Different libraries replace AA (dagger, retrofit, butterknife) • EventBus or RXJava • Pinch ideas from the google io app. • Come up with a good way to manage fragments

Closing thoughts

A humble request • Architecture is important! • Don’t be satisfied with just the simple architecture presented … • Think about architecture! • Talk about architecture! • Develop new architectures!

Questions?

Bonus slides

When not to use this architecture • Games • If your building one app over the course of years • If you can develop a large internal library of reusable components
