1.128 L INEAR A CTUATOR : S LIDE U NIT S ERIES NCX2 Courtesy of CMA/Flodyne/Hydradyne ▪ Motion Control ▪ Hydraulic ▪ Pneumatic ▪ Electrical ▪ Mechanical ▪ (800) 426-5480 ▪ www.cmafh.com S LIDE U NIT S ERIES NCX2 Bore sizes 10,15,25mm Magnetic sensing standard Slide bearing construction Mounting hole for shock absorber High accuracy positioning End plate housing mounting option T E C H N I C A L S PECIFICATIONS Type Non-Lube Type / Air-Hydro Type Fluid Air / LP Oil Proof Pressure 1.5MPa / 220 PSI Max Operating Pressure 1MPa / 150 PSI NCX2N10 0.15MPa / 22 PSI Either the housing or the plate can be fixed depending upon the application. Min Operating Pressure NCX2N1S 0.15MPa / 22 PSI Note: on the B type mounting (see “How to Order”), the NCX2N2S 0.1MPa / 15 PSI S E L E C T O R air supply is connected to the housing which is static. On Ambient and Operating Fluid Temp 5 ~ 60ºC / 40 ~ 140 O F the P type mounting, the air supply is connected to Piston Speed (Non-Lube Type) See List Below either end plate with the opposite end plugged. Cushion With Shock Absorber (Option) Stroke Adjustment Range 2~25.4mm / +0.08 ~ -1 inch NCX2N10 1Kg / 2.2 lb Note 1) Max Movable Load NCX2N1S 3Kg / 6.6 lb NCX2N2S 6Kg / 13.2 lb NCX2N10 +0.1 O Non Rotating Accuracy NCX2N1S +0.04 O (Except for bending of Piston Rod) NCX2N2S +0.02 O Note 1) please position the center of gravity of the load and the slide unit as close as possible. If this is not possible, please contact a SMCRepresentative. P I S T O N R O D P I S T O N R O D P I S T O N R O D A I R H Y D R O D E F L E C T I O N D E F L E C T I O N T YPE (R EFERENCE F ACTOR ) (R EFERENCE F ACTOR ) For a concentrated load at the center of For a concentrated load at the center of the end plate. Model End Plate Mounted Housing Mounted the housing. NCX2H15 * 0.2 ~ 2in/sec NCX2H25 0.2 ~ 1.6in/sec 0.2 ~ 4in/sec Deflection x 10 -3 inch Stroke (Inch) Stroke Inch Load Model Load (lb) Model (lb) 2 4 6 8 4 8 NCX2N10 2 2.8 - NCX2N10 0.5 2.4 11.8 - - NCX2N15 6 3.2 11 NCX2N15 1 3.5 8.7 14.7 39.4 H O W T O NCX2N25 13 0.8 3.2 NCX2N25 2 12 3.5 6.3 9.8 O R D E R Note) Values are the total amount of vertical deflection NCX2 S E R I E S S L I D E U N I T NC D X 2 N N O O F A U T O S W I T C H E S A U T O S W I T C H C A P A B L E A U T O S W I T C H - ……2 Pieces - ……Without Auto Switch S ……1 Piece See Accessories D ……With Auto Switch S T R O K E A D J U S T M E N T M O U N T I N G - ……With Adjustment Bolts (Std) S T R O K E ( I N C H ) B ……Housing fixed B ……With Shock Absorber P ……End plate fixed 100 … 1 BC …With Cap Type Shock Absorber 200 … 2 BCS …With One Cap Type Shock Absorber T Y P E 300 … 3 N ...Non-Lube 400 … 4 B O R E ( M M ) H ...Air Hydro Type 500 … 5 10, 15, 25 (except ø10) 600 … 6 700 … 7 800 … 8 D I M E N S I O N S S E E N E X T P A G E ☞ FOR FURTHER TECHNICAL DETAILS ON THIS PRODUCT, REQUEST CATALOG REFERENCE N340
1.129 L INEAR A CTUATOR : S LIDE U NIT S ERIES NCX2 Courtesy of CMA/Flodyne/Hydradyne ▪ Motion Control ▪ Hydraulic ▪ Pneumatic ▪ Electrical ▪ Mechanical ▪ (800) 426-5480 ▪ www.cmafh.com A CCESSORIES A CCESSORIES A UTO S WITCHES A PPLICABLE S HOCK A BSORBERS S ERIES NCX2 Note: Pre-wired Switches with 3/4 Pin Connectors available, please consult SMC Customer Service Model Type Operating Voltage Maximum Current D-A73 200VAC 5 ~ 10mA D-A73H Reed 24VDC 5 ~ 40mA Slide Unit Shock Absorber/Cap Type D-E73A 100VAC 5 ~ 20mA NCX2N10 D-A80 24VAC/DC or less 50mA NCDBX2N10 NRB031-025/NRBC031-025 D-A80H Reed 48VAC/DC or less 40mA NCDPX2N10 D-E80A 100VAC/DC or less 20mA NCX2N15 D-A76H Reed 4 ~ 8 VDC 20mA NCDBX2N15 NRB031-025/NRBC031-025 D-E76A NCDPX2N15 D-A73C Reed 24VDC 5 ~ 40mA NCX2N25 D-A80C Reed 24VAC/DC or less 50mA NCDBX2N25 NRB050-030/NRBC050-030 D-F79 3 Wire Solid State NPN 28VDC or less 150mA or less NCDPX2N25 D-F7P 3 Wire Solid State PNP - 100mA or less D-J79 2 Wire Solid State 24VDC (10~28V) 5 ~ 150mA D-F7NV 3 Wire Solid State NPN 28CVDC or less 150mA or less D-F7PV 3 Wire Solid State PNP - 100mA or less D-F7BV 2 Wire Solid State 24VDC (10 ~ 28V) 5 ~ 150mA D-F7PW 3 Wire Solid State PNP - 20mA or less D-J79W 2 Wire 24VDC (10 ~ 28V) 5 ~ 40mA D-F7BAL 2 Wire Solid State 24VDC (10 ~ 28V) 5 ~ 40mA D-J79C 2 Wire Solid State 24VDC (10 ~ 28V) 5 ~ 150mA D-F7LF 4 Wire Solid State NPN 26VDC or less 40mA or less D-F7NF 4 Wire Solid State NPN 28VDC or less 40mA or less D-F7NYTL 3 Wire Solid State NPN 28VDC or less 80mA or less D I M E N S I O N S BASIC TYPE N10 SERIES NCX2 4-ø0.25 Counter Bore Depth 0.16 +0.0004 0.08” 2-No10-32UNF 4-ø0.14 Through Hole Cylinder Ports ø0.24” 1.57 1.25” 0.78” 0.30” 5/16-32 UNEF 0.35” 2-0.151 +0.0012 ~ 0 Depth20 2-No8-32UNC Depth0.24 Bottom Holeø0.14 Through Applicable Pin Size 5/32 0.59” No10-32UNF 2 Holes Cylinder Port 0.63” 0.55” +0.0004 0.57” 0.35” 0.51” 4-0.151 +0.0012 ~ 0 Depth20 0.83” 0.35” 4-No8-32UNC Depth 0.24 Applicable Pin Size 5/32 0.875” 1.25” 1.81” Adjust Bolt ZZ Model F G L P Q R S SS Z NCX2N10-100 0.73 0.98 1.55 1.25 4.13 0.75 1.08 2.70 3.78 6.14 NCX2N10-200 1.23 1.48 2.55 1.25 6.13 0.75 2.08 3.70 5.78 8.14 2-ø0.26 Counter Bore Depth 0.13 NCX2N10-300 1.10 1.35 3.55 2.50 8.13 2.00 3.08 4.70 7.78 10.14 NCX2N10-400 1.60 1.85 4.55 2.50 10.13 2.00 4.08 5.70 9.78 12.14 MAX ZZ S E E I N S I D E F R O N T C O V E R F O R FOR FURTHER TECHNICAL DETAILS ON THIS DETAILS OF YOUR LOCAL SALES OFFICE PRODUCT, REQUEST CATALOG REFERENCE N340
1.130 L INEAR A CTUATOR : S LIDE U NIT S ERIES NCX2 Courtesy of CMA/Flodyne/Hydradyne ▪ Motion Control ▪ Hydraulic ▪ Pneumatic ▪ Electrical ▪ Mechanical ▪ (800) 426-5480 ▪ www.cmafh.com D I M E N S I O N S B A S I C T Y P E (N)15 S E R I E S NCX2 4-ø 0.31 Counter Bore Depth 0.18 2-No10-32UNF +0.0004 Cylinder Port 4-ø0.17 Through Hole ø0.32 1.63” 0.79” 1.63” 1.63 1.97 A +0.0012~0 0.16” 0.43” 2-ø0.183H9 4-No10-32UNF Depth 0.28 Depth 0.24/Applicable Pin 3/16 2-No10-32UNF Cylinder Port 0.87” 0.83” Adjust Bolt ZZ Z 0.83” Model F L P Q S SS 0.63” 3.86 5.98 NCX2_15-100 1.02 1.52 0.75 4.25 1.08 2.78 5/16-32UNEF 0.47” 0.39” 0.39” 5.86 7.98 4-No10-32UNF NCX2_15-200 1.14 2.52 1.50 6.25 2.08 3.78 Depth 0.28 7.86 9.98 NCX2_15-300 1.64 3.52 1.50 8.25 3.08 4.78 9.86 11.98 NCX2_15-400 1.39 4.52 3.00 10.25 4.08 5.78 1.63” 2.17” 11.86 13.98 NCX2_15-500 1.89 5.52 3.00 12.25 5.08 6.78 13.86 15.98 NCX2_15-600 2.39 6.52 3.00 14.25 6.08 7.78 15.86 17.98 4-Ø0.31 Counter Bore Depth 0.17 1.125 ” +0.0004 NCX2_15-700 2.89 7.52 3.00 16.25 7.08 8.78 4-ø0.17 Through Hole Adjustment Bolt 17.86 19.98 NCX2_15-800 3.39 8.52 3.00 18.25 8.08 9.78 D I M E N S I O N S B A S I C T Y P E (N)25 S E R I E S NCX2 4-ø0.37 Counter Bore 2-NPT 1/8 Depth 0.21 Plugged +0.0004 4-ø0.22 Through Hole ø0.55 2.63 2.63 3.11 2.63 1.38 4- 1/4 -28 UNF 2-ø0.245 +0.0014 ~ 0 0.74 0.20 Depth 0.35 Depth 0.32 Applicable Pin 1/4 2-NPT 1/8 0.75 inch stroke Cylinder Port 1.38 1.30 Adjust Bolt ZZ Model F L P Q S SS Z 1.26 NCX2_25-100 1.15 1.80 1.00 5 1.08 3.29 4.37 6.97 0.83 NCX2_25-200 1.15 2.64 2.00 7 2.08 4.29 6.37 8.97 0.63 0.67 0.63 4-1/4-28UNF 1/2-20 UNF NCX2_25-300 1.65 3.64 2.00 9 3.08 5.29 8.37 10.97 Depth 0.35 4-ø32 Through Hole NCX2_25-400 1.65 4.64 3.00 11 4.08 6.29 10.37 12.97 NCX2_25-500 2.15 5.64 3.00 13 5.08 7.29 12.37 14.97 2.63 3.31 NCX2_25-600 2.65 6.64 3.00 15 6.08 8.29 14.37 16.97 NCX2_25-700 3.15 7.64 3.00 17 7.08 9.29 16.37 18.97 NCX2_25-800 3.65 8.64 3.00 19 8.08 10.29 18.37 20.97 4-ø0.37 Counter Bore Depth 0.21 1.75 +0.0004 4-ø0.22 Through Hole FOR FURTHER TECHNICAL DETAILS ON THIS PRODUCT, REQUEST CATALOG REFERENCE N340
