STANDGAS STANDALONE DETECTORS FOR THE DETECTION OF TOXIC AND EXPLOSIVE GASES AND OXYGEN Certificado n FS82426 USING CATALYTIC, ELECTROCHEMICAL AND INFRARED TECHNOLOGY PROGRAMMABLE PROVIDED WITH RELAY OUTPUT PELLISTOR SENSORS RESISTANT TO

  1. STANDGAS STANDALONE DETECTORS FOR THE DETECTION OF TOXIC AND EXPLOSIVE GASES AND OXYGEN Certificado nº FS82426

  2. USING CATALYTIC, ELECTROCHEMICAL AND INFRARED TECHNOLOGY PROGRAMMABLE PROVIDED WITH RELAY OUTPUT PELLISTOR SENSORS RESISTANT TO SILICON VAPOURS PLASTIC HOUSING IP65 PROTECTION GRADE Available in four versions: W I T H O U T D I S P L A Y W I T H D I S P L A Y STANDGAS HC STANDGAS HC PRO STANDGAS PRO STANDGAS PRO LCD EXPLOSIVE LCD TOXIC Certificado nº FS82426

  3. STANDGAS HC & HC PRO DESIGNED FOR THE DETECTION OF EXPLOSIVE GASES • OPTICAL INDICATORS FOR STATUS AND SENSOR FAILURE USING CATALYTIC TECNOLOGY (PELLISTOR) • SELECTION OF GAS TO BE DETECTED BY USE OF JUMPER WITH A DETECTION RANGE OF 0 TO 100% L.E.L. • PROGRAMMABLE ALARM RELAY INITIAL STATUS • PROGRAMMABLE ALARM LEVELS • PROGRAMMABLE ALARM RELAY ACTIVATION DELAY STANDGAS HC STANDGAS HC PRO > FOR NON-INDUSTRIAL > FOR INDUSTRIAL USE USE > AVAILABLE FOR VARIOUS > AVAILABLE FOR NATURAL HYDROCARBONS, INCLUDING GAS, METHANE, ACETYLENE PROPANE, BUTANE AND > SENSOR AND COMPENSATOR ARE HYDROGEN INDEPENDENTLY ENCAPSULATED, ENSURING HIGHER LINEARITY AND STABILITY > WITH SINTERED FILTER Certificado nº FS82426

  4. • EXPLOSIVE GASES • TOXIC GASES AND OXYGEN STANDGAS PRO LCD PROGRAMMABLE STANDALONE DETECTORS PROVIDED WITH A BACKLIT 16x2 LINE DISPLAY, THREE KEYS, PROGRAMMABLE ALARM RELAY OUTPUT AND INTERNAL ACOUSTICS IP65 PROTECTION GRADE AVAILABLE IN TWO VERSIONS: OPTIONAL UNIVERSAL SUPPORT ANGLED FOR CEILING AND FLOOR INSTALLATION THAT ALLOWS VISUALIZING THE DISPLAY WHEN A HEAVY (FLOOR) OR LIGHT (CEILING) GAS IS BEING DETECTED. OPTIONAL 230V POWER UNIT WITH A CAPACITY TO SUPPLY FROM 1 TO 10 STANDGAS UNITS. APPLICATIONS: BATTERY ROOMS – PHARMACEUTICAL LABORATORIES – UNIVERSITY LABORATORIES – AIRCRAFT INDUSTRY – WINERIES – GALLERIES – DISTILLERIES – LIVESTOCK INDUSTRY – PETROL STATIONS – BOILER ROOMS – INDUSTRIAL KITCHENS – INDUSTRY IN GENERAL Certificado nº FS82426

  5. STANDGAS PRO LCD DESIGNED FOR THE DETECTION OF EXPLOSIVE GASES USING CATALYTIC TECNOLOGY (PELLISTOR) EXPLOSIVE GASES WITH A DETECTION RANGE OF 0 TO 100% L.E.L. AND RESISTANT TO SILICON VAPOURS. AVAILABLE FOR NUMEROUS HYDROCARBONS, INCLUDING A SPECIAL VERSION FOR ACETYLENE. PROVIDED WITH SINTERED FILTER ALLOWS PROGRAMMING OF THE FOLLOWING: GAS TYPE PREALARM LEVEL ALARM LEVEL RELAY OUTPUT INITIAL STATUS REARM TYPE: MANUAL OR AUTOMATIC REARM TIMING ACTIVATION OR NOT OF INTERNAL ACOUSTICS SYSTEM TEST POSSIBILITY OF INHIBITING THE SENSOR TO PREVENT INAPPROPRIATE ACTIONS IN CASE OF BREAKDOWN OR LACK OF MAINTENANCE Certificado nº FS82426

  6. STANDGAS PRO LCD DESIGNED FOR THE DETECTION OF TOXIC GASES AND OXYGEN TOXIC GASES AND OXYGEN USING ELECTROCHEMICAL TECHNOLOGY, AND OF CO 2 USING INFRARED TECHNOLOGY SPECIAL FUNCTIONS: AVAILABLE FOR: > DIGITAL CONTROL OVER SENSOR STATUS > CARBON MONOXIDE (CO) > AUTOMATIC TESTING OF HARDWARE STATUS > NITROGEN DIOXIDE (NO 2 ) > DIGITAL FILTER BASED ON VARIABLE SAMPLINGS OF THE > AMMONIA (NH 3 ) AVERAGES IN SENSOR VALUES > HYDROGEN SULFIDE (H 2 S) > AUTOMATIC THERMAL COMPENSATION (EXCEPT > SULFUR DIOXIDE (SO 2 ) STANDGAS O 2 , THAT DOES NOT NEED IT) > CHLORINE (Cl 2 ) > EXACT AUTOMATIC ZERO ADJUSTMENT > CARBON DIOXIDE (CO 2 ) > OXYGEN (O 2 ) In factory it is also possible to know the remaining useful life of the sensor, date of manufacture and last calibration, as well as the serial number Certificado nº FS82426
