When an alarm is false, every penny counts… …When its real, every minute counts.

Facts and Problems FACT: More than 90% of alarms are false. Burglary, Fire, … FACT: Verification rules are being increased (BS8243) with less tolerance from Policy forces around UK and Ireland. FACT: Police respond faster to a visual verification of intruders on site FACT: New rules on Panic Alarms potentially will require verification before police will respond FACT: Sequential verification works….but sometimes is not enough especially in high risk applications 2

Application - RealAlarm RealAlarm is a standalone or retro fit system that delivers real- time capture of alarm events, using wireless devices, enabling central stations to provide better response to alarms  Video Verification system, plus sound.  Wireless operation from camera’s to control panel  5 year battery life  GPRS signalling to central station  DD243 / BS8243 visual verification compliant  Images can be forwarded via email to users  Standalone, or retro fit to existing hardwired/wireless system RealAlarm enables REAL decisions based on REAL information 3

How does it work ? Monitoring Centre 1.Alarm Event ! Images are received at the control panel and despatched to the ARC via GPRS Intruder alarm images are automatically sent to the control panel GPRS Network 3.Response Operator receives the alarm and images Panic and Fire Alarms (streamed together as cause the control panel to video) which can also activate the camera PIR’s be emailed direct to 2.Communication and to take a batch of the key holder 4 4 images

The RealAlarm Kit p/n 0-101781  28 Wireless Zones, 1 Wired Input  Colour and B/W with Infra-red for  Arm/disarm for darkness  Internal GSM/GPRS module standalone systems  Fully programmable from panel  Audible and visual included  Up to 8 User Codes  90 ° Angle camera overlaps PIR field indication  Long lasting battery of view  Up to 8 Keyfobs  10m range in complete darkness  Up to 8 2-way keypads overlaps PIR range  Up to 3 Wireless Sirens  Captures images of fast moving  Internal power supply intruder  Auto-setup (Brightness, Contrast);  Up to 10 cameras Note – SIM card not  Optionally enabled audio with images included. Order part for listen-in number Z-UK072-0.  Pet variant (Next CAM K9 PG2) 5  Battery life: 5 years

Additional Components Next /Next K-985 PG KF-234 PG KP-140 PG MC-302 PG Next /Next Pet Cam Standard & Pet PIR Keyfob Keypad Door Contact PIR Camera 0-10212 / 0-102116 0-102118 0-102127 0-102119 0-102123 / 0-102122 SMD-426 PG SR-720 PG SR-730 PG SMD-427 PG RP-600 PG Smoke Sensor Internal Siren External Sounder Smoke & Heat Sensor Repeater 0-500167 0-102124 0-102125 0-500168 0-102117 6

RealAlarm: Retrofit RealAlarm solution retrofitted on existing alarm system. Enhance existing system with visual verification Low cost, effective, battery powered solution Images Images Wired Alarm Signal Images Alarm Messages Wired Alarm Signals Wired Alarm System 7

What does the ARC see ? Images are sent as snap shots so they start to arrive within 20 seconds of the alarm at the ARC. Within 50 seconds up to 10 snap shots are received and streamed together as video. 8

What does the ARC see ? Camera’s are programmed at the control panel for either black and white or colour images. Image resolution is also programmable as well as contrast and brightness. Email forwarding is programmed at the control panel 9

FAQ’s Q. Is a central station needed ? A. Yes, although there are options if only email notification is required. Contact your account manager for assistance. Q. Does the system replace CCTV ? A. No, RealAlarm is for the ARC or Key holder to verify the cause of the alarm only. Q. Can I use any contract SIM card ? A. Yes, provided it has access the GPRS (2G) network and you have the APN login details. We do not recommend PAYG SIM’s are used. Q. Do the camera’s work in the dark ? A. Yes, camera’s switch to black and white during darkness and have an IR illumination with up to 10M range

10 Sales Points 1. Suitable for commercial and residential applications . 2. Its wireless using two way wireless PowerG technology – just connect 230vac Up to 5 year battery life on CAM PIR’s – plug-in replacement battery 3. packs . Up to 8 years on other products. 4. Compliance with BS8243 for Intruder and Panic alarms . Ideal for premises that need increased level of verification. 5. Simple programming and setup – Kits are pre-programmed ready to use with only central station and network details needed. 6. Up to 10 cameras can be installed, plus other accessories for a complete standalone system. 7. Ideal for Retro fit installation – connect to an existing hardwired control panel 8. Devices are programmed from the control panel - change picture size, colour, event counter etc. Can also be programmed remotely from office location. 9. Fast image transfer – start to arrive in the ARC with 20 seconds and build in to a video within 60 seconds. 10. Email address programmed at the control panel enabling the installer to change as necessary. Picture sent directly to customers PC or smart phone 11

Any Questions ? We are here to help, just call:- South London / South - Adam 07747 448798 North above Coventry - Andy 07974 139093 South - Simon 07738 000901 Ireland / Post sales support - Andy B 07920 824426 Product Support - UK +44 (0)845 0755802 Ireland 051 272172 Product Support Email - productsupport.uk@visonic.com

Thank You No wires, no mess, no fuss !
