The Geomorphic Road Analysis and Inventory Package (GRAIP) - PowerPoint PPT Presentation

The Geomorphic Road Analysis and Inventory Package (GRAIP) Abdulrazzaq AlQashan Julia Campo Parker Jones Zach Kretsch Background Research Designed to inventory impacts of road systems on surface erosion and sediment delivery to bodies


  1. The Geomorphic Road Analysis and Inventory Package (GRAIP) Abdulrazzaq AlQashan Julia Campo Parker Jones Zach Kretsch

  2. Background Research Designed to inventory impacts of road systems on surface erosion and ● sediment delivery to bodies of water [1] Identifies: ● Hydrologic connectivity ○ Landslide and gully initiation risk [1] ○ Stream crossing failure and diversion risk [1] ○ GRAIP has only been used in the Rocky Mountain region and is now being ● evaluated for Odell Lake in Coconino County 2

  3. Project Understanding Goal Statement: Use the GRAIP process to analyze runoff of roads within ● the south fork watershed to assess the success of the GRAIP process, followed by creating recommendations based off of cost and effectiveness. GRAIP is a process that derives from TerraSync and ArcGIS to model the ● road inventory TerraSync: Data dictionary describing road and runoff features and ○ connections ArcGIS: Compiles geospatial data to create an inventory map ○ 3

  4. Project Understanding Potential challenges include: ● In-depth modeling using Terrasync and ArcGIS ○ Making recommendations for road erosion and sediment delivery ○ abatement design Stakeholders include: ● United States Forest Service ○ Dr. Wilbert Odem (TA) ○ Tom Runyon (Client) ○ Coconino County (water quality) ○ Munds Park users and residents ○ 4

  5. NAU N Odell Lake Figure 1: Proximity of Odell Lake to NAU [2] 5

  6. South Fork Watershed, Munds Park, AZ 2 watersheds drain ● N Odell Lake into Odell Lake USFS Road NF-9492D Scope focuses on the ● southern watershed Watershed area ● =0.86 square miles [4] Legend: South Fork Watershed 6 Figure 2: Watershed of focus for GRAIP Analysis [3]

  7. Scope of Work Task 1: Training ● 1.1: Learning the softwares included in the GRAIP process 1.2: Preliminary site visit Task 2: Site Investigation ● 2.1: Conduct road inventory 2.2: Collecting data 2.3: Collecting Photos Figure 3: Data Collector [6] 7

  8. Scope of Work Task 3: Mapping ● 3.1: Creating a road inventory using TerraSync software 3.2: Implement into ArcGIS Task 4: Watershed Analysis ● 4.1: Identify roads of concern 4.2: Determine if USFS road NF-9492D is problematic Figure 4: View of Forest Road in Munds Park, AZ [7] 8

  9. Scope of Work Task 5: Reporting Results ● 5.1: Feasibility of GRAIP on a larger scale 5.2: Decision matrix 5.3: Recommendations for future application Task 6: Deliverables ● 6.1: 50% Analysis Report 6.2: Final Analysis Report 6.3: Final Presentation 6.4: Final Website Figure 5: Odell Lake [8] 9

  10. Figure 6: Gantt Chart with critical path shown in green 10

  11. Staffing Project Engineer: GIS Specialist: ● ● Preplanning for schedules Represent data Using ArcGIS. ○ ○ Maintain project cost Map unofficial forest roads ○ ○ Hydrologist: Field Technician/E.I.T: ● ● Measure water properties of Collect data in field using ○ ○ the area TerraSync Interpret data obtained from Photograph and keep records of ○ ○ Field Technician notable features 11

  12. Expenses Cost Travel Expenses Table 1: Equipment Travel Distance needed and cost of travel Terrasync $1,295.00 (mi) 40 to and from site Data Collector $1,600.00 # of trips 3 Trimble Pro Travel Receiver $325.00 reimbursement $0.65/mile Cost of Travel $80.00 Total Cost - - $3,300.00 Project Field Table 2: Rate of services for Title Engineer Hydrologist GIS Specialist Technician/E.I.T Hours Spent each position and total cost Rate $120.00 $80.00 $60.00 $50.00 - of services [11] Training 4 16 4 16 40 Site Investigation 6 9 9 36 60 Mapping 18 63 63 36 180 Watershed Analysis 13.2 99 0 19.8 132 Reporting Results 50 150 0 0 200 Total Hours 91.2 337 76 107.8 612 Cost $10,955.00 $26,960.00 $4,560.00 $5,390.00 - Cost of Services - - - - $47,855.00 Expenses - - - - $3,300.00 Total Cost of 12 Project - - - - $51,150.00

  13. References 1. “GRAIP Homepage,” Rocky Mountain Research Station - Air, Water, and Aquatic Environments Program . [Online]. Available: https://www.fs.fed.us/GRAIP/. [Accessed: 28-Nov-2017]. 2. “Odell Lake,” Google Maps . [Online]. Available: https://www.google.com/maps/place/Odell Lake/@35.0434318,-111.9078894,10z/data=!4m5!3m4!1s0x872dbd1013cf031d:0x2820b091e0f14e5a!8m2!3d34.9352452!4d-111.6314177. [Accessed: 28-Nov-2017]. 3. USGS StreamStats . [Online]. Available: https://streamstats.usgs.gov/ss/. [Accessed: 28-Nov-2017]. 4. T. A. Runyon, “NAU GRAIP Capstone group meeting,” NAU GRAIP Capstone group meeting , 14-Nov-2017 5. T. A. Black, R. M. Cissel, and C. H. Luce, “The Geomorphic Road Analysis and Inventory Package (GRAIP).” United States Department of Agriculture / Forest Service, Rocky Mountain Research Station, May-2012. 6. “Spectra Recon Data Collector 400 Series RE5-SY4CEN-SS,” Spectra Precision Recon Data Collector 400 Series RE5SY4CENSS Tiger Supplies . [Online]. Available: https://www.tigersupplies.com/Products/Spectra-Recon-Data-Collector-400-Series__SPERECON.aspx. [Accessed: 29-Nov-2017]. 7. “Munds Park AZ to a viewpoint of Sedona AZ through the Coconino National Forest,” YouTube , 18-Sep-2014. [Online]. Available: https://www.youtube.com/watch?v=-N8MW14zq7o. [Accessed: 29-Nov-2017]. 8. “Home,” The Rugged Forge . [Online]. Available: http://www.theruggedforge.com/. [Accessed: 29-Nov-2017]. 9. “ Field software for quality GIS data,” Trimble Store : Product Details . [Online]. Available: https://store.trimble.com/OA_HTML/ibeCCtpItmDspRte.jsp?section=14824&item=796315&sitex=10140%3A22372%3AUS. [Accessed: 29-Nov-2017]. 10. “Trimble Pro Series Receivers,” Trimble Store : Mapping and GIS Customer Store . [Online]. Available: https://store.trimble.com/OA_HTML/ibeCCtpSctDspRte.jsp?section=68193&sitex=10140%3A22372%3AUS. [Accessed: 29-Nov-2017]. 11. PayScale - Salary Search: Salary Reports For Any Job Topic . [Online]. Available: 13 https://www.payscale.com/rcsearch.aspx?category=Job&str=&CountryName=United%2BStates&SourceId=. [Accessed: 28-Nov-2017].
