Voice of the Market 25% 25% 23% 20% 15% 10% 10% 5% 5% 8% - PowerPoint PPT Presentation

Voice of the Market 25% 25% 23% 20% 15% 10% 10% 5% 5% 8% 5% 3% 0% 5% 3% Photocell Presence Corner 3% Detector Emerg Mount Vandal Resis Colours Textured Int Control LED Gear Prismatic Diffuser Denver Elite Wall Model


  1. Voice of the Market 25% 25% 23% 20% 15% 10% 10% 5% 5% 8% 5% 3% 0% 5% 3% Photocell Presence Corner 3% Detector Emerg Mount Vandal Resis Colours Textured Int Control LED Gear Prismatic Diffuser

  2. Denver Elite Wall Model Production Concept

  3. Strategic Aim  Latest discharge lamp and gear technologies.  Inclusion of an LED light source  Offer a low upward light wall luminare.  Ability to provide up to 100W HID solution.  Part of a growing family of products.

  4. Optical Arrangement  Two glass lens. • Clear glass lens for LED variants. • Prismatic glass lens for HID & CFL variants.  2,000 lm LED unit mounted at 3m. • Provides 9m spacing • 4m forward throw • 20 lux average • 40% uniformity  Option for reduced upward light • Circa 3% ULOR LED version (standard) • <5.0% ULOR HID Version (with uplight shield)

  5. LED  Order codes for LED’s have been changed to now clearly represent the LED module performance Product Code Description L014 LED light engine producing c.1,000 lm with a nominal 4000K colour temperature L024 LED light engine producing c.2,000 lm with a nominal 4000K colour temperature Colour L034 LED light engine producing c.3,000 lm with a nominal 4000K colour temperature temp LED Lumen package

  6. LED “Soak Testing”  The Denver Elite Wall, as with all Acuity LED products, is put through a “Soak Testing” regime that ensures that early failures are captured . This ensures that our customers receive products that have been put through the stringent LED testing to avoid early on-site failure.  Details of the soak testing process are included in the LED Guidelines document.

  7. Characteristics A - LM6 die cast aluminium housing (front and back). Ensures IP65 rating, robustness and Non corrosive material. B1 - LED = Clear glass lens B2 - HID/CFL = Prismatic glass lens C - Three screws allow ease of access during maintenance whilst maintaining luminaire robustness D - External ribs on the back casting ensures heat dissipation away from gear and allow air flow between the luminaire and wall surface for cooling.

  8. Characteristics E - Electronic gear or LED driver mounted directly to the back casting to aid heat dissipation. F - Internal reflector system that works in conjunction with the glass prismatic refractor to direct light and achieve optical performance. G - Optional ULOR shield used with HID and CFL options. Provides <5% upward light Ensuring BREAM compliance (for clarity the image shows a bare casting with no lens).

  9. Characteristics H - LED version features a clear glass lens. Light is controlled by individual lenses on each LED I - 32 LED light engine module behind clear glass lens providing a BREAM compliant circa 3% ULOR. J & K - Each LED has individual lens. Lenses in group ‘J’ push the light sideways providing wide spacing's. Group ‘K’ controls the light going forward of the fitting.

  10. Characteristics L - Photocell option designed into casting ensuring that the product appearance remains uncompromised. M - Half shears located at the top, back, left and right side of back casting ensures a variety of entries into the lumainaire and installation options as standard. N- Half shears (on all entry options) is a new and improved knock out feature which gives the installer the ability to remove them without distorting the casting.

  11. Voice of the Market 25% 25% 23% 20% 15% 10% 10% 5% 5% 8% 5% 3% 0% 5% 3% Photocell Presence Corner 3% Detector Emerg Mount Vandal Resis Colours Textured Int Control LED Gear Prismatic Diffuser

  12. Voice of the Market 25% 25% 23% 20% 15% 10% 10% 5% 5% 8% 5% 3% 0% 5% 3% Photocell Presence Corner 3% Detector Emerg Mount Vandal Resis Colours Textured Int Control LED Gear Prismatic Diffuser

  13. Product Highlights  Designed to IP657 and 20 Joules impact resistant.  Wide spacing's with LED version.  Registered Design  Flexibility during installation  Available with electronic gear only.

  14. Features & Benefits Two Lenses Types • Specific glass lenses designed to achieve the best optical performance for HID, CFL or LED. Vandal Resistant Design • Die cast aluminum body provides a robust and vandal resistant product. LED BREAM compliant • Meets European light pollution Guidelines. Thermal Management • Back casting with ribs and offset feature from wall allow heat dissipation away from the electronic gear, extending the life of the gear. HID & CFL Installer Friendly • Variety of on-site wiring options available. • Improved knockouts

  15. Marketing Support  Product brochure has been printed and is available.  Website will be updated to highlight product availability with PDF download in the coming weeks.  LED Guidelines are available
