Systems Design and Programming Arch. of the 80x86 CMPE 310 Basic Architecture Basic components ISA EISA Bus Microprocessor I/O System Memory Memory VESA Bus PCI DRAM Bus 8086 Plotter Printer SRAM through Serial Keyboard Cache


  1. Systems Design and Programming Arch. of the 80x86 CMPE 310 Basic Architecture Basic components ISA EISA Bus Microprocessor I/O System Memory Memory VESA Bus PCI DRAM Bus 8086 Plotter Printer SRAM through Serial Keyboard Cache Pentium IV Monitor Floppy ROM Tape Hard Drive Flash Scanner Mouse EEPROM DVD CDROM L A N R Y D UMBC A B M A L T F O U M B C I M Y O R T 1 (Jan. 30th, 2002) I E S R C E O V U I N N U T Y 1 6 9 6

  2. Systems Design and Programming Arch. of the 80x86 CMPE 310 Basic Architecture Bus Architecture: Address bus Microprocessor Data bus MWTC MRDC IOWC IORC DRAM Keyboard ROM Printer The Pentium bus architecture is not this simple. We will elaborate on this later. L A N R Y D UMBC A B M A L T F O U M B C I M Y O R T 2 (Jan. 30th, 2002) I E S R C E O V U I N N U T Y 1 6 9 6

  3. Systems Design and Programming Arch. of the 80x86 CMPE 310 Basic Bus Architecture Bus Architecture: Three buses: • Address: If I/O, a value between 0000H and FFFFH is issued. If memory, it depends on the architecture: 20 -bits (8086/8088) 24 -bits (80286/80386SX) 25 -bits (80386SL/SLC/EX) 32 -bits (80386DX/80486/Pentium) 36 -bits (Pentium Pro/II/III) • Data: 8 -bits (8088) 16 -bits (8086/80286/80386SX/SL/SLC/EX) 32 -bits (80386DX/80486/Pentium) 64 -bits (Pentium/Pro/II/III) • Control: Most systems have at least 4 control bus connections (active low). MRDC (Memory ReaD Control), MWRC , IORC (I/O Read Control), IOWC . L A N R Y D UMBC A B M A L T F O U M B C I M Y O R T 3 (Jan. 30th, 2002) I E S R C E O V U I N N U T Y 1 6 9 6

  4. Systems Design and Programming Arch. of the 80x86 CMPE 310 Basic Bus Architecture Bus Standards: ISA (Industry Standard Architecture): 8 MHz 8-bit (8086/8088) 16-bit (80286-Pentium) EISA : 8 MHz 32-bit (older 386 and 486 machines). PCI (Peripheral Component Interconnect): 33 MHz 32-bit or 64-bit (Pentiums) VESA (Video Electronic Standards Association): Runs at processor speed. 32-bit or 64-bit (Pentiums) Only disk and video. Competes with the PCI but is not popular. L A N R Y D UMBC A B M A L T F O U M B C I M Y O R T 4 (Jan. 30th, 2002) I E S R C E O V U I N N U T Y 1 6 9 6

  5. Systems Design and Programming Arch. of the 80x86 CMPE 310 Basic Bus Architecture Bus Standards: USB (Universal Serial Bus): 10 Mbps (extensions to 100Mbps) Newest systems. Serial connection to microprocessor. For keyboards, the mouse, modems and sound cards. To reduce system cost through fewer wires. AGP (Advanced Graphics Port): 66MHz Newest systems. Fast parallel connection: Across 64-bits for 533MB/sec. For video cards. To accommodate the new DVD (Digital Versatile Disk) players. L A N R Y D UMBC A B M A L T F O U M B C I M Y O R T 5 (Jan. 30th, 2002) I E S R C E O V U I N N U T Y 1 6 9 6

  6. Systems Design and Programming Arch. of the 80x86 CMPE 310 Basic Memory Architecture Bank layout High bank Low bank FFFFF FFFFFF FFFFFE FFFFE FFFFFD FFFFFC 8 bits 8 bits 8 bits Odd bytes Even bytes 1 MB 8 MB 8 MB 00002 000005 000004 00001 000003 000002 00000 000001 000000 D7-D0 D15-D8 D7-D0 8086 (1MB only) 8088 80286, 80386SX 80386SL/SLC(32MB) L A N R Y D UMBC A B M A L T F O U M B C I M Y O R T 6 (Jan. 30th, 2002) I E S R C E O V U I N N U T Y 1 6 9 6

  7. Systems Design and Programming Arch. of the 80x86 CMPE 310 Basic Memory Architecture Bank layout Bank 3 Bank 2 Bank 1 Bank 0 FFFFFFFF FFFFFFFE FFFFFFFD FFFFFFFC FFFFFFFB FFFFFFFA FFFFFFF9 FFFFFFF8 8 bits 8 bits 8 bits 8 bits 1 GB 1 GB 1 GB 1 GB 0000000A 00000009 00000008 0000000B 00000007 00000006 00000005 00000004 00000003 00000002 00000001 00000000 D31-D24 D23-D16 D15-D8 D7-D0 80386DX, 80486 L A N R Y D UMBC A B M A L T F O U M B C I M Y O R T 7 (Jan. 30th, 2002) I E S R C E O V U I N N U T Y 1 6 9 6

  8. Systems Design and Programming Arch. of the 80x86 CMPE 310 Basic Memory Architecture Bank layout Bank 7 Bank 6 Bank 5 Bank 4 FFFFFFFF FFFFFFFE FFFFFFFD FFFFFFFC FFFFFFF7 FFFFFFF6 FFFFFFF5 FFFFFFF4 8 bits 8 bits 8 bits 8 bits 512 MB 512 MB 512 MB 512 MB 00000015 00000017 00000016 00000014 0000000F 0000000D 0000000E 0000000C 00000007 00000006 00000005 00000004 D63-D56 D47-D40 D55-D48 D39-D32 Bank 3 Bank 1 Bank 2 Bank 0 FFFFFFFB FFFFFFF9 FFFFFFFA FFFFFFF8 FFFFFFF1 FFFFFFF3 FFFFFFF2 FFFFFFF0 8 bits 8 bits 8 bits 8 bits 512 MB 512 MB 512 MB 512 MB 00000013 00000012 00000011 00000010 0000000B 0000000A 00000009 00000008 00000003 00000002 00000001 00000000 D31-D24 D23-D16 D15-D8 D7-D0 Pentium/Pro/II/III L A N R Y D UMBC A B M A L T F O U M B C I M Y O R T 8 (Jan. 30th, 2002) I E S R C E O V U I N N U T Y 1 6 9 6

  9. Systems Design and Programming Arch. of the 80x86 CMPE 310 Basic I/O Architecture DRAM (Main Memory) Active Processes ISR NIC NIC ISR sound I/O Space Other OS code FFFF Interrupt Vectors 0000 Mem Ports Bus I/O Bus Micro IRQs Sound card INTR processor 0 1 2 ... 7 Ports PIC L A N R Y D UMBC A B M A L T F O U M B C I M Y O R T 9 (Jan. 30th, 2002) I E S R C E O V U I N N U T Y 1 6 9 6

  10. Systems Design and Programming Arch. of the 80x86 CMPE 310 Interrupt Vectors (DOS PC) Address Interrupt # FFFFFH 1FH 7C-7F Video Graphic Chars Pts to Data BIOS Program Area 1EH 78-7B Diskette Parameters 1DH 74-77 Video Initialization 1CH 70-73 Timer Tick (18.2/sec) Read-Only Memory 1BH 6C-6F Keyboard Break 1AH 68-6B Software Interrupts Time of Day 19H 64-67 Bootstrap Synchronous 18H 60-63 Resident BASIC 17H 5C-5F Printer 16H 58-5B Keyboard 15H 54-57 Cassette 14H 50-53 Communications 13H 4C-4F Diskette/Disk 12H 48-4B Memory 11H 44-47 Equipment Check 10H 40-43 Video Hardware Interrupts FH 3C-3F Printer EH 38-3B Diskette Asynchronous DH 34-37 Disk CH 30-33 8259A Communications BH 2C-2F 00500H Communications AH 28-2B Reserved BIOS Data area 64 long words 9H Keyboard 24-27 8H 20-23 Time of Day 00400H 7H 1D-1F Available Int. vectors Reserved 6H 224 long words 18-1B Microprocessor Reserved (DOS int #s 20H-3FH) 5H 14-17 Print Screen 00080H Interrupts 4H 10-13 Overflow (CPU) 32 long words Interrupt Vectors 3H C-F Breakpoint (CPU) 2H 00000H 8-B Non-maskable (8087) 1H 4-7 Single Step (CPU) DRAM (Main Memory) 0-3 0H Divide by zero (CPU) L A N R Y D UMBC A B M A L T F O U M B C I M Y O R T 10 (Jan. 30th, 2002) I E S R C E O V U I N N U T Y 1 6 9 6

  11. Systems Design and Programming Arch. of the 80x86 CMPE 310 I/O Space It is important to notice that these I/O addresses are NOT memory-mapped addresses on the 80x86 machines. I/O Device Space FFFF I/O Expansion Area COM1 03F8 Floppy Disk Controller 03F0 CGA Adapter 03D0 0378 LPT1 Hard Disk Controller 0320 64K 8-bit I/O devices COM2 02F8 8255 (PIA) 0060 Timer (8253) 0040 Interrupt Controller 0020 DMA Controller 0000 Special instructions (IN/OUT) are used to communicate to the I/O devices. L A N R Y D UMBC A B M A L T F O U M B C I M Y O R T 11 (Jan. 30th, 2002) I E S R C E O V U I N N U T Y 1 6 9 6
