Stahltec.GmbH 0178/4596289 Info@Stahltec.gmbh Production capacity - PowerPoint PPT Presentation

Stahltec.GmbH 0178/4596289 Info@Stahltec.gmbh Production capacity : 12.000 ton/year Main Plant Stahltec.GmbH Total area: 60.000m Closed area: 30.000m 0178/4596289 Rolling Plant Info@Stahltec.gmbh Total area: 17.800 m Closed area:


  1. Stahltec.GmbH 0178/4596289 Info@Stahltec.gmbh

  2. Production capacity : 12.000 ton/year Main Plant Stahltec.GmbH Total area: 60.000m² Closed area: 30.000m² 0178/4596289 Rolling Plant Info@Stahltec.gmbh Total area: 17.800 m² Closed area: 9.500 m²

  3. Main Plant Establishment : 2017 Total area : 60.000 m² Closed area : 30.000 m² Products : Heat and wear resistant steel castings Production sectors : Cement and mining, Railway, Energy, Earthmoving equipment

  4. Production Facilities

  5. Rolling Plant Establishment : 1986 Total area : 9.500 m² Closed area : 17.800 m² Products : Rolling mill rolls Production sectors : Rolling mill

  6. Moulding

  7. Moulding - 1 (Size 3 & Size 5)

  8. Moulding - 2 (Shuttle System & Manual Moulding)

  9. Moulding - 3 (Pit Moulding)

  10. MELTING & CASTING Capacity Definition Brand Typ (Ton) 1 Melting furnace Inductotherm Tri-Trak 3x10 ton 2 Melting furnace Inductotherm Dual-Trak 2x4 ton 3 Melting furnace Inductotherm Dual-Trak 2x3 ton

  11. MELTING & CASTING

  12. HEAT TREATMENT Capacity Definition Brand Fuel Type Dimensions (mm) (ton) 1 Heat Treatment Furnace Sistem Teknik Electric 4000X3800X1700 10 2 Heat Treatment Furnace Sistem Teknik Natural Gas 4000X3800X1700 10 3 Heat Treatment Furnace Sistem Teknik Natural Gas 4000X3800X1700 10 4 Heat Treatment Furnace Sistem Teknik Natural Gas 3300X3300X1700 10 5 Heat Treatment Furnace Sistem Teknik Natural Gas 3300X3300X1700 10 6 Heat Treatment Furnace Sistem Teknik Natural Gas 2500X3000X1700 5 7 Heat Treatment Furnace Sistem Teknik Natural Gas 3300X3300X1700 10 8 Heat Treatment Furnace Sistem Teknik Natural Gas 4300X4300X2200 15 9 Heat Treatment Furnace Sistem Teknik Electric 4300X4300X2700 35 10 Heat Treatment Furnace Sistem Teknik Natural Gas 5100X5700X1700 15 11 Heat Treatment Furnace Sistem Teknik Electric 2000X3500 5 12 Heat Treatment Furnace Sistem Teknik Electric 2500X3000 10 Heat Treatment Furnace 13 Sistem Teknik Electric 5 (Well Type) Heat Treatment Furnace 14 Sistem Teknik Electric 10 (Well Type)

  13. HEAT TREATMENT

  14. GRINDING & SHOT BLASTING Definition Brand Capacity (ton) Shot blasting machine 40 ton 1 Rösler (automatic + manual) (Usable volume: ø4000 mm / h: 4000 mm) 2 Shot blasting machine(AK1) Endümak 1 ton 3 Shot blasting machine(AK3) Endümak 2,5 ton

  15. GRINDING & SHOT BLASTING

  16. MACHINING Brand Type Quantity 1 YouJi VTL-4000 ATC+C Vertical Lathe 2 2 YouJi VTL-2500 ATC+C Vertical Lathe 2 3 YouJi YV 1200 ATC Vertical Lathe 1 4 YouJi YV 600 Vertical Lathe 1 5 YouJi YV 1000 ATC Vertical Lathe 2

  17. MACHINING

  18. MACHINING POLLING PLANT DESCRIPTION DESCRIPTION 1 Machining equipment Bohrwerk center drill 2 Machining equipment Poreba tcg160*6000 lathe 3 Machining equipment Poreba tcg160*4000 lathe 4 Machining equipment Poreba tcg125*4000 lathe 5 Machining equipment Poreba tcg160*6000 lathe 6 Machining equipment Poreba tcg200*6000 lathe 7 Machining equipment Herkules wd350s lathe 8 Machining equipment Herkules wd350s lathe 9 Machining equipment Herkules wd500le cnc*5000 lathe 10 Machining equipment Herkulesp300/400*5.000 cnc lathe 11 Machining equipment Poreba tcg160x6000 cnc lathe 12 Machining equipment Poreba tr135 b1*4000 lathe 13 Machining equipment Poreba tr115 b3*6000 lathe 14 Machining equipment Herkules wf350 neck milling machine 15 Machining equipment Defum ads115 / 1 7467 boring machine 16 Machining equipment Defum ads115 / 1 7343 boring machine

  19. MACHINING ROLLING PLANT DESCRIPTION DESCRIPTION 17 Machining equipment Herkules ws300 roll grinding machine 18 Machining equipment Herkules uws 450*5000 nc roll grinding machine 19 Machining equipment Zayer kp5000 milling machine 20 Machining equipment Zayer kpc5000 ar milling machine 21 Machining equipment Schiess ag vertical lathe 22 Machining equipment Kna 140 / 160 vertical lathe 23 Machining equipment Kna 110 / 135 a vertical lathe 24 Machining equipment Cnc vertical lathe 25 Machining equipment Tezsan sm35 a pillar drilling machine 26 Machining equipment Hcp wr 50 / 2 radial drilling machine 27 Machining equipment Uzay makina um500 saw 28 Machining equipment Haarmann sharpening machine 29 Machining equipment Simon v35 / 2 sharpening machine 30 Machining equipment Simon l20 / 2 lapping machine 31 Machining equipment Tezsan sn50c lathe 32 Machining equipment Herkules sf100 template milling machine

  20. QUALITY CONTROL • Chemical analysis • Metallographic Inspection • Visual Inspection • Hardness measurement • Impect test • Ultrasonic test Ultrasonic test Metallographic Inspection Tensile • Magnetic particle test test • Liquid penetration test • Surface roughness measurement • Dimension control • Sand analysis Magnetic particle test Chemical analysis Hardness measurement Liquid penetrant test Impect test Sand analysis

  21. Products Cone Crusher Parts

  22. Products Pressure Armatur Housing

  23. Products Brake discs

  24. Products Coal Power Plant

  25. Products Grinding Mill Parts Grinding Ring Grinding Balls

  26. Products Waste Incineration Plants Grate Bar

  27. Products Cement Industry Chain Link Liner Plate Plate Inlet Plate Cooler plates Nozzle Ring Segment

  28. Products Crusher Crusher Ring Conical Crusher Crusher Jaw Hammer

  29. Products Undercarriage Parts Idler Track Shoe Drive Tumbler Roller

  30. Products Earthmoving Equipments • Unitooths • Tips • Cutting Edges and End Bites • Bucket Edges and Segments • Ripper Shanks and Adapters • Ripper Protectors • Grader Edges • Undercarriage Parts
