The Effect of Lime Addition in Physical and Mechanical Soil - PowerPoint PPT Presentation

The Effect of Lime Addition in Physical and Mechanical Soil Properties Due to Drying Process on Bengawan Solo River Embankment in Plangwot Area, Lamongan Alpha Rizky Utthea R P , Ria Asih Aryani S. Dwa Desa Warnana, Januarti Jaya Ekaputri, and


  1. The Effect of Lime Addition in Physical and Mechanical Soil Properties Due to Drying Process on Bengawan Solo River Embankment in Plangwot Area, Lamongan Alpha Rizky Utthea R P , Ria Asih Aryani S. Dwa Desa Warnana, Januarti Jaya Ekaputri, and Yerry Kahaditu F Institut Teknologi Sepuluh Nopember, Indonesia 4 th International Conference on Rehabilitation and Maintenance in Civil Engineering Solo, July 11-12 2018

  2. Outline • Introduction • Methodology • Optimum Condition • Actual Dry Water Content and Drying Process • Physical Properties • Mechanical Properties

  3. Introduction Bengawan Solo River Dry Season Soil on surface Decrease of water level Drying (reduction of water content) Weather Negative pore water The sun+ incrase in temperature preassure increased

  4. Methodology

  5. Optimum Condition 1,460 Optimum Water Maximum Dry 1,440 Lime Content Content Density (%) 1,420 (%) (t/m 3 ) Dry density (gr/cm³) 1,400 3 21,29 1,447 1,380 7 28,20 1,470 1,360 11 31,05 1,427 1,340 15 24,32 1,391 1,320 1,300 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 Water content(%)

  6. Actual Dry Water Content and Drying Process the dry conditions of the field → w c actual dry the lowest groundwater content 11,00 if the soil is drained as the 10,00 actual condition → drying with 9,00 the help of the sun wc (%) 8,00 7,00 6,00 5,00 1 2 3 4 5 6 7 Observation Sample 1 Sample 2 Sample 3 average

  7. Physical Properties With 7% lime w c vs suction(-U w ) γ t vs suction(-U w ) 180000,00 180000,00 content 160000,00 160000,00 Natural Natural 140000,00 140000,00 Lime Stablized Lime Stabilized Specific Gravity 120000,00 120000,00 -U w (kPa) -U w (kPa) 100000,00 100000,00 2,603 → 2,651 80000,00 80000,00 60000,00 60000,00 Void ratio (e) 40000,00 40000,00 20000,00 20000,00 decrease by an R² = 0,9915 R² = 0,9587 R² = 0,961 R² = 0,9972 0,00 0,00 average 12,01% 30 25 20 15 10 5 19 18,5 18 17,5 17 16,5 16 15,5 15 w c (%) γ t (kN/m 3 ) γ t vs void ratio(e) Degree of saturation w c vs void ratio (e) 1,10 1,10 decrease by an average 1,05 1,05 4,093% 1,00 1,00 R² = 0,9766 R² = 0,9767 0,95 0,95 weight volume of soil 0,90 e 0,90 e ( ɣ t ) increased by an R² = 0,9056 0,85 0,85 R² = 0,9548 average 4,093% 0,80 0,80 Natural Natural Lime Stabilized Lime Stabilized 0,75 0,75 0,70 0,70 30 25 20 15 10 5 19 18,5 18 17,5 17 16,5 16 15,5 15 w c (%) γ t (kN/m 3 )

  8. w c (%) vs C u (kN/m 2 ) Mechanical Properties 800 700 Both soil conditions, natural and stabilized soils, show the 600 C u (kN/m 2 ) same tendency due to the drying process. 500 R² = 0,9579 The reduction of moisture content results in the undrained 400 cohesion value of the soil increasing. R² = 0,9602 300 The weight of the soil volume decreased as a result of the reduction in water content. 200 30 25 20 15 10 5 Lime-stabilized soils have greater shear strength than w c (%) natural soils. w c (%) vs γ t (kN/m 3 ) 19,0 Natural soil → maximum value of Cu is 540,6 kN/m 2 at 18,5 ɣ t =15,684 kN/m 3 . 18,0 R² = 0,9767 17,5 γ t (kN/m 3 ) 17,0 Lime-stabilized soil → maximum value of Cu is 705,967 R² = 0,9867 kN/m 2 at ɣ t =16,693 kN/m 3 . 16,5 16,0 Natural Lime Stabilized 15,5 Addition of 7% lime → Cu increased by an average 15,0 of 25,11% 30 25 20 15 10 5 w c (%)

  9. Conclusion • Natural soil has w c opt =26.815% with ɣ d max =1.432 t / m 3 . Optimum lime-stabilized soil with 7% lime content has and w c opt = 28.20% and ɣ d max = 1.470 t / m 3 . The average actual dry water content until the 7 th day drying is 5.61%. In the initial process • of draining the moisture content drops significantly. When water content of about 6% (2 nd observation) decrease due to drying is not very significant. The actual dry water content is about 6%. The reduction of water content is about 2.20%. With 7% lime content , ɣ d max increased from1,43 t/m 3 to 1,47 t/m 3 . Gs increased from 2, • 603 to 2,651. Void ratio (e) decreased by an average 12,01 %, Sr decreased by 8,672 %, ɣ t increased by an average 4,093%. In lime-stabilized soils, the maximum value of Cu is 705,967 kN/m 2 at ɣ t =16,693 kN/m 3 . Due • to the addition of 7% lime , Cu increased by an average of 25,11%. • The addition of lime with the optimum lime content 7% can improve the physical and mechanical properties of Bengawan Solo river embankment due to drying process.

  10. References • Firmansyah, Y. K., Soemitro, R.A.A., Warnana, D. D., Prelimenary Assessment to Bengawan Solo River Embankment Stability. (2016) • Fredlund, D.G., and Rahardjo, H, Soil Mechanics for Unsaturated Soils. (1993) • Fredlund, D.G., Morgenstern, N.R. and Widger, R.A., The Shear Strength of Unsaturated S oils”, Canadian Geotechnical Journal, 15(3): 313– 321 (1978) • Satrya, T.R., Soemitro, R.A.A., Mukunoki, T., Assessment to the Comparison Between The Initial State and Insitu Conditions of Bengawan Solo River Embankment During The Dry and Monsoon Seasons at Kanor-Village. (2015) • Stoltz, G., Cuisinier, O., Masrouri, F., Weathering of a Lime-Treated Clayey Soil by Drying a nd Wtting Cycles. (2014) • Paulus, N., Pengaruh Air Garam pada Proses Pengeringan dan Pembasahan Terhadap Kuat Tekan Geser Tanah Lempung yang Distabilisasi dengan Fly Ash Ditambah Kapur . Surabaya : Tesis Pascasarjana ITS . (2005)

  11. THANK YOU
