Southwest Tier 2

Southwest Tier 2 ➢ Computing facility used by the ATLAS experiment ➢ Funded by the National Science Foundation as a subcontract to the U.S. ATLAS Operations program. ➢ A consortium of the University of Texas at Arlington (UTA) and The University of Oklahoma (OU) ➢ One of four Tier 2 facilities in United States of America ➢ There are forty Tier 2 facilities worldwide

Large Hadron Collider ➢ The LHC is a ~17 mile ring crossing between France and Switzerland ➢ Accelerates beams of protons to nearly (0.99999) the speed of light ➢ Collides the beams at certain locations (ATLAS) for data to be recorded ➢ Current Run II provides 13 TeV collisions/events

ATLAS Experiment ➢ The size of a seven story building ➢ 90+ million data channels ➢ 40 million events occur per second ➢ 500-600 events per second are recorded ➢ 4 megabytes per event ➢ 2.5 GB/s stored to

ATLAS Computing Model ➢ Tiered Model with Tiers 0, 1 , ➢ Tier 2 is a regional facility 2 and 3 USA Tier 2's ➢ ➢ Tier 0 is central facility Northeast Tier 2 ➢ ATLAS Great Lakes Tier2 ➢ CERN ➢ Midwest Tier 2 ➢ ➢ Tier 1 is a national facility Southwest Tier 2 ➢ Brookhaven National ➢ Tier 3 is an institutional ➢ Laboratory (BNL) for the USA facility University or group cluster ➢

ATLAS Tier 2 Roles ➢ Provides CPU cycles for: User Analysis ➢ Monte Carlo simulations of ➢ events Reprocessing exercises ➢ ➢ Provides Storage for: Physics Data ➢ From recorded collisions ➢ From simulated collisions ➢ User Analysis Results ➢

Southwest Tier 2 resources ➢ OU UTA ➢ UTA_SWT2 OU_OCHEP ➢ ➢ Dedicated to simulations ➢ Performs all tier 2 processing ➢ 2360 job slots; 420 TB of storage ➢ jobs SWT2_CPB ➢ 844 job slots ➢ Performs all tier 2 processing ➢ OU_OSCER ➢ jobs Campus cluster provides ➢ 10,000 job slots; 5.5 PB of storage ➢ additional simulation resources 2000 job slots, 700TB Storage ➢

Tier 2 Contributions Within ATLAS This chart show the cumulative contribution of CPU-seconds delivered by Tier 2's for successful processing jobs for the year (1/1 through 10/31) SWT2 is second largest in ATLAS!

SWT2_CPB ➢ Supports all ATLAS activities ➢ Current Deployed Resources: 20 Gbps external network connection ➢ 451 compute nodes ➢ 4928 cores / 9856 job slots ➢ At least 2 GB RAM per job slot ➢ 32 storage servers ➢ 5.5 PB usable storage ➢ 1 NFS server ➢ 1 admin server ➢ 14 grid/service nodes ➢

Grid Services ➢ Compute Element GLOBUS based access to local batch system for submitting work ➢ ➢ Storage Element Access to storage using GridFTP servers (2) ➢ ➢ Root Door Alternative access to storage ➢ ➢ Squid caching services CVMFS (distributed file system for experiment code base) ➢ Calibration data ➢ ➢ Monitoring services

Topology

Compute ➢ Dell R630 CPU: 2 x Xeon E5-2640 v4 2.4 GHz ➢ Broadwell 10 cores, 20 threads / CPU ➢ RAM: 128 GB , 2.133 GHz, DDR4 ➢ Storage: 2 x 800 GB SSD (RAID-0) ➢ Network: ➢ 2 x 10 Gbps (SFP+) ➢ 2 x 1 Gbps (Ethernet) ➢

Storage ➢ MD 3460 Shelf 60 x 8 GB SATA disk ➢ (4 x RAID 6 Disk Groups => 4 x 104 TB exported SAS drives) ➢ 4 x 12 Gbps SAS connections ➢ ➢ Dell R730 CPU: 2 x Xeon E5-2680 v4 2.8 GHz ➢ Broadwell 14 cores, 28 threads / CPU ➢ RAM: 256 GB, 2.133 GHz, DDR4 ➢ Network: 4 x 10 Gbps (SFP+), 2 x 1 Gbps (Ethernet) ➢ ➢ XrootD Federates storage into a common namespace ➢

Networking ➢ Core: 2 x Dell S6000 (LAG) 32 x 40 Gbps (QFSP+) ➢ ➢ TOR: Dell N4032F 24 x 10 Gbps (SFP+) ➢ 2 x 40 Gbps (QFSP+) ➢ ➢ Legacy: Dell N2048 48 x 1 Gbps (Ethernet) ➢ 2 x 10 Gbps (SFP+) ➢

Topology (revisited)

Conclusions ➢ The Southwest Tier 2 continues to be a valuable resource for the ATLAS experiment ➢ We are helping to enable the discovery of new physics at the LHC ➢ Our contributions will grow as we add more resources ➢ For more information visit www.atlas-swt2.org
